Speaker Break-In Service

Speaker Break-In / Agin Service for Guitar Speakers.
Corresponds to a continuous operation of 24 hours.
Many new and unused loudspeakers sound harsh and must be used for a certain time to develop their sound. This ageing process can be accelerates with this service which "wears" different parts of the speaker, so it will sound softer and smoother, in particular the top end.

TTC - what you should know

All TTC Speaker Cabinets, Combos and Headcabs are "Made in Germany"
The shipping weight may differ from the actual weight of the product.
All TTC Speaker Cabinets, Heads and Combos are made with real wood, no MDF or chipboard.
All TTC Speaker Cabinets, Heads and Combos are made with dovetail joints for a maximum of stability.
Due to continual improvement, all specifications are subject to change without notice.
Screws for speaker mounting are included
We mount speakers for free if they get ordered together with a cabinet and wire them if a wire-set gets ordered too. Exception: Lemberg standard boxes or boxes which are then too large and / or heavy for normal package transport. For these boxes we deliver the speakers and must be mounted by the customer.
For speaker cabs with custom-shop size please note the size in the comment field (during the checkout) or send them by email. Consider the min and max dimensions !

Manufacturer

Herstellerinformationen | Manufacturer Information
Tube-Town GmbH
Rumbergring 37
66969 Lemberg
Germany
www.tt-cabs.com

Customer reviews

Essential information about customer reviews We do not verify that the published reviews come from such consumers who have actually used or purchased the rated goods or services. All reviews, i.e. positive and negative, are published. No reviews that are unobjective, offensive or unrelated to the product will be published.

Unfortunately there are no review yet. Be the first who rate this product.

Needed for:

WGS G12 C/S 12" / 75 W / 8 Ohm

If you are looking for a speaker with a classic American vibe, but need a smoother more soulful top end, look no further than the WGS G12C/S. This is based on our popular G12C, but with a smooth cone, felt dust cap and just the right amount of edge treatment. This speaker works great in amps where you are going for that big American clean but just need it a little softer up top. Destined to be another WGS classic!

Thiele-Small Parameters

Resonant Frequency (Fs): 95.68 Hz
DC Resistance (Re): 7.47 Ohm
Coil Inductance (Le): 0.28 mH
Mechanical Q (Qms): 14.56
Electromagnetic Q (Qes): 0.73
Total Q (Qts): 0.69
Compliance Equiv. Vol. (Vas): 19.70 cu ft
Mech. Compliance of Susp. (Cms): 0.10 mm/N
BL Product (BL): 12.83 T-M
Diaphragm Mass Inc. Airload (Mms): 26.70 grams
Surface Area of Cone (Sd): 366.10 cm squared
Sound Pressure Level (spl): 99.54 db

119,00 €

Celestion Gold 12" / 50 W / 16 Ohm - MADE IN UK

Building on the platform of the Blue the Gold is a higher-powered Alnico-magnet guitar speaker that recreates the unmistakable sonic signature of a ‘well played-in’ original.
Over time the high frequencies of a Blue soften and become less chalky as the cone becomes more flexible – a much sought after characteristic that the Gold exhibits straight out of the box.

Also present in the Gold sound from the outset is an added warmth and complexity in the midrange which coupled with the classic Alnico qualities of a laid-back attack rounded low end and brilliant bell-like highs deliver huge rhythm voicings and saturated vocal lead tones.
The Gold is a wonderfully expressive and revealing loudspeaker affording guitarists an unprecedented degree of dynamic control.

