Screw set for loudspeaker mounting

Originating from the Green Beret and Invader 50 lineage, the Invader 65HV celebrates our tonal heritage with remarkable proficiency. While retaining the authentic rock and roll character that established its predecessors, we’ve expanded on its capabilities with more power handling and a vented 50 oz. magnet giving greater SPL and thermal relief.

These build attributes result in a wide-ranging, potent voicing suitable for whatever style of guitar inspires you. Expect a refined harmonic profile—offering midrange complexity, smooth top end shimmer and a formidable bass presence. This design maintains extraordinary sensitivity to playing dynamics responding with remarkable clarity to every nuance of your technique, whether delivering delicate passages or commanding rhythmic chunk.

Building on the popularity of our G12C, we developed the G12Q for those times when you want the speaker to add some natural, vintage breakup but maintain clarity.  With a 20 oz magnet and a 1" voicecoil, the G12Q definitely has a vintage American flavor.  We highly recommend it with 5E3 style circuits.

Thiele-Small Parameters

• Resonant Frequency (Fs):91.91 Hz
• DC Resistance (Re): 7.70 Ohm
• Coil Inductance (Le): 0.26 mH
• Mechanical Q (Qms): 20.75
• Electromagnetic Q (Qes): 2.64
• Total Q (Qts): 2.35
• Compliance Equiv. Vol. (Vas): 22.17 cu ft
• Mech. Compliance of Susp. (Cms): 0.12 mm/N
• BL Product (BL): 6.57 T-M
• Diaphragm Mass Inc. Airload (Mms): 25.71 grams
• Surface Area of Cone (Sd): 366.10 cm squared
• Sound Pressure Level (spl): 95.92 db

Sacrificing none of the delicious musicality of your favourite Celestions, the Neo 250 Copperback is a neodymium speaker that supplies tons of tone without the signature cone break-up immediately associated with the classic Celestion growl.
It's definitely not the “brown sound”, but for those wanting more transparency and less midrange vocal intensity the Neo 250 reveals the best from your amplifier and playing without additional colouration. The speaker's unique response has a tight low end, neutral low mids, a clear, open upper-mid definition and well-controlled high treble, meaning you can shift from shimmering tubular-bell-like cleans to “flute-like” high gain with simply a tweak of the drive knob. Rated at a monstrous 250-watts, the Neo 250 works together with your amp to provide unparalleled dynamics, delivering all the headroom and touch sensitivity you could possibly need. And built with a neodymium magnet, you get all this power and tone weighing in at a modest 5.5lb (2.6kg)

General Specifications

• Nominal diameter: 12", 305mm
• Power rating: 250W
• Nominal impedance 16Ω
• Sensitivity: 100dB
• Chassis type: Pressed steel
• Voice coil diameter: 2.5", 63mm
• Voice coil material: Round copper
• Magnet type: Neodymium
• Frequency range: 70-5500Hz
• Resonance frequency, Fs: 55Hz

Mounting Information

• Cut-out diameter: 11.1", 283mm
• Diameter: 12.2", 309mm
• Magnet structure diameter: 4.9", 125mm
• Mounting slot dimensions: 0.31", 7.9mm Ø
• Mounting slot PCD: 11.7", 297mm
• Number of mounting slots: 8
• Overall depth: 5", 127mm
• Unit weight: 5.5lb, 2.6kg

Create your next signature sound with the Boston 10” guitar speaker. Spotlight your tone with a driver that delivers a warm, articulate bottom-end, scooped mids, and blooming highs.

This model includes a good old fashioned 1960’s style Alnico magnet assembly for an ultra-quick impulse response. The often-misunderstood magic of Alnico is that it partially and temporarily demagnetizes when you push them hard, applying a simple compression effect that adds a satisfying sense of sweetness that can't be beat.

