MOD Reverb Tank 8BB2C1B

• Type: Footswitch
• Version: 3PDT Latching
• for True Bypass
• Rating: 1A/9VDC
• Contact resistance: <30mΩ
• Insulation resistance: 500VDC-100MΩ min.
• Dielectric strength: 500VAC for 1 minute
• Operating Life: 30.000 cycles
• Termination Style: solder-lugs

Files:

• Datasheet

Superflat 6.3 mm jack plug, massive pin with gold-plated tip, solder version, black metal housing, 90° angled, moisture-repellent insulation, cable Ø 4.0 - 6.4 mm, with clamping strain relief, ideal for space-saving cabling of effects pedal boards.

• Size: 6.3 mm 1/4"
• Pole: 2-pin, mono
• Design: angled
• Connection type: solder connections
• Housing: metal, extra flat
• Color: silver
• Cable pickup: max 7 mm
• Manufacturer: HiCon

2 tubes, matched as pair

JJ 6V6 Double Mica double-layered mica in the upper part of the tube. This stabilizes the tube system and significantly reduces possible vibrations that can occur due to heavy mechanical stress. This version of the JJ 6V6 was specifically designed for use in combo amplifiers.

The JJ6V6 is a beam power pentode with octal base and a maximum plate dissipation of 14W. It has fat low end and full mid tones with very good tone separation and a smooth, clean high end - in general, a very balanced tone.
Currently, the only new production 6V6 which is approved for up to 500V anode voltage in pentode operation.

Files:

• Datasheet

Superior medium-mu small signal twin triode with high transconductance. May be used instead of 12AX7/ECC83 in first gain stage of various amps for a more linear, vintage response.

• Originally designed for use in audio preamplifiers requiring low microphonics and good linearity, such as Fender "Tweed" Series
• Perfect replacement for any 6072/12AY7 type
• Relabeled Electro-Harmonix vacuum tubes are used by many OEMs in their amplifiers