Specifications

Nominal diameter 305mm / 12in
Power rating 50W
Rated impedance 8Ω or 15Ω
Sensitivity 100dB
Chassis type Pressed steel
Magnet type Alnico
Voice coil diameter 1.75in / 44.5mm
Voice coil material Round copper
Frequency range 75-5000Hz
Resonance frequency, Fs 75Hz
DC resistance, Re 6.4Ω or 11.8Ω

Mounting Information

Cut-out diameter 283mm / 11.1in
Diameter 309mm / 12.2in
Magnet structure diameter 128mm / 5.0in
Mounting hole dimensions 7.9mm / 0.31in Ø
Mounting hole PCD 297mm / 11.7in
Number of mounting holes 4
Chassis depth (inc gasket) 92mm / 3.63in
Magnet depth 73mm / 2.87in
Overall depth 165mm / 6.5in
Unit weight 4.2kg / 9.3lb

279,00 €

Celestion G12H-150 Redback - 12" / 150 W / 8 Ohm - MADE IN UK

The G12H-150 Redback has been created for players who are looking for extreme power handling but refuse to compromise on great tone.
Rated at a gargantuan 150-watts the Redback is constructed with a supersized 2-inch voice coil and features the heaviest G12 magnet.
The result is a guitar speaker that sounds 100% Celestion in character yet is primed to withstand a pummelling from a 100-watt head all by itself and still come back for more.
The Redback proves that you no longer need to choose between power and tone.
With a tight well-controlled low end detailed midrange and more relaxed treble Celestion’s engineering expertise has produced a truly high power
guitar speaker that can still deliver balance responsiveness and superb playability with muscular ease.
With lower power combos expect tons of smooth clean tone and don’t be afraid to plug in your favourite stomp box.
Thinking of downsizing your cabinet? Simply hook up a single Redback to your 100-watt head and generate giant slabs of frightening monstrous tone.

Specifications

Nominal diameter 305mm / 12in
Power rating 150W
Rated impedance 8Ω or 16Ω
Sensitivity 100dB
Chassis type Pressed steel
Magnet type Ceramic
Magnet weight 1.42kg / 50oz
Voice coil diameter 2in / 50mm
Voice coil material Round copper
Frequency range 70-5000Hz
Resonance frequency, Fs 75Hz
DC resistance, Re 6.45Ω & 12.54Ω

Mounting Information

Cut-out diameter 283mm / 11.1in
Diameter 309mm / 12.2in
Magnet structure diameter 168mm / 6.6in
Mounting hole dimensions 7.9mm / 0.31in Ø
Mounting hole PCD 297mm / 11.7in
Number of mounting holes 8
Chassis depth (inc gasket) 95mm / 3.71in
Magnet depth 43mm / 1.69”in
Overall depth 138mm / 5.4in
Unit weight 4.7kg / 10.4lb

149,00 €

Tonespeak Belfast 820 8" / 20 W / 4 Ohm

The Belfast 820 provides players and listeners with a well-tailored and satisfyingly clear response. This model gives your tone a defined contour⁠—open and present lows, soft mids, and glassy/articulate highs—that will make your lead and solo lines soar.

Upgrade your 8" guitar speaker cabinet with this high-sensitivity driver, combining a powerful ferrite magnet motor, a 1" copper voice coil, a paper composite cone, a pair of dual terminals for easy connectivity and installation, with a sturdy steel basket to hold it all in place.

