Fender Jack, 4 pin Mono #0990912000

JJ 6L6 - #19 - Mesa GREEN - GRAY

• Corresponds to Mesa Color Code GREEN - GRAY
• Price for one tube.
• Very Strong !

FAQ: If I order two or more of these tubes, are they all "matched"?
Yes, the tubes are all "matched" and selected for the above amplifiers.

FAQ: Can I change the tubes myself or does anything need to be adjusted?
Adjustment work is not possible on the above amplifiers (unless a bias adjustment has been retrofitted). The exchange can therefore be done without any adjustment or measurement work.

Files:

• Datasheet

• Type: Electrolytic capacitor
• Capacitance: 47 µF
• Voltage Rating: 100 V
• Tolerance: - 20 % / +20 %
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 8 mm x 18 mm
• Termination Style: axial

Images are for reference only. See Product Specifications

• Type: Electrolytic capacitor
• Capacitance: 4,7 µF
• Voltage Rating: 63 V
• Tolerance: - 10 % / +30 %
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 4,5 mm x 11 mm
• Termination Style: axial

Images are for reference only. See Product Specifications

• Type: Aluminum Electrolytic Capacitors
• Capacitance: 15 µF
• Voltage Rating: 500 V
• Tolerance: +/- 20%
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 16 mm x 30 mm
• Termination Style: axial

2 tubes, matched as pair

Standard EL34 made by JJ with a smooth and dizzy sound.

Limiting Values:

• Ua0: 2000 V
• Ua: 800 V
• Wa(max): 25 W
• Ug20: 800 V
• Ug2: 450 V
• Wg2(max): 8 W
• Ik: 150 mA
• Uk/f: 100 V
• Rk/f: 20 kΩ

Files:

• Datasheet

FULL - WAVE VACUUM RECTIFIER
5U4GB is a directly heated full wave octal base rectifier for Hi-Fi and guitar amplifiers. Suitable for use in any 5U4 socket.

Files:

• Datasheet



JJ's version of the ECC81/12AT7 tube type with a warm and soft sound. Often used for phase inverters or reverb drivers.

Files:

• Datasheet

2 tubes, matched as pair

Rugged and wonderful-sounding Power Beam tetrode that performs flawlessly at up to 475 volts. Great replacement for single-ended amps such as Fender Champ, or high plate voltage amps like the Fender Deluxe Reverb.

• Specially developed cathode coating
• Tri-alloy plate material
• Carefully aligned grid

Sweet and warm sounding preamp tube with high gain. We recommend this tube for guitar/bass amps.

Files:

• Datasheet

• Type: Electrolytic capacitor
• Capacitance: 22 µF
• Voltage Rating: 35 V
• Tolerance: - 10 % / +30 %
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 5 mm x 11 mm
• Termination Style: axial
• Color and manufacturer may differ from the picture shown

Images are for reference only. See Product Specifications

JJ EL84 #08 - Medium

• recommended for TT 18W, TT Spitfire and AC30
• Price for one tube.

FAQ: If I order two or more of these tubes, are they all "the same"?
Yes, the tubes are all "matched" and selected for the in the description mentioned amplifiers.
FAQ: Can I replace the tubes myself or are adjustments needed?
Adjustments are not possible on the listed amplifier (unless a bias potentiometer has been added afterwards). The replacement can therefore be done without adjustments.

4 tubes, matched as quad

Standard EL34 made by JJ with a smooth and dizzy sound.

Limiting Values:

• Ua0: 2000 V
• Ua: 800 V
• Wa(max): 25 W
• Ug20: 800 V
• Ug2: 450 V
• Wg2(max): 8 W
• Ik: 150 mA
• Uk/f: 100 V
• Rk/f: 20 kΩ

Files:

• Datasheet

• Type: Electrolytic can capacitor
• Capacitance: 10 µF
• Voltage Rating: 350 V
• Tolerance: - 20 % / +20 %
• Operating Temperature Range: - 40°C / + 105 °C
• Dimensions: Ø 10 mm x 15 mm
• Termination Style: radial
• Grid: 5,0

Images are for reference only. See Product Specifications

4 tubes, matched as quad

Premium high-voltage power pentode, featuring improved materials and workmanship over the original EL34B. Higher impedance design with increased touch responsiveness.

Files:

• Datasheet