American tone guitar speaker

• 10" (250 mm) steel basket diameter
• 20 watts, 8 ohm, 96 dB SPL
• 1" copper voice coil, Kraft paper former
• 6.8 oz alnico magnet
• USA-made seamed paper cone
• Size, Nominal (inch & mm): 10" (250 mm)
• RoHS Compliant: Yes
• Nominal Impedance (Z) (Ω): 8
• Rated Power IEC268-5 (W): 20 Watts
• Rated Impedance (Ω): 8
• Continuous Power (W): 20
• Program Power (W): 40
• Frequency Range (Hz): 55 - 6,200
• Sensitivity (dB SPL) ¹: 96
• Resonant Frequency (Fs) (Hz): 104
• DC Resistance (Re) (Ω): 6.3
• Voice Coil Inductance (Le) (mH): 0.35
• Mechanical Q Factor (Qms): 19.9
• Electrical Q Factor (Qes): 1.77
• Total Q Factor (Qts): 1.63
• Mechanical Resistance (Rms) (kg/s): 0.58
• Compliance Equivalent Volume (Vas) (L): 29.6
• Suspension Compliance (Cms) (mm/N): 0.1
• Surface Area of Diaphragm (Sd) (cm²): 397.6
• Moving Mass (Mms) (gm): 17.5
• Motor Force Factor (BL) (T•M): 6.4
• Efficiency (η₀) (%): 1.83
• Efficiency Bandwidth Product (EBP) (Fs/Qes): 58.8
• Basket Type: Cold-rolled steel
• Terminal Size (mm): 5.2 x 0.5 (Dual lug)
• Voice Coil Diameter (mm): 25.4
• Voice Coil Wire Material: Copper
• Voice Coil Former Material: Kraft paper
• Voice Coil Winding Style: Single Layer
• Magnet Material: Alnico
• Magnet Weight (g): 192.77
• Cone Body Material: Paper composite
• Cone Surround Material: Paper composite
• Dust Cap Material: Felt

The Neo Creamback is every ounce a Classic Celestion, delivering all the magical tone you’d get from a traditional Creamback. The difference is, it’s built with a neodymium magnet: making this speaker around half the weight of a traditional ceramic magnet speaker.Celestion’s engineers have developed a new and innovative way to better harness the mighty forces of the neodymium magnet, enabling us to create a guitar speaker that can deliver authentic Creamback tone with ease, while preserving the benefit of neodymium’s much lighter weight.You still get the low end punch, warm, vocal midrange and sweet refined highs the Creamback is famous for: push it hard and enjoy the ‘race-car growl’ that sets pulses racing. But pick up a cab that’s loaded with Neo Creambacks and you’ll see what makes this speaker truly different.


General Specifications

• Nominal diameter: 12", 305mm
• Power rating: 60W
• Nominal impedance: 8Ω & 16Ω
• Sensitivity: 97dB
• Chassis type: Pressed steel
• Voice coil diameter: 1.75", 44.5mm
• Magnet type: Neodymium
• Frequency range: 75-5000Hz
• Resonance frequency, Fs: 75Hz
• DC resistance, Re: 6.6Ω & 13.1Ω
• Voice coil former material: Round copper

Mounting Information

• Cut-out diameter: 11.1", 283mm
• Diameter: 12.2", 309mm
• Magnet structure diameter: 4.9", 124mm
• Mounting slot dimensions: 0.31", 7.9mm
• Mounting slot PCD: 11.7", 297mm
• Number of mounting slots: 8
• Overall depth: 4.8", 121.5mm
• Unit weight: 4.2lb, 1.9kg



Vintage American Ceramic Guitar Speaker
8″ seamed ribbed cone with small ceramic motor, replacement for Jensen C8R.

• Small Ceramic Magnet
• Power: 25 W
• Sensitivity: 94,5dB
• Weight: 1,2 kg
• VC Diameter: 1″
• 16 Ohm

With the Retro 10, we set out to build something with all the qualities we enjoy about our Retro 30 in a 10” speaker. It’s got a tight bottom, an articulate top end, and a nice low-midrange growl. It can be thought of as a distant cousin of the Green Beret 10, but with more low end, slightly more top end, and a shift in midrange characteristics.