British tone guitar speaker

8" (203 mm) steel basket diameter
20 watts, 4 ohm, 97 dB SPL
1" copper voice coil, Kraft paper former
10 oz ferrite magnet
Paper composite cone
Size, Nominal (inch & mm): 8" (203 mm)
RoHS Compliant: Yes
Nominal Impedance (Z) (Ω): 4
Rated Power IEC268-5 (W): 20 Watts
Rated Impedance (Ω): 4
Continuous Power (W): 20
Program Power (W): 40
Frequency Range (Hz): 88 - 11,000
Sensitivity (dB SPL) ¹: 97
Resonant Frequency (Fs) (Hz): 155
DC Resistance (Re) (Ω): 3.4
Voice Coil Inductance (Le) (mH): 0.12
Mechanical Q Factor (Qms): 15.49
Electrical Q Factor (Qes): 1.77
Total Q Factor (Qts): 1.59
Mechanical Resistance (Rms) (kg/s): 0.58
Compliance Equivalent Volume (Vas) (L): 8.31
Suspension Compliance (Cms) (mm/N): 0.11
Surface Area of Diaphragm (Sd) (cm²): 226.98
Moving Mass (Mms) (gm): 9.22
Magnetic Gap Height (mm): 6.0
Coil Winding Height (mm): 6.35
Motor Force Factor (BL) (T•M): 4.17
Efficiency (η₀) (%): 1.69
Efficiency Bandwidth Product (EBP) (Fs/Qes): 87.88
Basket Type: Stamped steel with black powder coating
Terminal Size (mm): 5.2 x 0.5
Voice Coil Diameter (mm): 25.4
Voice Coil Wire Material: copper
Voice Coil Former Material: Kraft paper
Voice Coil Winding Style: Single Layer
Magnet Material: Ferrite
Magnet Weight (g): 283.5
Cone Body Material: Paper composite
Dust Cap Material: Paper
Spider Material: Cotton
Net Weight (kg): 1.02

Old price: 49,00 €
Only 39,00 €

Offer valid until: 21.10.2025"

Celestion Classic Lead 80 - 12" / 80 W / 8 Ohm - MADE IN UK

Developed in the late '70s, the Classic Lead uses a fibreglass voice coil former to deliver an 80W power rating and a unique dynamic sound.

A firm favourite with lead guitarists, the Classic Lead features a tightly controlled low-end, with strong high bass / low mid punch, aggressive mid range attack and a powerful yet controlled top-end.

For power chords it has the tone to make its presence felt but the subtle high-frequency roll- off makes it ideal for solos, able to project single notes on loud stages without becoming shrill.

General Specifications

Nominal diameter: 12", 305mm
Power rating: 80Wrms
Nominal impedance: Available 8Ω or 16Ω
Sensitivity: 99dB
Chassis type: Pressed steel
Voice coil diameter: 1.75", 55.5mm
Voice coil material: Round copper
Magnet type: Ceramic
Magnet weight: 50oz, 1.42kg
Frequency range: 80-5000Hz
Resonance frequency, Fs: 85Hz
DC resistance, Re: Available 6.9Ω or 11.8Ω

Mounting Information

Cut-out diameter: 11.1", 283mm
Diameter: 12.2", 309mm
Magnet structure diameter: 6.1", 156mm
Mounting slot dimensions: 0.31", 7.9mm Ø
Mounting slot PCD: 11.7", 297mm
Number of mounting slots: 4
Overall depth: 5.3", 135mm
Unit weight: 10.4lb, 4.7kg

139,00 €

Jensen P12Q - 12" / 40 W / 4 Ohm

The "Living legends" of Rock and Roll guitar sounds are back! Original designs of the late 40's and early 50's have been recreated using many of the original parts suppliers. Highly efficient AlNiCo magnets and seamed paper cones are the foundation for the famous JENSEN® Sound. JENSEN® "P" Series Vintage AlNiCo magnet speakers represent an important contribution to the paste, present and, no doubt, the future of rock and roll music. They are loved by generations of guitarists around the world.

Technical Details:

Size: 12"
Impedance: 4 Ohm
Rated Power (RMS): 40 W
Sensitivity @ 1 W, 1 m: 95 dB
Resonance Frequency fs: 90,4 Hz
Bell: No Bell

Files:

Datasheet

149,00 €

Jensen C6V / 20W / 8 Ohm

CERAMIC Vintage

The JENSEN® "C" series speakers were developed because the world's supply of cobal (Co in AlNiCo) slump, making this raw material more expensive. While ceramic magnets are larger in size than comparable AlNiCo magnets of the same gauss strenght, their cost is lower. "C" series JENSEN® speakers use same cones and voice coils comparable to our AlNiCo series speakers, thus providing a similar tone but at a reduced price.

