Rean NYS225B - 6,3 mm (1/4") phone plug, mono

• Type: Panel Mount Potentiometer
• Power Rating: 0,25 W log / 0,5 W linear
• Voltage Rating: 250 V DC Audio / 500 V DC linear
• Tolerance: 20%
• Shaft: 6,35 mm, Solid Shaft
• Shaft length: 15 mm
• Drill Ø: M8 (7,8 mm)
• Termination: Solder lugs
• Dimension: 24 mm

• 1x internal and 1x external thread
• Thread size: M4
• External thread: 8.0 mm
• Internal thread: 8.0 mm
• Material: galvanised steel
• Length: 15 mm

• up to T 70 °C
• with one fuse holders 5.0 x 20 mm
• Housing: polyamide
• UL 94 V-0, black
• for panel mounting
• Double-pole + protective ground 10 A/250 V
• single-pole fusing with bridge to the fuse holder at the L terminal
• fuse holder terminals for soldering
• Design to IEC/EN 60320-1
• fuse holder to IEC/EN 60127-6
• Certifications: ENEC, Semko, UL, CSA

Cliff 1160 mono jack

• Jack socket, mono
• switched
• for chassis mounting, 4 solder terminals
• for 6.3 mm jack plug
• Used by Marshall and many others

Files

• Datasheet



Cliff 1220 stereo jack

• Jack socket, stereo
• switched
• for chassis mounting, 6 solder terminals
• for 6.3 mm jack plug, stereo

Files

• Datasheet



• Size (B x L) : 74 x 100 cm (only available with this size)
• Material: 94 % Polypropylen, 6 % Acrylic
• Price per pcs.
• Actual shades may vary.

Further information and notes on Grillcloth

• FAQ Grillcloth

Superior medium-mu small signal twin triode with high transconductance. May be used instead of 12AX7/ECC83 in first gain stage of various amps for a more linear, vintage response.

• Originally designed for use in audio preamplifiers requiring low microphonics and good linearity, such as Fender "Tweed" Series
• Perfect replacement for any 6072/12AY7 type
• Relabeled Electro-Harmonix vacuum tubes are used by many OEMs in their amplifiers

• Type: Hex Head
• Material: Polyamide
• Color: white
• Surface: Zinc-plated
• ISO: 4017
• Price: per pcs.
