Grommet 8 mm

• Choke for Fender 125C1A & 022699
• Bandmaster, Dual Showman, Pro Reverb, Twin Super
• 4 H

Files:

• Datasheet

NLJ2MD-V

2 pole combination of speakON socket and 1/4" jack receptacle, vertical pcb mount, same pcb footprint and panel cut out as NL4MD-H

First speakON / jack hybrid panel mount connector combining the speakON chassis connector with a 1/4" 2 pole jack socket permitting connection using either type of plug. The speakON Combo mates with all 2- and 4-pole speakON cable connectors and 1/4" jack plugs utilizing 2 contacts.

Features & Benefits

• Combine Speakon D size receptacle and 1/4" jack
• Save rack space and costs by combining 2 connectors in one housing
• Mates with two types of connectors offering greater flexibility of interconnections
• Rear panel mount
• PA-wiring: 1+ is connected to Tip, 1- to Sleeve

Files:

• Datasheet

• Power Rating: 0,125 W
• Voltage Rating: 150 V AC
• Tolerance: 20%
• Shaft: 6,35 mm, Solid Shaft
• Shaft length: 15 mm
• Drill Ø: M7 (6,8 mm)
• Termination: PCB
• Dimension: 16 mm
• Switch: DPDT

Screw set for Torodial-Transformers

1 x Screw M5*30 mm
1 x Screw Lock Nut M5
2 x Washer M5

suitable for this TT Transformers:

tt-t27

• Termination Style: Axial
• Power Rating: 5 W
• Tolerance: 5 %
• Temperature Coefficient: 350 PPM / C
• Operating Temperature min/max: - 55 C / + 155 C
• Voltage Rating: 500 V
• Diameter: 8,5 mm
• Length: 25 mm
• Lead Diameter:  0.75 mm

Stranded copper wire AWG 20 ca. 0.52 mm² with modern insulation and lacquered cotton braid finish

• Conductor cross-section: AWG 20 approx. 0.52 mm²
• Length: 50 ft / 15,2 m
• Temperature rating: 105°C
• Voltage Rating: 600V

• Pushback Wire, solid copper, tinned
• With vintage cotton fabric insulation
• Cross-Section: AWG #22 / 0,32 mm²
• Outer Diameter:  0,64 mm
• Packing: Spool 50 ft / ca. 15 m

• Pushback Wire, solid copper, tinned
• With vintage cotton fabric insulation
• Cross-Section: AWG #22 / 0,32 mm²
• Outer Diameter:  0,64 mm
• Packing: Spool 50 ft / ca. 15 m