Technical Details:

Size: 6"
Impedance: 8 Ohm
Rated Power (RMS): 20 W
Sensitivity @ 1 W, 1 m: 91,3 dB
Resonance Frequency fs: 106 Hz

39,00 €

Jupiter M10C Midnight 10" / 50 W / 8 Ohm

The M10C has a slightly smoother sound that retains headroom. Similar to the 10LC but with less output but a more balanced sound with more presence and sparkle on the top end.
Initially intended for studio or home use, musicians claim it to be the closest to the original C10N from 4 and 5 decades ago.
The standard voice coil gives a more 3D presence when compared to a paper voice coil.

Specs:

Power Handling: 50W
Sensitivity: 97 dB
Voice Coil Diameter: 1.5"
Magnet: Ceramic - 35oz
Weight: 7lbs / 3,17 kg

Dimensions:

Diameter: 10 3/16" / 258 mm
Depth rear mount: 4 1/4:
Cut-out hole diameter: 9"
Mounting Holes: 1/4"
Number of mounting holes: 8
Mounting Hole Circle Diameter: 9 3/4"

129,00 €

Celestion Bass PULSE 12 12" / 200 W / 8 Ohm

PULSE12
For bass players demanding well-defined clarity and stunning articulationtogether with a rich, full tone, PULSE12 bass speakers deliver an idealcombination of responsiveness and rock solid low end. The Kevlar-loaded conepulses with up to 200 watts of raw bass power. Expect each note to deliver athick, percussive attack along with the mid-range necessary to break through inany performance situation.

General Specifications

Nominal diameter: 12", 304.8mm
Power rating: 200W
Nominal impedance: 8 Ohm
Sensitivity: 94dB
Magnet type: Ferrite
Voice coil diameter: 2", 50.8mm
Coil material: Copper
Cone material: Kevlar loaded paper
Former material: Polyimide
Surround material: Cloth-sealed
Frequency range: 45-3500Hz
Xmax: 0.15", 4mm
Gap depth: 0.31", 8mm
Voice coil winding width: 0.62", 16mm

Small Signal Parameters

D: 0.26m/10.2in
Fs: 45Hz
Mms: 47.6g/1.68oz
Qms: 2.74
Qes: 0.49
Mmd: 40.7g/1.44oz
Qts: 0.42
Re: 5.88O
Vas: 104.6lt/3.7cu.ft.
BI: 12.71Tm
Cms: 0.26mm/N
Rms: 4.92kg/s
Le (at 1kHz): 1.0mH

Mounting Information

Cut-out diameter: 11.1", 283mm
Diameter: 12.2", 309mm
Mounting slot dimensions: 0.31", 7.9mm Ø
Mounting slot PCD: 11.7", 297mm
Number of mounting slots: 4
Overall depth: 5.1", 130mm
Unit weight: 7lb, 3.2kg

109,00 €

WGS G12Q 12" / 20 W / 8 Ohm

Building on the popularity of our G12C, we developed the G12Q for those times when you want the speaker to add some natural, vintage breakup but maintain clarity. With a 20 oz magnet and a 1" voicecoil, the G12Q definitely has a vintage American flavor. We highly recommend it with 5E3 style circuits.

Thiele-Small Parameters

Resonant Frequency (Fs):91.91 Hz
DC Resistance (Re): 7.70 Ohm
Coil Inductance (Le): 0.26 mH
Mechanical Q (Qms): 20.75
Electromagnetic Q (Qes): 2.64
Total Q (Qts): 2.35
Compliance Equiv. Vol. (Vas): 22.17 cu ft
Mech. Compliance of Susp. (Cms): 0.12 mm/N
BL Product (BL): 6.57 T-M
Diaphragm Mass Inc. Airload (Mms): 25.71 grams
Surface Area of Cone (Sd): 366.10 cm squared
Sound Pressure Level (spl): 95.92 db

89,00 €

Jupiter M12C-P Midnight 12" / 25 W / 8 Ohm - Paper Coil

12" seamed ribbed cone with a large ceramic magnet, the replacement for C12N.
Similar to the 12LC but with less output and a smoother yet balanced sound that retains headroom. Some nice compression is evident compared to the 12LC but not at the expense of headroom. Originally intended for studio or home use, many musicians claim it to be the closest to the original C12N from 4 and 5 decades ago.

