F+T 33 µF @ 500 Volt, axial

• Type: Chickenhead
• Material: Phenolic
• Shaft Size: 6 - 6,3 mm
• Size: 32 x 13,7 mm
• Mounting: Set-Screw

• Type: Toggle Switch
• Version:DPST, ON - OFF
• Rating: 15A / 250VAC, 10A / 400VAC
• Contact resistance: 10 mΩ max. at 1A 2VDC
• Insulation resistance: 1.000 MΩ min. at 500VDC
• Dielectric strength: 2.000 Vrms 50 Hz min.
• Operating Life:    10.000 cycles at full load
• Termination Style: solder lug / quick-connect terminals

• Datasheet

• Type: Toggle Switch
• Version: SPST, ON - OFF
• Rating: 15A / 250VAC, 10A / 400VAC
• Contact resistance: 10 mΩ max. at 1A 2VDC
• Insulation resistance: 1.000 MΩ min. at 500VDC
• Dielectric strength: 2.000 Vrms 50 Hz min.
• Operating Life: 10.000 cycles at full load
• Termination Style: solder lug / quick-connect terminals

Files:

• Datasheet

TT-Chassis Fender Style 5E3
Dimensions: 369 x  67 x 106 mm (W x H x D)
Lettering: Standby - Fuse - ON - Tone - Volume - Bright - Normal

Attention:
The Hammond Powertransformer 290AEX / 291AEX does not fit onto this chassis. Please use
290BEX/291BEX instead. The platevoltage of the 290BEX is 10V higher and it has a bias tap too, but that is
no problem!

Protective contact plug (Type F, CEE 7/7) > Loose cable ends.
The power cable with open ends and crimped wire end sleeves for confectioning. This power cable comes with a plug (angled) for connecting to electrical devices. The power cable can be creatively and versatilely used.

• Connection Type: Protective contact plug (Type F, CEE 7/7)
• Connection 2 Type: Loose cable ends
• Maximum Current Rating: 10 A
• Operating Voltage: 250 V (AC)
• Cable Length: 2m
• Conductor Cross-section: 0.75 mm²
• Cable Type: H05-VV-F3G
• Color: Black
• Markings: CE

This universal power cable is versatile and can be used for a variety of applications. It is perfect for replacing an old or damaged power cable.

• Connections: Schuko plug (Type F, CEE 7/7) and IEC C13 socket (cold device connection)
• Power: Max. current rating 10A, operating voltage 250V (AC)
• Cable: Cable type designation H05-VV-F3G, cable length 1.8m, conductor 0.75 mm²
• General: Color black, markings CE, WEEE, Packaging Type Retail Polybag

• Output Transformer 125A10B / 022923 Push-Pull
• for Princeton Reverb, Tweed Deluxe
• Pri: 8500 Ohm / CT
• Sec: 4, 8, 16 Ohm
• Power: 15 Watt

Files:

• Datasheet

Combining decades of experience with advanced measurement and analysis, the V-Type has been built using a carefully balanced 'recipe' of old and new design techniques. It produces a heady, exciting modern vintage sound that just makes you want to keep on playing: a speaker that delivers authentic Celestion tone whatever your style.The V-type is a sweet sounding speaker with a superbly balanced tonal signature that imparts a vintage musicality to your tone. Clean sounds are true across the lows, mids and highs, with just enough upper-mid chime and HF sparkle to add clarity and definition. Crank it up for a sizzling overdrive and raw rock tones, with plenty of mid-band warmth to give body and substance to lead note playing.

General Specifications

• Nominal diameter: 12", 305mm
• Power rating: 70Wrms
• Nominal impedance: Available 8Ω or 16Ω
• Sensitivity: 98dB
• Chassis type: Pressed steel
• Voice coil diameter: 1.75", 44.5mm
• Voice coil material: Round copper
• Magnet type: Ceramic
• Magnet weight: 31oz, 0.88Kg
• Frequency range: 70-5000 Hz
• Resonance frequency, Fs: 75Hz
• DC resistance, Re: Available 7.3Ω or 12.9Ω

Mounting Information

• Cut-out diameter: 11.1", 283mm
• Diameter: 12.2", 309mm
• Magnet structure diameter: 5.3”, 134mm
• Mounting slot dimensions: 0.31", 7.9mm Ø
• Mounting slot PCD: 11.7", 297mm
• Number of mounting slots: 8
• Overall depth: 4.84”, 123mm
• Unit weight: 7.2lb, 3.3kg

• Termination Style: Axial
• Power Rating: 5 W
• Tolerance: 5 %
• Temperature Coefficient: 350 PPM / C
• Operating Temperature min/max: - 55 C / + 155 C
• Voltage Rating: 500 V
• Diameter: 8,5 mm
• Length: 25 mm
• Lead Diameter:  0.75 mm
