JJ 12AU7 / ECC82 Balanced

The G12H-150 Redback has been created for players who are looking for extreme power handling but refuse to compromise on great tone.
Rated at a gargantuan 150-watts the Redback is constructed with a supersized 2-inch voice coil and features the heaviest G12 magnet.
The result is a guitar speaker that sounds 100% Celestion in character yet is primed to withstand a pummelling from a 100-watt head all by itself and still come back for more.
The Redback proves that you no longer need to choose between power and tone.
With a tight well-controlled low end detailed midrange and more relaxed treble Celestion’s engineering expertise has produced a truly high power
guitar speaker that can still deliver balance responsiveness and superb playability with muscular ease.
With lower power combos expect tons of smooth clean tone and don’t be afraid to plug in your favourite stomp box.
Thinking of downsizing your cabinet? Simply hook up a single Redback to your 100-watt head and generate giant slabs of frightening monstrous tone.

Specifications

• Nominal diameter 305mm / 12in
• Power rating 150W
• Rated impedance 8Ω or 16Ω
• Sensitivity 100dB
• Chassis type Pressed steel
• Magnet type Ceramic
• Magnet weight 1.42kg / 50oz
• Voice coil diameter 2in / 50mm
• Voice coil material Round copper
• Frequency range 70-5000Hz
• Resonance frequency, Fs 75Hz
• DC resistance, Re 6.45Ω & 12.54Ω

Mounting Information

• Cut-out diameter 283mm / 11.1in
• Diameter 309mm / 12.2in
• Magnet structure diameter 168mm / 6.6in
• Mounting hole dimensions 7.9mm / 0.31in Ø
• Mounting hole PCD 297mm / 11.7in
• Number of mounting holes 8
• Chassis depth (inc gasket) 95mm / 3.71in
• Magnet depth 43mm / 1.69”in
• Overall depth 138mm / 5.4in
• Unit weight 4.7kg / 10.4lb

Variable voltage control for voltages up to 600 V

Possible applications:
- G2 Control
- Power adjustment

Please see the >>TT VoCoM Projekt-Seite zu finden.

Der Bausatz beinhaltet alle Teile die zum Bau benötigt werden wie Widerstände, Dioden, Leistungstransistor, Kühlkörper, Potentiometer, Schraube, Mutter, Leitung, Beschriftungsschild.

ACHTUNG HOCHSPANNUNG:
Dieser Bausatz ist nichts für Anfänger. Wer nicht weis, was er damit tut, sollte diesen Bausatz auch nicht kaufen !

">>TT VoCoM project page for more infos

Kit includes:
all parts to build this VVC. Resistors, Heatsink, Wires, Potentiometer, PCB, Label, Screws, Nuts.

WARNING: HIGH VOLTAGE !!
This kit is not for beginners. If you do not know what you are doing than you should NOT buy this kit!

The Sovtek 12AX7WA is a defacto standard in 12AX7 tubes for many years yet because of its high dependability and its low noise floor.

• Pri: 0-120-230-240 V (black-yellow-purple-red)
• Sec 1: 200 V @ 0,085 A (red)
• Sec 2: 6,3 V @ 2 A (green)
• long leads ca 200 mm
• h=35mm d=70mm
• 50/60 Hz EN 61558

Carbon Composition Resistors

• Specification: ½ Watt, axial
• Temperature Range: -55°C to +125°C
• Tolerance: 10%
• Max. Operating Voltage: 350 V
• Size: l=9.5 mm, d=3.6 mm

• Audio: 8W
• Max. DC: 60 mA
• Pri. Inductance: 5,60 H

• Type: Electrolytic can capacitor
• Capacitance: 1000 µF
• Voltage Rating: 25 V
• Tolerance: - 20 % / +20 %
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 10 mm x 19 mm
• Termination Style: radial
• Grid: 5

Images are for reference only. See Product Specifications

Tube-Shield for Belton socket VT9-ST-C

• Color: silver
• Length: 50 mm
• Including Base and Shield

• Pri: 0-220-230-240 V (blue-black-orange-yellow)
• Sec 1:  250 V / 0,1 A (red)
• Sec 2: 6,3 V / 1,5 A (blue)
• Sec 3: 12,6 V / 1 A (green)
• Size: d = 80 mm, h = 35 mm
• ta 40 EN 61558

Sweet and warm sounding preamp tube with high gain. We recommend this tube for guitar/bass amps.

Files:

• Datasheet

TT Selection: Balanced
Both systems with balanced gain

Tube-Town E83CC Preamp-Tube

High-quality 12AX7 / ECC83 / 7025 preamp tube with low background noise and reduced feedback tendency due to short anode plates, as well as a powerful bass and a dense sound. Very suitable for input stages with high amplification or amplifiers with generally high gain.
Dropin replacement for all 12AX7, ECC83, 7025, and E83CC tubes.

Electrical Characteristics

• Heater voltage (Uf): 6.3V or 12.6V
• Heater current (If): 300mA at 6.3V, 150mA at 12.6V
• Anode voltage (Ua): Maximum 300V
• Grid voltages (Ug1): -2V (typical)
• Grid voltages: -50V to 0V
• Anode current (Ia): 1.2mA (typical)
• Anode power dissipation: Maximum 1W per triode
• Anode resistance (ra): 62.5kΩ
• Amplification factor (μ): 100
• Transconductance (S): 1.6mA/V
• Input capacitance (Cin): 1.6pF
• Output capacitance (Cout): 1.6pF

Mechanical Characteristics

• Socket: B9A (Noval)
• Number of pins: 9

Pin Configuration

• 1 Anode (Triode 1)
• 2 Grid (Triode 1)
• 3 Cathode (Triode 1)
• 4 Heater (f)
• 5 Heater (f)
• 6 Anode (Triode 2)
• 7 Grid (Triode 2)
• 8 Cathode (Triode 2)
• 9 Center Heater (f)

Application Notes

• Heater operation: The tube can be operated with 6.3V or 12.6V, depending on the circuit design.
• Grid resistors: It is recommended to use grid resistors of at least 1MΩ to ensure stable functionality.
• Coupling capacitors: Capacitors with low capacitance (typically 0.1µF) are recommended to minimize high-frequency interference.
