Toggle Switch 3PDT - ON-OFF-ON

• Angled phone plug
• 6.3 mm, mono
• metal housing, silver

• Type: Toggle Switch
• Version: 4PDT, ON-OFF-ON
• Assembly Ø: 5,8 mm
• Rating: 5 A / 250VAC, 2 A / 125VAC
• Termination Style: solder-lugs

• Size: 6.3 mm 1/4"
• Poles: 2-pole, mono
• Design: straight
• Connection type: solder terminals
• Housing: metal, large
• Color: black
• Cable outlet: max 9 mm

• Datasheet

• Size: 6.3 mm 1/4"
• Poles: 2-pole, mono
• Design: right angle
• Connection type: solder connections
• Housing: metal
• Color: silver
• Cable entry: max 7 mm
• Manufacturer: Rean (by Neutrik)

Files:

• Datasheet

This high end guitar cable is one of the most successful products of the past years and enjoys cult status with guitarists and bassists alike. Because of the excellent price-performance ratio, German and international trade press elected the SC-SPIRIT XXL test champion several times in a row.
The cable is robust and yet flexible, while its smoke-coloured jacket gives it a high recall value.
The shielding is ideal: The braiding is 95 % opaque and provides optical protection of 100 %, for even more safety.
A special lacquering makes the complex foamed polyethylene insulation very endurable and helps protect the excellent transmission properties for years to come.
The wire diameter of 0.75 mm² limits the loss typical for long distance guitar cables. There is hardly a guitar cable at a length of 10 m that sounds as good as the SC-SPIRIT XXL.
The customers consider the sound of the SC-SPIRIT XXL to be crystal-clear, clean and very neutral. It reproduces the impulsiveness of bass attacks exquisitely.
Caution: The black carbon shield between the braided shielding and the insulation is highly conductive. It must be removed before soldering to avoid short circuiting!

THE APPLICATION:

• Enormously powerful and clear sound image for bass, guitar and keyboard
• Double shielding due to the combination of copper braided shield and conductive carbon shielding
• Transmission free of losses due to low capacity and large wire diameter
• Very flexible and easy to wind due to the use of fine individual stranding
• Durability and robustness due to a special high quality PVC-mixture for the jacket
• High quality guitar and bass cable for studio and stage
• Unbalanced cable for keyboards, samplers, mixing boards, etc.
• Connection of stereo video recorder and DAT-recorder

• Construction LI2Y(LS)CY 1x0,75mm²
• Jacket, diameter PVC 6,8 mm
• AWG 18
• Inner conductors 1 x 0,75 mm²
• Copper strand per conductor 42 x 0,15 mm
• Conductor insulation Foam/skin-PE 3,1 mm
• Shielding copper spiral tin-plated + semiconductor
• Shielding factor 100 %
• Temperature range min. -30 °C
• Temperature range max. 70 °C
• Fire load per m 0,26 kWh
• Weight per 1 m 52 g
• Color black transparent

• Capac. cond./shield. per 1 m 86 pF
• Cond. resistance per 1 km 25 Ohm
• Insulation resist. per 1 km > 50 MOhm

The SC-CLASSIQUE looks old, but the technology is new and unused. The core is made up of an inside lead with a diameter of 0.5 mm², consisting of 28 individual fine copper litz, ensuring untainted musical pleasure across lengths of 20 m often considered a problem by spoiled musicians. The cable is rounded off by a thick insulation of foamed and lacquered PE and dense, tin-plated copper braiding. Eye-catching is the additional fabric coating giving the SC-CLASSIQUE the necessary vintage styling. And it also sounds like a cable from the sixties:
The SC-CLASSIQUE convinces with a lot of warmth, a solid sound, and heights as clear as glass.

• The warm and fat sound image of the "Sixties"
• Robust textile jacket in vintage styling
• Very low capacity and double shielding made of copper braiding + semiconductor
• Easily windable

• High-end guitar and instrument cable with vintage styling
• Unbalanced cable for stage and studio

• Construction LI2Y(LS)CY1x0,50mm²
• Jacket, diameter PVC + fabric 7,0 mm
• AWG 21
• No. of inner conductors 1 x 0,50 mm²
• Copper strand per conductor 28 x 0,15 mm
• Conductor insulation Foam PE 2,2 mm
• Shielding copper braiding tin-plated + semiconductor
• Shielding factor 100 %
• Temperature range min. -20 °C
• Temperature range max. 70 °C
• Fire load per m 0,26 kWh
• Color: tweed-yellow
• Weight per 1 m 65 g

• Capac. cond./shield. per 1 m < 80 pF
• Cond. resistance per 1 km < 40 Ohm
• Insulation resist. per 1 km > 1 GOhm

• Material: Phenolic
• Shaft Size: 6 - 6,3 mm
• Size: 19 x 14,5 mm
• Mounting: Hexagon Set-Screw

• Material: Phenolic
• Shaft Size: 6 - 6,3 mm
• Size: 19 x 14,5 mm
• Mounting: Hexagon Set Screw

The signal lamps for front panel installation are designed for screw mounting with a recommended installation hole of Ø8mm. The sockets can be supplied with an external or internal reflector. The plug insert is removable. Supplied with washer and hexagonal nut.

• Size: 91,5 x 124 x 45,1 mm
• Material: 1,5 mm Steel (DC01 / Sendzimer) - Extra heavy !
• Made in Germany

• Datasheet

• Length: 117 mm
• Width: 38 mm
• Solder Lugs: 2 x 18
• Distance between Solder Lugs: 6 mm
• Laminated Paper

• Soft Touch, low actuation force
• for real bypass
• Solder lugs
