Fender Style Pilot Light Set - blue

• Size: 365 x 160 x 65 mm
• Same size as the Chassis 005 but with closed sides
• 2 mm Aluminium
• Mounting: with cage nuts (not included)
• Made in Germany

• Datasheet

• Can be used as Voltage or Impedance selector
• 1 pole / 3 position
• 3 A @ 250 VAC
• 6 A @ 125 VAC
• Solder lugs
• Size: 28 mm x 39,5 mm
• Frontpanel drill: 10,5 mm
• Shaft Diameter 6 mm, D-Shaft

Carbonfilm Resistor
Low noise, small size, high power rating
Power: 1 Watt
Voltag: 500 V working / 1000 V overload
Axial Leads
-55° C - 155° C
12 * 5 mm
RoHS

Carbonfilm Resistor
Low noise, small size, high power rating
Power: 1 Watt
Voltag: 500 V working / 1000 V overload
Axial Leads
-55° C - 155° C
12 * 5 mm
RoHS

• Rubber foot with steel insert
• Size: d = 38 mm, h = 25 mm
• Pack of 4

• Type: Toggle Switch
• Version: DPDT   ON - ON
• Rating: 15A / 250VAC, 10A / 400VAC
• Contact resistance: 10 mΩ max. at 1A 2VDC
• Insulation resistance: 1.000 MΩ min. at 500VDC
• Dielectric strength: 2.000 Vrms 50 Hz min.
• Operating Life:    10.000 cycles at full load
• Termination Style: solder lug / quick-connect terminals

Files:

• Datasheet

High-power level control, plastic carrier, mono version, with push-on knob.

Technical Specifications

• Impedance: 8 Ohm ±20%
• Attenuation direction: counterclockwise
• Turning angle: 300° ±5°
• Attenuation: 0dB up to 8dB
• Channels: mono
• Peak current: max. 100W
• Thread: 10 mm

Files:

• Datasheet

• Type: Metalized polypropylene film Capacitors
• Capacitance: 2,2 µF
• Voltage Rating: 630 V
• Tolerance: - 5% / +5 %
• Operating Temperature Range: - 25°C / + 85 °C
• Dimensions: Ø 18 mm x 34 mm
• Termination Style: axial
• Small size
• self-healing
• non inductive

These axial capacitors are specially appreciated for their high sonic performances.