Unit weight: 7.5 pounds

Thiele-Small Parameters

• Resonant Frequency (Fs): 115.58 Hz
• DC Resistance (Re): 6.27 Ohm
• Coil Inductance (Le): 0.17 mH
• Mechanical Q (Qms): 6.72
• Electromagnetic Q (Qes): 0.66
• Total Q (Qts): 0.6
• Compliance Equiv. Vol. (Vas): 16.26 cu ft
• Mech. Compliance of Susp. (Cms): 0.11 mm/N
• BL Product (BL): 10.99 T-M
• Diaphragm Mass Inc. Airload (Mms): 17.39 grams
• Surface Area of Cone (Sd): 324.29 cm squared
• Sound Pressure Level (spl): 100.62 db

The Revolution 65 provides the most sought-after British tones with a touch-sensitive dynamic range that offers versatility, clarity, shimmering treble, and a formidable low end to the mid-range foundation.
WGS ET65 Upgrade - more low end and fuller sound due to a larger magnet !

Vintage American Ceramic Guitar Speaker
8″ seamed ribbed cone with small ceramic motor, replacement for Jensen C8R.

• Small Ceramic Magnet
• Power: 15 W
• Sensitivity: 94,5dB
• Weight: 1,2 kg
• VC Diameter: 1″
• 16 Ohm
• Paper Coil

The 40 watt version of the Jensen Blackbird has smoother top end compared to the 100 watt version, making it suitable not only for crisp clean sounds but also good for crunchy leads.

Gene: Blues, Jazz, Rock'n Roll, Rockabilly

Technical Details:

• Size: 12"
• Impedance: 8 Ohm
• Rated Power (RMS): 40 W
• Sensitivity @ 1 W, 1 m: 96 dB
• Resonance Frequency  fs: 93,2 Hz

Thiele/Small Parameter (8 Ohm Version)

• Re: 5.9 Ω
• Fs: 93.2 Hz
• Qms: 14.29
• Mms: 28.7 g
• Qts: 1.36
• Bxl: 8.20 Tm
• Cms: 102 µm/N
• Sd: 490.9 cm²
• Vas: 34.6 l
• Le (1kHz): 0.40 mH

Featured in the world's top selling 4x12 cabinet, the G12T-75 is a high powered rock player's dream.

Built to meet the demands of high gain amplifiers, the G12T-75 combines a huge, tightly controlled low-end and aggressive mid-range with a softened top-end that adds a welcome sweetness to overdrive, distortion and aggressive upper harmonics. These are the characteristics that make the G12T-75 the weapon of choice for Yngwie Malmsteen.

General Specifications

• Nominal diameter: 12", 305mm
• Power rating: 75Wrms
• Nominal impedance: Available 8Ω or 16Ω
• Sensitivity: 97dB
• Chassis type: Pressed steel
• Voice coil diameter: 1.75", 44.5mm
• Voice coil material: Round copper
• Magnet type: Ceramic
• Magnet weight: 35oz, 0.99kg
• Frequency range: 80-5000Hz
• Resonance frequency, Fs: 85Hz
• DC resistance, Re: Available 6.77Ω or 12.9Ω

Mounting Information

• Cut-out diameter: 11.1", 283mm
• Diameter: 12.2", 309mm
• Magnet structure diameter: 5.7", 145mm
• Mounting slot dimensions: 0.31", 7.9mm Ø
• Mounting slot PCD: 11.7", 297mm
• Number of mounting slots: 4
• Overall depth: 5.0", 127mm
• Unit weight: 7.7lb, 3.5k

The brand new G8A Alnico from Warehouse Guitar Speakers. Highly recommended for the Champ, Vibro Champ, and many other 8" combos.

• Impedance: 4 Ohm
• Power: 20 Watt

It's hard to escape the sound of the G12H, just listen to any Hendrix recording and chances are you'll be hearing a whole raft of them powering the guitar out of the mix.

These faithful re-creations capture the unmistakeable mojo of late 60s rock guitar tones. Unsurpassed in a 4x12 for cranking out towering, huge power chords, the Heritage Series G12H (55) features the 55c/s 'bass' cone. This model is famous for its thick syrupy tones, with a deep growling back end, densely complex mid-range and a finely detailed top end.

