TT-Chassis 030 - LoW XL

• Type: Octal Socket Fender Style
• Version: Ceramic Chassis mount
•   w/mounting bracket
• Termination Style: solder lugs
• for Tube Type: EL34, E34L, 6L6, 6V6, 6550,
•   KT66/77/88 etc.

• Version: High quality Micalex socket
• Chassis mount
• Termination Style: solder lugs
• for Tube Type: 12AX7, 12AT7, 12AU7, EL84, EZ81, EL844 etc.

• up to T 70 °C
• with one fuse holders 5.0 x 20 mm
• Housing: polyamide
• UL 94 V-0, black
• for snap-on mounting
• Double-pole + protective ground 10 A/250 V
• single-pole fusing with bridge to the fuse holder at the L terminal
• fuse holder terminals for soldering
• Design to IEC/EN 60320-1
• fuse holder to IEC/EN 60127-6
• Certifications: ENEC, Semko, UL, CSA

Empty amplifier housing for TT-Chassis #030
The headshell is made of 18 mm Pine Plywood and can be painted or tolexed by the customers to their own ideas. The front and back panel and the holders are not assembled but included. They can get assembled if needed (woodglue is included).
Hardware, such as corners, handles or feet are NOT included.

Note: the side brackets inside are NOT needed when using chassis 036 - model 2020.

Specifications

• Size: 510 x 240 x 240 mm (Outside)
• Hardware: Screws are included.
• Weight: ca. 4 kg
• Wood: 18 mm Pine Plywood
• Dovetail joints
• Made in Germany

Empty amplifier housing for TT-Chassis #030
The headshell is made of 18 mm Pine Plywood and can be painted or tolexed by the customers to their own ideas. The front and back panel and the holders are not assembled but included. They can get assembled if needed (woodglue is included).
Hardware, such as corners, handles or feet are NOT included.

Note: the side brackets inside are NOT needed when using chassis 036 - model 2020.

Specifications

• Size: 510 x 240 x 240 mm (Outside)
• Hardware: Screws are included.
• Weight: ca. 4 kg
• Wood: 18 mm Pine Plywood
• Dovetail joints
• Made in Germany

Set of componentes for building the TT Jim HP. Please visit the >>Project page for more infos about the amp.

INCLUDED:

• Transformers for 220, 230 and 240 V Mains
• Outputtransformer
• Resistors
• Capacitors
• Jacks
• Light
• Wires
• Board
• Switche
• PSU
• Tubes (2 x 12AX7, 1 x EL34)
• Fuses & Fuesholder

NOT INCLUDED:

• Knobs
• Chassis
• FX-Loop
• Faceplate

To build this project knowledge in electric engeneering, experience with high voltage, and the reading and understanding of schematics and dealing with measurement device is highly recommended .
There is NO step-by-step guide for beginners. The circuit and layout plan includes all relevant information. If you don't understand it than don't build it.

PVC piping for baffles and front panels

• Size 3.1 x 8.5 mm
• 4 m piece

• Version: Raised Handle imitation leather
• Mounting caps: Steel, nickel plated
• Color: Black
• Mounting hardware: included

• Size: ca. L: 60 cm x W: 90 cm (only available with this size)
• Material: 94 % Polypropylen, 6 % Acrylic
• Price per pcs.
• Actual shades may vary.

• FAQ Grillcloth

• Type: Chickenhead
• Material: Phenolic
• Shaft Size: 6 - 6,3 mm
• Size: 32 x 13,7 mm
• Mounting: Set-Screw

• Type: Chickenhead
• Material: Phenolic
• Shaft Size: 6 - 6,3 mm
• Size: 32 x 13,7 mm
• Mounting: Set-Screw

• Material: Phenolic
• Shaft Size: 6 - 6,4 mm
• Size: 19,5 x 15,3 mm
• Mounting: Set-Screw, hexagon

Set of componentes for building the TT Jim HP. Please visit the >>Project page for more infos about the amp.

INCLUDED:

• Transformers for 220, 230 and 240 V Mains
• Outputtransformer
• Resistors
• Capacitors
• Jacks
• Light
• Wires
• Board
• Switche
• PSU
• Tubes (2 x 12AX7, 1 x EL34)
• Fuses & Fuesholder

NOT INCLUDED:

• Knobs
• Chassis
• FX-Loop
• Faceplate

To build this project knowledge in electric engeneering, experience with high voltage, and the reading and understanding of schematics and dealing with measurement device is highly recommended .
There is NO step-by-step guide for beginners. The circuit and layout plan includes all relevant information. If you don't understand it than don't build it.
