Tube-Town EZ-Board 2 x 15 Turrets, black, small

Aluminium chassis based on the YAH100 chassis, but without cut-outs, drillings etc.

• Size: 483 x 238 x 70 mm
• Material: 2 mm AlMg3
• Reinforced corner joints
• Net Weight ca. 1,4 kg
• Mounting: with cage nuts (not included)
• Made in Germany

• Faceplate Template

This chassis is based on a regular HiWatt chassis which was used for amplifiers up to 100 Watt. The chassis was adapted and optimized for the YAH100 kit but get used for other HiWatt Clones too.

• Size: 483 x 238 x 70 mm
• Material: 1,5 mm Steel
• hot zinc dipped
• Reinforced corner joints
• Made in Germany
• Mounting: with cage nuts (not included)

• Faceplate Template

Clamp for capacitors

• Material: Steel, galvanized
• Diameter: 35 mm

The rosette is versatile and ideal for construction and assembly projects. Thanks to the high-quality brass material and nickel-plated surface, it is well protected against corrosion and offers a long lifespan.

• Inner diameter (d1): 6.4 mm
• Outer diameter (d2): 20 mm
• Height (h1): 4 mm
• Standards: DIN 17670
• Material: Brass
• Surface: Nickel-plated
• Pack of 10

• Plastic covered with steel inner core
• Metal Endcaps w/ Plastic Cover
• Color: Black
• Screws and t-nuts included

• Handle Plastic covered with steel inner core
• Metal Endcaps w/ Plastic Cover

• Type: Countersunk raised head with cross recess
• Material: Steel
• Strength class: 4.8
• Surface: silver
• Price: per pcs.

• Type: Toggle Switch
• Version: SPST, ON - OFF
• Rating: 15A / 250VAC, 10A / 400VAC
• Contact resistance: 10 mΩ max. at 1A 2VDC
• Insulation resistance: 1.000 MΩ min. at 500VDC
• Dielectric strength: 2.000 Vrms 50 Hz min.
• Operating Life: 10.000 cycles at full load
• Termination Style: solder lug / quick-connect terminals

Files:

• Datasheet

• Type: Toggle Switch
• Version: DPDT  ON-ON
• Assembly Ø: 12.2 mm
• Switching current: 1,5 A
• Rating: 1,5 A / 250VAC, 3 A / 125VAC
• Insulation resistance: Min. 500 V/DC/100 MΩ
• Contact Resistance: Max. 50MΩ
• Termination Style: solder-lugs

• Type: Panel Mount Potentiometer
• Fender# 001-7502-000
• Power Rating: 0,5 W
• Voltage Rating: 750 V DC
• Drill Ø: 9,4 mm
• Termination: Solder lugs
• Dimension: 24 mm

Files:

• Datasheet

• Version: High quality Micalex socket
• Chassis mount
• Termination Style: solder lugs
• for Tube Type: 12AX7, 12AT7, 12AU7, EL84, EZ81, EL844 etc.

• Version: High quality Micalex socket
• Chassis mount
• Termination Style: solder lugs
• for Tube Type: EL34, E34L, 6L6, 6V6, 6550, KT66/77/88 etc.

• Power Rating: 0,25 W
• Voltage Rating: 250 V AC
• Tolerance: 20%
• Shaft: 6,35 mm, Solid Shaft
• Shaft length: 15 mm
• Drill Ø: M8 (7,8 mm)
• Termination: Solder lugs
• Dimension: 24 mm
