TT-Chassis YAH100 - HiWatt Style, universal, Basic

Panel Mount Potentiometer - 3/8"

• Power Rating: 0,25 W
• Voltage Rating: 250 V AC
• Tolerance: 20%
• Shaft: 6,35 mm, Solid Shaft
• Shaft length: 15 mm
• Drill Ø: 3/8-32 (9,45 mm)
• Termination: Solder lugs
• Dimension: 24 mm

Panel Mount Potentiometer - 3/8"

• Power Rating: 0,25 W
• Voltage Rating: 250 V AC
• Tolerance: 20%
• Shaft: 6,35 mm, Solid Shaft
• Shaft length: 15 mm
• Drill Ø: 3/8-32 (9,45 mm)
• Termination: Solder lugs
• Dimension: 24 mm

TT-Cabs Headshell HiWatt Style, just like the original Hiwatt Headshell with white Piping, black mesh and handle with silver endcaps.

Specifications

• Size: ca. 635 x 270 x 285 mm
• Chassis Cut Out: ca. 475 x 64 mm
• Tolex: customer preference
• Hardware: Silber
• Piping: customer preference
• Weight: ca. 8 kg
• Wood: 18 mm Poplar

[content:3210136]

• Size: 143 x 37,5 mm
• Material: FR4, 2 mm
• Color: black
• Turrets: 2 x 15

TT-Cabs Headshell HiWatt Style, just like the original Hiwatt Headshell with white Piping, black mesh and handle with silver endcaps.

Specifications

• Size: ca. 635 x 270 x 285 mm
• Chassis Cut Out: ca. 475 mm
• Tolex: HiWatt black
• Hardware: Silver
• Keder / Piping: White
• Weight: ca. 8 kg
• Wood: 18 mm Poplar

[content:3210136]

• up to T 70 °C
• with one fuse holders 5.0 x 20 mm
• Housing: polyamide
• UL 94 V-0, black
• for snap-on mounting
• Double-pole + protective ground 10 A/250 V
• single-pole fusing with bridge to the fuse holder at the L terminal
• fuse holder terminals for soldering
• Design to IEC/EN 60320-1
• fuse holder to IEC/EN 60127-6
• Certifications: ENEC, Semko, UL, CSA

• Color: black
• Size:
  • A: 10 mm
  • B: 12 mm
  • D: 17,5 mm
  • H: 6,8 mm
  • h: 2 mm
• Material: soft PVC,UL 94 V-2
• Operating temperatures: –30 to +60 °C

Type: Noval Socket Belton VT9-ST-2

• Version: High quality Micalex socket
• Chassis mount
• Termination Style: solder lugs
• for Tube Type: 12AX7, 12AT7, 12AU7, EL84, EZ81, EL844 etc.

Octal Socket Belton VT8

• Version: High quality Micalex socket
• Chassis mount
• Termination Style: solder lugs
• for Tube Type: EL34, E34L, 6L6, 6V6, 6550, KT66/77/88 etc.

• Fuseholder, Chassismount, 5x20 mm
• IP 40
• Rated voltage: 250 VAC
• Rated current: 10 A (VDE), 16 A (UL/CSA)

Files:

• Datasheet

Clamp for capacitors

• Material: Steel, galvanized
• Diameter: 35 mm

• Type: Toggle Switch
• Version:DPST, ON - OFF
• Rating: 15A / 250VAC, 10A / 400VAC
• Contact resistance: 10 mΩ max. at 1A 2VDC
• Insulation resistance: 1.000 MΩ min. at 500VDC
• Dielectric strength: 2.000 Vrms 50 Hz min.
• Operating Life:    10.000 cycles at full load
• Termination Style: solder lug / quick-connect terminals

Files:

• Datasheet

1/4" mono jack, switched, with chrome ferrule and standard solder lugs
Mounting nut included

• Wide body and extremely durable contacts
• Mates with all mono A-gauge plugs acc. EIA RS-453 standard

Files:

• Datasheet

Signal lamp square red

• Operating voltage: 230 V~
• Power: 0,05 W
• Light/housing color: red
• Connection: soldering lugs
• Installation Ø: 10 mm
• Installation depth: 35 mm
• Overall dimensions (ØxL): 12x42 mm

TT-Cabs Headshell HiWatt Style, just like the original Hiwatt Headshell with white Piping, black mesh and handle with silver endcaps.

Specifications

• Size: ca. 635 x 270 x 285 mm
• Chassis Cut Out: ca. 475 x 64 mm
• Tolex: customer preference
• Hardware: Silber
• Piping: customer preference
• Weight: ca. 8 kg
• Wood: 18 mm Poplar

[content:3210136]

In collaboration with Howlin' Amps: Dumble-Style ODS 50 All-Tube Guitar-Amp Kit.
More information about this kit and and assembly instructions can be found on the project page and don't forget to check the Promo-Video on YouTube

This parts kit includes all the parts to build the Howlin' Amps Dumble ODS 50 including chassis, faceplate and knobs.
NOT included is a headshell.

Please note, very important and is really meant like this: To build the amplifier you need electrical engineering knowledge, experience with high voltages, as well as reading and understanding schematics and handling measuring instruments.
There is no step-by-step guide for beginners. The circuit and layout plan contains all relevant information

You do not want to build the amp by yourself ? This kit can also be delivered ready built and tested. If you are interested, please contact us...

Carbonfilm Resistor
Low noise, small size, high power rating
Power: 1 Watt
Voltag: 500 V working / 1000 V overload
Axial Leads
-55° C - 155° C
12 * 5 mm
RoHS

for building turret boards

• Tube-Town Turrets Type 32
• for 2 mm Boards
• Gold plated

• Type: Footswitch
• Version: SPDT latching ON - ON
• max. Rating: 2A / 250 VAC
• Drill Ø: 12 mm
• Termination Style: solder-lugs

Footswitch 3PDT

• Soft Touch, low actuation force
• for real bypass
• Solder lugs

• Size: 254 x 70 x 35 mm
• Color: Natural
