Neutrik NMJ6HCD2 - 6,3 mm Stereo switched, PCB

Steel Bottom Plate for Hammond 1441 and 1431-Series Chassis

• Size: 203,5 x 102 mm

• Inductance (+/- 15%): 10 H
• Resistance (+/- 15%): 408 Ohm
• max Current DC: 50 mA
• max Voltage DC: 500 V
• Leads: min 12 cm
• Hipot tested (100%) mit 1500 VAC

• Datasheet

• Pri: 0-120-230-240 V (black-yellow-purple-red)
• Sec 1: 200 V @ 0,085 A (red)
• Sec 2: 6,3 V @ 2 A (green)
• long leads ca 200 mm
• h=35mm d=70mm
• 50/60 Hz EN 61558

TT Selection: Balanced
Both systems with balanced gain

ECC82 / 12AU7 medium gain pre-amplifying double triode.
Provides a very smooth sound with well-defined tones suitable for audio and guitar amplifiers.


Files:

• Datasheet

 Fits for the Hammond Chassis 1441 / 1444 Serie

• Type: Fillister-head with cross recess
• Material: Steel
• Surface: zinc-plated
• Price: per 6 pcs.

All JJ preamptubes are selected within a close tolerance and handtested for best sound and quality. Furthermore all pins are gold plated to achieve best electrical contact.
What about the sound ? It is still the famouse and well known JJ brownsound - warm and smooth.

Files:

• Datasheet

• Type: Aluminum Electrolytic Capacitors
• Capacitance: 100 µF
• Voltage Rating: 100 V
• Tolerance: +/- 20%
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 10 mm x 30 mm
• Termination Style: axial

• Type: Aluminum Electrolytic Capacitors
• Capacitance: 47 µF
• Voltage Rating: 450 V
• Tolerance: - 20 % / +20 %
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 18 mm x 39 mm
• Termination Style: axial

• Type: Aluminum Electrolytic Capacitors
• Capacitance: 47 µF
• Voltage Rating: 500 V
• Tolerance: +/- 20%
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 21 mm x 37 mm
• Termination Style: axial

• Type: Aluminum Electrolytic Capacitors
• Capacitance: 220 µF
• Voltage Rating: 350 V
• Tolerance: - 10%+30%
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 25 mm x 38 mm
• Termination Style: axial
