Strap Handle black, large

The F12M-150 is a full range, LIVE response speaker, purpose designed for use with amp modellers and IRs.
Its unique design features two additional tweeter cones integrated into the main woofer cone (making it “Triple Cone”).
This enables the speaker to deliver near full-range frequency performance: from 60Hz up to 12kHz, for a rich and detailed sound, whatever your set-up.

Designed with Celestion’s Pro Audio know-how, response is flat and neutral, ensuring no unwanted colourations that could overwhelm the input signal.
But with an optimised woofer cone and lighter moving mass the F12M-150 Triple Cone is designed to closely mimic the responsiveness of a traditional guitar speaker,
delivering all the tactile feel you would expect from playing through a conventional guitar rig. It’s not just FRFR, it’s Full Range LIVE Response.


Specifications

• Nominal diameter 305mm / 12in
• Power rating 150W
• Rated impedance 8Ω
• Sensitivity 97dB
• Chassis type Pressed steel
• Magnet type Ceramic
• Magnet weight 0.9kg / 35oz
• Voice coil diameter 2in / 51mm
• Voice coil material Round copper
• Frequency range 60-12,000Hz
• Resonance frequency, Fs 70Hz
• DC resistance, Re 6.07Ω

Parameters

• D 0.26m / 10.24in
• Fs 69.4Hz
• Mms 44.772g / 1.58oz
• Qms 10.446
• Qes 0.992
• Qts 0.906
• Re 6.07
• Vas 46.89l / 1.66ft3
• BI 10.923
• Cms 0.118
• Rms 1.868
• Le (at 1kHz) 0.12

Mounting Information

• Cut-out diameter 283mm / 11.1in
• Diameter 283mm / 11.1in
• Magnet structure diameter 145mm / 5.7in
• Mounting hole dimensions 7.9mm / 0.31in Ø
• Mounting hole PCD 297mm / 11.7in
• Number of mounting holes 8
• Chassis depth (inc gasket) 94mm / 3.7in
• Magnet depth 33mm / 1.3in
• Overall depth 127mm / 5in
• Unit weight 3.6kg / 7.9lb

• Size: 6.3 mm 1/4"
• Poles: 2-pole, mono
• Design: open, chassis-mount
• Connection type: solder connections
• Housing: metal
• Manufacturer: Rean (by Neutrik)

Files:

• Datasheet

TT Selection: Balanced
Both systems with balanced gain

JJ's version of the ECC81/12AT7 tube type with a warm and soft sound. Often used for phase inverters or reverb drivers.

Files:

• Datasheet

Optocoupler. Vibrato LDR for Fender Amps.

• Optical side indicated by the dot

Large plate format Twin Triode, ideal for use in driver and reverb circuits. Offers superior dissipation compared to NOS versions of this tube.

Note: Tubes equipped with long plates are commonly associated with a "warmer" or "richer" sound, whereas those with shorter plates tend to deliver a "tighter sound". However, tubes featuring long plates exhibit increased sensitivity to vibrations and mechanical disturbances, rendering them less ideal for critical applications.

•

• Type: Aluminum Electrolytic Capacitors
• Capacitance: 22 µF
• Voltage Rating: 500 V
• Tolerance: +/- 20%
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 18 mm x 39 mm
• Termination Style: axial

• Type: Electrolytic capacitor
• Capacitance: 22 µF
• Voltage Rating: 35 V
• Tolerance: - 10 % / +30 %
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 5 mm x 11 mm
• Termination Style: axial
• Color and manufacturer may differ from the picture shown

Images are for reference only. See Product Specifications
