Speaker

B-STOCK:S peaker shows visible installation marks on the mounting holes, indicating prior installation.

The G12C is a 12" ceramic speaker with a 35 oz magnet and seamed cone. It's comparable to the Jensen C12n. However, our speaker has a warmer sound and more depth in the tone.

Thiele-Small Parameters

• Resonant Frequency (Fs): 134.10 Hz
• DC Resistance (Re): 7.71 Ohm
• Coil Inductance (Le): 0.30 mH
• Mechanical Q (Qms): 18.33
• Electromagnetic Q (Qes): 1.43
• Total Q (Qts): 1.33
• Compliance Equiv. Vol. (Vas): 8.76 cu ft
• Mech. Compliance of Susp. (Cms): 0.05 mm/N
• BL Product (BL): 11.80 T-M
• Diaphragm Mass Inc. Airload (Mms): 30.58 grams
• Surface Area of Cone (Sd): 366.10 cm squared
• Sound Pressure Level (spl): 99.48 db