Specs:

Power Handling: 50W
Sensitivity: 97 dB
Voice Coil Diameter: 1.5"
Magnet: Ceramic - 35oz
Weight: 9lbs / 4,1 Kg
Paper Coil

Dimensions:

Diameter: 12 1/4" / 311 mm
Depth rear mount: 5 1/16"
Cut-out hole diameter". 11"
Mounting Holes: 1/4"
Number of mounting holes: 8
Mounting Hole Circle Diameter: 11 3/4"

140,00 €

Jensen P12R - 12" / 25 W / 4 Ohms

Technical Details:

Size: 12"
Impedance: 4 Ohm
Rated Power (RMS): 25 W
Sensitivity @ 1 W, 1 m: 95 dB
Resonance Frequency fs: 80 Hz
Bell: No Bell

Files:

Datasheet

109,00 €

Celestion G12H(55) Heritage 55 Hz, 12" / 30 W / 8 Ohm - MADE IN UK

It's hard to escape the sound of the G12H, just listen to any Hendrix recording and chances are you'll be hearing a whole raft of them powering the guitar out of the mix.

These faithful re-creations capture the unmistakeable mojo of late 60s rock guitar tones. Unsurpassed in a 4x12 for cranking out towering, huge power chords, the Heritage Series G12H (55) features the 55c/s 'bass' cone. This model is famous for its thick syrupy tones, with a deep growling back end, densely complex mid-range and a finely detailed top end.

General Specifications

Nominal diameter: 12", 305mm
Power rating: 30Wrms
Nominal impedance: Available 8Ω or 15Ω
Sensitivity: 100dB
Chassis type: Pressed steel
Voice coil diameter: 1.75", 44.5mm
Magnet type: Ceramic
Magnet weight:50oz, 1.42kg
Frequency range: 55-5000Hz
Resonance frequency, Fs: 55Hz
DC resistance, Re: 6.53Ω and 12.11Ω

Mounting Information

Cut-out diameter: 11.1", 283mm
Diameter: 12.2", 309mm
Magnet structure diameter: 6.6", 168mm
Mounting slot PCD: 11.7", 297mm
Number of mounting slots: 4
Overall depth: 5.3", 135mm
Unit weight: 10.4lb, 4.7kg

169,00 €

Tonespeak Austin 1250 12" / 50 W / 8 Ohm

Balance, punch, fullness, and clarity are at the forefront of this speaker. The mids are tailored and even, enabling the articulation, openness, air, and a nice glassiness to shine through in the highs. The tight, solid, and responsive lows round out the tone and perfectly balance the detail in the highs. A very musical speaker optimized for the ever so popular Deluxe Reverb, but suitable anywhere you want pure American tone.

Spzification:

Nominal Impedance(Z): 8 Ohm
Rated Power IEC268-5: 50 Watt
Sensitivity (@1W/1 m): 100 dB/SPL
Frequency range: 80 – 5000 Hz
Resonant Frequency (Fs): 90 Hz
Voice Coil Diameter: 1,75"

Files:

Datasheet

Old price: 129,00 €
Only 108,00 €

Offer valid until: 21.10.2025"

WGS G15C 15" / 75 W / 16 Ohm

We have created a truly awesome 15" speaker with the G15! Now you can play a 15" with quick, articulate response, aggressive mid-range, & fat low end.