General Specifications

• Nominal diameter: 12", 305mm
• Power rating: 30Wrms
• Nominal impedance: Available 8Ω or 15Ω
• Sensitivity: 100dB
• Chassis type: Pressed steel
• Voice coil diameter: 1.75", 44.5mm
• Magnet type: Ceramic
• Magnet weight:50oz, 1.42kg
• Frequency range: 55-5000Hz
• Resonance frequency, Fs: 55Hz
• DC resistance, Re: 6.53Ω and 12.11Ω

Mounting Information

• Cut-out diameter: 11.1", 283mm
• Diameter: 12.2", 309mm
• Magnet structure diameter: 6.6", 168mm
• Mounting slot PCD: 11.7", 297mm
• Number of mounting slots: 4
• Overall depth: 5.3", 135mm
• Unit weight: 10.4lb, 4.7kg

The original G12M of the 1960s was Celestion's first guitar speaker to use a ceramic magnet and paved the way for high power guitar amplifiers. The G12M uses a medium weight magnet to produce a sound that is smooth and warm but bright enough to hold its own against any rock backline.Known simply these days as the 'Greenback', the G12M's fabled 'brown tone' is characterised by a warm, controlled low-end, a rich, vocal mid-range and a delicate, detailed top-end. Loaded into a 4x12 and driven hard, these speakers exude warm, crunchy chords and sweet searing single-notes

General Specifications

• Nominal diameter: 12", 305mm
• Power rating:20Wrms
• Nominal impedance: 8Ω and 15Ω
• Sensitivity: 96dB
• Chassis type: Pressed steel
• Voice coil diameter: 1.75", 44.5mm
• Voice coil material: Round copper
• Magnet type: Ceramic
• Magnet weight: 35oz, 0.99kg
• Frequency range: 75-5000Hz
• Resonance frequency, Fs: 75Hz
• DC resistance, Re: 6.57Ω and 12.13Ω

Mounting Information

• Cut-out diameter: 11.1", 283mm
• Diameter: 12.2", 309mm
• Magnet structure diameter: 5.9", 150mm
• Mounting slot PCD: 11.7", 297mm
• Number of mounting slots: 4
• Overall depth: 5.1", 130mm
• Unit weight: 7.9lb, 3.6kg

With the Retro 10, we set out to build something with all the qualities we enjoy about our Retro 30 in a 10” speaker. It’s got a tight bottom, an articulate top end, and a nice low-midrange growl. It can be thought of as a distant cousin of the Green Beret 10, but with more low end, slightly more top end, and a shift in midrange characteristics.

Unit weight: 7.5 pounds

Thiele-Small Parameters

• Resonant Frequency (Fs): 115.58 Hz
• DC Resistance (Re): 6.27 Ohm
• Coil Inductance (Le): 0.17 mH
• Mechanical Q (Qms): 6.72
• Electromagnetic Q (Qes): 0.66
• Total Q (Qts): 0.6
• Compliance Equiv. Vol. (Vas): 16.26 cu ft
• Mech. Compliance of Susp. (Cms): 0.11 mm/N
• BL Product (BL): 10.99 T-M
• Diaphragm Mass Inc. Airload (Mms): 17.39 grams
• Surface Area of Cone (Sd): 324.29 cm squared
• Sound Pressure Level (spl): 100.62 db

A worthy successor to the Vintage 10, the G10 Vintage is a 10" speaker with bags of attitude. Using powerful ceramic magnets and the same voice coil design as the Vintage 30, the G10 packs an impressive punch with its 60W power handling.With the fast response of a 10" but with the strong and creamy vocal tones of a 12", the G10 is the ideal choice to add depth to hollow- sounding amps, or for players who want to get humbucker-type girth from single-coils. Can be used singly to add vocal warmth to small valve combos, or in quartets for a weightier but still lively attack:

