TT-CK03 Choke 3 H

• Type: Multisection Capacitor
• Capacitance: 32 + 32 µF
• Voltage Rating: 500 V
• Tolerance: - 10% / +30 %
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 35 mm x 50 mm
• Termination Style: radial, solder lugs

• Resistance: 50k Ohm
• Power: 0,25 W
• Max Voltage: 250 V
• Grid 12,5/10 mm
• Ø: 15,0 mm
• h: 7,0 mm

• Type: Tubular Metalized Polyester Film Capacitors
• Voltage Rating: 630 V
• Tolerance: +/- 10%
• Operating Temperature Range: - 40°C / + 85 °C
• Termination Style: axial
• • Non-inductive
  • Self healing windings.
  • Similar to the Mallorys 150-Series

• Type: Tubular Metalized Polyester Film Capacitors
• Voltage Rating: 630 V
• Tolerance: +/- 10%
• Operating Temperature Range: - 40°C / + 85 °C
• Termination Style: axial
• • Non-inductive
  • Self healing windings.
  • Similar to the Mallorys 150-Series

Drill Ø: 12 mm
Rated voltage: 250 VAC
Rated current: 10 A (VDE), 16 A (UL/CSA)

• Pri: 0 - 220 - 230 - 240 V (schwarz-gelb-lila-rot / black-yellow-purple-red)
• Sec 1: 350 V @ 0,4 A (rot-grün/red-green)
• Sec 2: 350 V @ 0,4 A (weiß-blau/white-blue)
• Sec 3: 50 V @ 0,1 A (schwarz-schwarz/black-black)
• Sec 4: 50 V @ 0,1 A (braun-braun/brown-brown)
• Sec 5: 6,3 V @ 4,0 A (orange-orange)
• Sec 6: 6,3 V @ 4,0 A (lila-lila/purple-purple)
•
• freie Enden / long leads ca. 200 mm
• 140 x 60  mm
•
• 50/60 Hz / EN 61558

• Tube-Town universal basic pcb for stomp-boxes
• Size: 77,5 x 54 mm
• Material: 1,6 mm FR3, blue