Thiele-Small Parameters

Resonant Frequency (Fs): 100.45 Hz
DC Resistance (Re): 6.4 Ohm
Coil Inductance (Le): 8 mH
Mechanical Q (Qms): 12.3144
Electromagnetic Q (Qes): 1.188
Total Q (Qts): 1.0835
Compliance Equiv. Vol. (Vas): 2.165 cu ft
Mech. Compliance of Susp. (Cms): 50.169 mm/N
BL Product (BL): 11.64 T-M
Diaphragm Mass Inc. Airload (Mms): 50.0389 grams
Surface Area of Cone (Sd): 923.4744 cm squared
Sound Pressure Level (spl): 99.03 db

129,00 €

WGS Veteran 10 10" / 20 W / 4 Ohm

The 10” Veteran™ speaker from WGS™ has great crunchy cone breakup and clean, warm overtones. The seamed paper cone is key to this guitar speaker's sound.

Thielle-Small Parameters

Resonant Frequency (Fs): 110.86 Hz
DC Resistance (Re): 6.9 Ohm
Coil Inductance (Le): 8 mH
Mechanical Q (Qms): 17.2304
Electromagnetic Q (Qes): 1.9694
Total Q (Qts): 1.7674
Compliance Equiv. Vol. (Vas): 0.808 cu ft
Mech. Compliance of Susp. (Cms): 119.122 mm/N
BL Product (BL): 6.15 T-M
Diaphragm Mass Inc. Airload (Mms): 17.3021 grams
Surface Area of Cone (Sd): 366.0962 cm squared
Sound Pressure Level (spl): 93.84 db

75,00 €

Celestion G12H-150 Redback - 12" / 80 W / 16 Ohm - MADE IN UK

Nominal diameter 305mm / 12in
Power rating 150W
Rated impedance 8Ω or 16Ω
Sensitivity 100dB
Chassis type Pressed steel
Magnet type Ceramic
Magnet weight 1.42kg / 50oz
Voice coil diameter 2in / 50mm
Voice coil material Round copper
Frequency range 70-5000Hz
Resonance frequency, Fs 75Hz
DC resistance, Re 6.45Ω & 12.54Ω

Mounting Information

Cut-out diameter 283mm / 11.1in
Diameter 309mm / 12.2in
Magnet structure diameter 168mm / 6.6in
Mounting hole dimensions 7.9mm / 0.31in Ø
Mounting hole PCD 297mm / 11.7in
Number of mounting holes 8
Chassis depth (inc gasket) 95mm / 3.71in
Magnet depth 43mm / 1.69”in
Overall depth 138mm / 5.4in
Unit weight 4.7kg / 10.4lb

159,00 €

Celestion G12H(55) Heritage 55 Hz, 12" / 30 W / 16 Ohm - MADE IN UK - B-Stock

B-goods item with slight signs of use, but technically 100% OK.

It's hard to escape the sound of the G12H, just listen to any Hendrix recording and chances are you'll be hearing a whole raft of them powering the guitar out of the mix.

These faithful re-creations capture the unmistakeable mojo of late 60s rock guitar tones. Unsurpassed in a 4x12 for cranking out towering, huge power chords, the Heritage Series G12H (55) features the 55c/s 'bass' cone. This model is famous for its thick syrupy tones, with a deep growling back end, densely complex mid-range and a finely detailed top end.

General Specifications

Nominal diameter: 12", 305mm
Power rating: 30Wrms
Nominal impedance: Available 8Ω or 15Ω
Sensitivity: 100dB
Chassis type: Pressed steel
Voice coil diameter: 1.75", 44.5mm
Magnet type: Ceramic
Magnet weight:50oz, 1.42kg
Frequency range: 55-5000Hz
Resonance frequency, Fs: 55Hz
DC resistance, Re: 6.53Ω and 12.11Ω

Mounting Information

Cut-out diameter: 11.1", 283mm
Diameter: 12.2", 309mm
Magnet structure diameter: 6.6", 168mm
Mounting slot PCD: 11.7", 297mm
Number of mounting slots: 4
Overall depth: 5.3", 135mm
Unit weight: 10.4lb, 4.7kg

Old price: 169,00 €
Only 143,65 €

Offer valid until: 29.10.2025"