General Specifications

• Nominal diameter: 10", 254mm
• Power rating: 60Wrms
• Nominal impedance: Available 8Ω or 16Ω
• Sensitivity: 97dB
• Chassis type: Pressed steel
• Voice coil diameter: 1.75", 44.5mm
• Voice coil material: Roundcopper
• Magnet type: Ceramic
• Magnet weight: 31oz, 0.88kg
• Frequency range: 100-5500Hz
• Resonance frequency, Fs: 115Hz
• DC resistance, Re: Available 7.47Ω or 12.33Ω

Mounting Information

• Cut-out diameter: 9.0", 229mm
• Diameter: 10.1", 256mm
• Magnet structure diameter: 5.3", 134mm
• Mounting slot dimensions: 0.2 x 0.3", 6 x 8mm
• Mounting slot PCD: 9.6", 245mm
• Number of mounting slots: 4
• Overall depth: 4.1", 104mm
• Unit weight: 5.3lb, 2.4kg

The 12” BlackHawk™ alnico speaker has finally arrived! Now your 1x12” 30-50 watt amp can really rock. This guitar speaker will give your amp pristine top end, tight mids, and all just the right amount of warmth and bottom end. This speaker is the 50 watt version of the 12” Black & Blue alnico. This 50 watt version has more low end than its 15 watt cousin. This speaker is the perfect upgrade for your VOX™ AC30. Drop in replacement for Celestion™ Gold™ alnico speaker.

Note: the naming is a bit awkward, because the difference to the Blackhawk HP is enormous. More correct would be the name "Black & Blue HP", so the 50 watt version of the Black&Blue or Celestion Blue.

Mounting Information

• Diameter: 12.2”
• Overall depth: 6.4”
• Cut-out diameter: 11.1”
• Mounting slot dimensions: 0.31”
• Number of mounting slots: 8

Thiele-Small Parameters

• Resonant Frequency (Fs): 110.42 Hz
• DC Resistance (Re): 7.98 Ohm
• Coil Inductance (Le): 0.35 mH
• Mechanical Q (Qms): 14.62
• Electromagnetic Q (Qes): 1.06
• Total Q (Qts): 0.98
• Compliance Equiv. Vol. (Vas): 13.30 cu ft
• Mech. Compliance of Susp. (Cms): .07 mm/N
• BL Product (BL): 12.42 T-M
• Diaphragm Mass Inc. Airload (Mms): 29.69 grams
• Surface Area of Cone (Sd): 366.10 cm squared
• Sound Pressure Level (spl): 100.08 db

The Invader 50 is the weeter and creamier version of the hugely popular Green Beret.  It retains all the same great rock and roll character with just a little sweeter top end and breakup.  The beefed up coil means you can now use it with higher wattage amps.  It's time to invade your amp with tone!

Thiele-Small Parameters

• Resonant Frequency (Fs): 82.67 Hz
• DC Resistance (Re): 7.83 Ohm
• Coil Inductance (Le): 0.34 mH
• Mechanical Q (Qms): 10.73
• Electromagnetic Q (Qes):0.81
• Total Q (Qts): 0.76
• Compliance Equiv. Vol. (Vas): 24.13 cu ft
• Mech. Compliance of Susp. (Cms):0.13 mm/N
• BL Product (BL): 12.08 T-M
• Diaphragm Mass Inc. Airload (Mms): 29.20 grams
• Surface Area of Cone (Sd): 366.10 cm squared
• Sound Pressure Level (spl): 99.03 db

Headroom, clarity, balanced response, power...
These terms have become synonymous with a vintage American design that is known and sought the world over.  WGS now pays tribute to this classic with our WGS12L. However like all of our designs, we didn't set out to make a clone.  With this model we paid extra special attention to the details, producing a speaker that delivers that same even response without sounding sterile and lifeless.  Boasting a cast frame, 2.5" voice coil and a 200 watt rating, and clocking in at 18 pounds, this beast is loaded for bear.  As a welcome addition to the WGS fleet, this speaker is definitely our battleship.

