Lock Washer M4, 100 pcs

• Type: LIH/125 Stranded wire - halogen free
• Conductor: stranded copper - tinned
• Conductor strands: 16 x 0.2 mm
• Insulation: TPE-S (12Y), flammable
• Cross sectional area: 0,5 mm²
• Outer Ø: 1.6 mm
• Temperature Range
• static / dynamic: -40 to +125°C / -25 to +125°C
• Operating voltage: 900V
• Insulation resistance: min. 200MΩ x km at +20°C

Solder wire lead-free, ø 1.0 mm, 17 g
Composition: 0.3% silver, 0.7% copper, 99% tin, flux content: 2.5%, melting point 217 °C
Suitable for soldering work on electrical components and devices such as printed circuit boards, PCBs, SMDs, DIP components, cables, televisions, headphones or microphones. The integrated flux ensures particularly convenient and effective soldering.

• Flux-cored solder wire with a diameter of 1 mm, ideal for electronics soldering
• Easy, homogeneous wetting of the solder joint thanks to the rosin flux core
• No-clean solution with continuous flux cores, eliminating the need to clean the solder joint after use
• Reduced spattering behavior for increased user safety and protection of the workpiece
• Halogen-free and with low smoke emission
• Perfect for soft soldering at low temperatures in both machine and hand soldering applications

Technical Data

• Composition: 0.3% silver, 0.7% copper, 99% tin
• Flux content: 2.5%
• Melting point: 217 °C
• Diameter: 1 mm
• Weight: 17 g

Drill Ø: 12 mm
Rated voltage: 250 VAC
Rated current: 10 A (VDE), 16 A (UL/CSA)

• Type: LIH/125 Stranded wire - halogen free
• Conductor: stranded copper - tinned
• Conductor strands: 16 x 0.2 mm
• Insulation: TPE-S (12Y), flammable
• Cross sectional area: 0,5 mm²
• Outer Ø: 1.6 mm
• Temperature Range
• static / dynamic: -40 to +125°C / -25 to +125°C
• Operating voltage: 900V
• Insulation resistance: min. 200MΩ x km at +20°C

• Type: LIH/125 Stranded wire - halogen free
• Conductor: stranded copper - tinned
• Conductor strands: 16 x 0.2 mm
• Insulation: TPE-S (12Y), flammable
• Cross sectional area: 0,5 mm²
• Outer Ø: 1.6 mm
• Temperature Range
• static / dynamic: -40 to +125°C / -25 to +125°C
• Operating voltage: 900V
• Insulation resistance: min. 200MΩ x km at +20°C

Vishay ORANGE DROP® 225P

• Type:  Polyester Film Capacitors
• Voltage Rating: 100 V
• Tolerance: - 10 % / +10 %
• Operating Temperature Range: - 55°C / + 85 °C
• Termination Style: radial

Vishay ORANGE DROP® 225P

• Type:  Polyester Film Capacitors
• Voltage Rating: 400 V
• Tolerance: - 10 % / +10 %
• Operating Temperature Range: - 55°C / + 85 °C
• Termination Style: radial

TT Selection: V1 - Low Noise
This tube is selected for sensitive input stages (V1)

Sweet and warm sounding preamp tube with high gain. We recommend this tube for guitar/bass amps.

Files:

• Datasheet

TT Selection: Balanced
Both systems with balanced gain

Sweet and warm sounding preamp tube with high gain. We recommend this tube for guitar/bass amps.

Files:

• Datasheet