Note from the boss: "We compared both the EVM 12L and the WGS 12L in an 806 cabinet and it was almost impossible to tell them apart. The WGS 12L is a great alternative to the original and we recommend it without reservation as a perfect replacement for the EVM 12L."

Thiele-Small Parameters (8 Ohm Version)

• Resonant Frequency (Fs): 49.58 Hz
• DC Resistance (Re): 5.84 Ohm
• Coil Inductance (Le): 0.35 mH
• Mechanical Q (Qms): 7.41
• Electromagnetic Q (Qes): 0.25
• Total Q (Qts): 0.24
• Compliance Equiv. Vol. (Vas): 50.51 cu ft
• Mech. Compliance of Susp. (Cms): 0.27 mm/N
• BL Product (BL): 16.74 T-M
• Diaphragm Mass Inc. Airload (Mms): 38.77 grams
• Surface Area of Cone (Sd): 366.10 cm squared
• Sound Pressure Level (spl): 99.67 db

Inexpensive yet high quality 5F1 style combo with 8" speaker cutout.

Specifications

• Outside dimensions
  • Width: 345 mm
  • Height: 310 mm
  • Depth: 190 mm (bottom)
• Chassis cutout: 162 x 55 mm
• Tweed / Oxblood Style Gold
• Speaker cutout: 8"
• Loudspeaker: without
• Wood: 18 mm plywood
• TTC foreign product, Made in Asia

We have created a truly awesome 15" speaker with the G15! Now you can play a 15" with quick, articulate response, aggressive mid-range, & fat low end.

Thiele-Small Parameters

• Resonant Frequency (Fs): 100.45 Hz
• DC Resistance (Re): 6.4 Ohm
• Coil Inductance (Le): 8 mH
• Mechanical Q (Qms): 12.3144
• Electromagnetic Q (Qes): 1.188
• Total Q (Qts): 1.0835
• Compliance Equiv. Vol. (Vas): 2.165 cu ft
• Mech. Compliance of Susp. (Cms): 50.169 mm/N
• BL Product (BL): 11.64 T-M
• Diaphragm Mass Inc. Airload (Mms): 50.0389 grams
• Surface Area of Cone (Sd): 923.4744 cm squared
• Sound Pressure Level (spl): 99.03 db

Dish - Punched for 2 x 1/4" Jack Connectors

• Material: 1.2 mm Steel, black powder coated.
• Size: 78 x 88 mm
• Fixing holes Ø 10 mm

Were raw force reigns...

the sound technicians are at work and do not have the time to handle cables with tender love and care. This robust cable is especially intended for speakers and satifies all special technical demands. The oxygen-free copper strand provides better sound and more durability.
All PVC-versions are easy to wind. Versions SP215 and SP225 are now available with highly flexible 0.15 mm copper stranding!
New are the versions in FRNC and E30 (IEC 228, IEC 332-/1, IEC 332-3 Cat C, IEC 60331, IEC 61034-1/2, IEC 60754-2)

THE ADVANTAGES:

• Flexible and easily windable
• Small diameter
• Great durability through the use of a special jacket mixture
• Very affordable

THE APPLICATION:

• All types of sound systems
• For fixed installation
• Wiring of HiFi-systems

TECHNICAL DATA:

• Construction (2LIY1.50mm²)Y
• Diameter 6,8 mm
• AWG 16
• No. of conductors 2 x 1,5 mm²
• Jacket material, insulation PVC
• Copper strand per conductor 84 x 0,15 mm
• Conductor insulation, diameter 2,62 mm
• Temperature range min. -30 °C
• Temperature range max. 70 °C
• Fire load per m 0,28 kWh
• Weight per 1 m 78 g
• Color black

ELECTRICAL DATA:

• Capac. cond./cond. per 1 m 150 pF
• Cond. resistance per 1 km < 13 Ohm
• Insulat. resistance per 1 km > 5 MOhm

Cliff 1160 mono jack, vintage-style

• Jack socket, mono
• switched
• for chassis mounting, 4 solder terminals
• for 6.3 mm jack plug
• Used by Marshall and many others

Files

• Datasheet

The Invader 50 is the weeter and creamier version of the hugely popular Green Beret.  It retains all the same great rock and roll character with just a little sweeter top end and breakup.  The beefed up coil means you can now use it with higher wattage amps.  It's time to invade your amp with tone!

Thiele-Small Parameters

• Resonant Frequency (Fs): 82.67 Hz
• DC Resistance (Re): 7.83 Ohm
• Coil Inductance (Le): 0.34 mH
• Mechanical Q (Qms): 10.73
• Electromagnetic Q (Qes):0.81
• Total Q (Qts): 0.76
• Compliance Equiv. Vol. (Vas): 24.13 cu ft
• Mech. Compliance of Susp. (Cms):0.13 mm/N
• BL Product (BL): 12.08 T-M
• Diaphragm Mass Inc. Airload (Mms): 29.20 grams
• Surface Area of Cone (Sd): 366.10 cm squared
• Sound Pressure Level (spl): 99.03 db

B-STOCK: could have flaws in weaving

• Color and texture like the "Marshall Bluesbreaker" Grillcloth
• Size (W x L): ca. 80 x 100 cm (only available in this size)
• Material: 100% treated paper
• Price per pcs.
• Actual shades may vary.

Further information and notes on Grillcloth

• FAQ Grillcloth

Universal Mono/Stereo Terminal, replacement for Marshall Terminal ME-19605000 which is used in 2X12 or 4X12 Marshall speaker cabs, with extended connections and possibilities. For the used with a 4X12 a second wireset is needed to connect two speakers in parallel. Please see the list with recommended products.

If used with this speakers

• 2 x 8 Ohms or
• 4 x 16 Ohms or
• 4 x 4 Ohm

one will get the following connection options

• 4 ohm mono
• 8 ohm left + 8 ohm right stereo
• 8 ohm left only mono
• 8 ohm right only mono
• 16 ohm mono

Colorcodes:

• black: L-
• red: L +
• green: R -
• white: R +

Files:

• Datasheet

The 12” ET65™ speakers has big and creamy lows blend with tight midrange and sparkling highs for some of the best tones ever created! This speaker is for classic rock, country, and blues. Upgrade from your Celestion™ G12-65.

Unit Weight:  7.5 pounds

Thiele-Small Parameters

• Resonant Frequency (Fs): 98.69 Hz
• DC Resistance (Re): 8.05 Ohm
• Coil Inductance (Le): 0.35 mH
• Mechanical Q (Qms): 5.38
• Electromagnetic Q (Qes): 1.10
• Total Q (Qts): 0.91
• Compliance Equiv. Vol. (Vas): 16.75 cu ft
• Mech. Compliance of Susp. (Cms): 0.09 mm/N
• BL Product (BL): 11.58 T-M
• Diaphragm Mass Inc. Airload (Mms): 29.51 grams
• Surface Area of Cone (Sd): 366.10 cm squared
• Sound Pressure Level (spl): 99.45 db

Cabinet corner leather dark brown, Set of 4
100 % real letaher, vegetable tanned
Caution: natural product ! The texture and thickness may vary.

Hint: put the corners into water for a few minuties before mounting. This makes them soft and elastic and than they will fit better.
The corners on the chassis should be well rounded too in order to achieve best results.

50 mm Swivel Castor. Steel frame and plate, zinc plated. Grey rubber wheel on bolted hub. Unbraked.
Height: 72 mm
Safe running load per set of four: 120 kg

50 mm Swivel Castor. Steel frame and plate, zinc plated. Grey rubber wheel on bolted hub. Braked wheel and swivel.
Height: 72 mm
Safe running load per set of four: 120 kg

Case Handle imitation leather, Dog-Bone Style

• Mounting fittings: Steel, nickel plated
• Color: Red
• WITHOUT NUTS AND SCREWS

• Size: ca. 60 x 90 cm (only available with this size)
• ORIGINAL FENDER
• Material: 100% Polypropylen
• Price per pcs.
• Actual shades may vary.

Further information and notes on Grillcloth

• FAQ Grillcloth