Jupiter M12C Midnight 12" / 50 W / 8 Ohm

Power Handling: 50W
Sensitivity: 97 dB
Voice Coil Diameter: 1.5"
Magnet: Ceramic - 35oz
Weight: 9lbs / 4,1 Kg

Dimensions:

Diameter: 12 1/4" / 311 mm
Depth rear mount: 5 1/16"
Cut-out hole diameter". 11"
Mounting Holes: 1/4"
Number of mounting holes: 8
Mounting Hole Circle Diameter: 11 3/4"

140,00 €

Celestion Ten 30 - 10" / 30 W / 8 Ohm

Ten 30

Rich and expressive, the Ten 30 combines warm lows with a vocal mid-range and an articulate top end. The clean sound is open and revealing; push hard and you're rewarded with full-blooded Celestion grind.

General specifications

Nominal diameter: 10", 254mm
Power rating: 30Wrms
Nominal impedance: 8 Ohm
Sensitivity: 95dB
Chassis type: Pressed steel
Voice coil diameter: 1.25", 31.25mm
Voice coil material: Round copper
Magnet type: Ceramic
Magnet weight: 13oz, 0.37kg
Frequency range: 85-5000Hz
Resonance frequency, Fs: 93.9Hz
DC resistance, Re: 6 Ohm

Mounting Information

Cut-out diameter: 9.0", 229mm
Diameter: 10.1", 256mm
Magnet structure diameter: 3.8", 96mm
Mounting slot dimensions: 0.24 x 35", 6 x 9mm
Mounting slot PCD: 9.6", 245mm
Number of mounting slots: 8
Overall depth: 3.8", 96mm
Unit weight: 3.5lb, 1.6kg

49,00 €

Customers who bought this product bought also the following products:

SOMMER CABLE - SC-TRICONE MKII black - 10 Meter

The TRICONE® MKII is a flexible cable for guitar, keyboard, the live musician, studio keyboarder, and the home recorder. Based on the sound wire diameter of 0.22 mm² and the fine individual strands of 0.10 mm, it is protected against cable breaks and convinces with high bending cycles. It is very robust, easy to wind, and very reasonably priced.

When working with it care should be taken when removing the concutive shielding (black PVC-hose) from the insulation, so that it does not touch the inner conductor.

TRICONE® is a protected and registered trademark of SOMMER CABLE GmbH.

THE ADVANTAGES:

Very robust due to the large conductor diameter and fine individual stranding
Good electrical values due to the insulation made of skin PE
100 % Protected due to double shielding (copper spiral + conductive carbon shielding)
High number of bending cycles

THE APPLICATION:

Dependable cable for live application (guitar and keyboard)
Reasonable line or patch cable for the home recorder

TECHNICAL DATA:

Construction LI2Y(LS)DY1x0.22mm²
Jacket, diameter PVC 5,9 mm
AWG 24
No. of inner conductors 1 x 0,22 mm²
Copper strand per conductor 28 x 0,10 mm
Conductor insulation skin PE 1,8 mm
Shielding copper spiral shielding + semiconductor
Shielding factor 100 %
Temperature range min. -20 °C
Temperature range max. 70 °C
Fire load per m 0,26 kWh
Color: black
Weight per 1 m 42 g

ELECTRICAL DATA:

Capac. cond./shield. per 1 m < 85 pF
Cond. resistance per 1 km < 90 Ohm
Insulation resist. per 1 km > 1 GOhm

12,70 €
1,27 € per m

Sommer Cable SC-Spirit High-End, black - 10 Meter

Like a lasso... the guitar players throw the cables around.
That's why especially this cable has to have a very demanding and unique inner life.

Most musicians invest a lot of money in low cost cables, until they finally realise that the cables they just bought are barely good enough for shortwave radio reception or that it even ruins the entire sound image of a very expensive instrument. We have distanced ourselves from cheap products and offer a top quality cable at a fair price.
SC-SPIRIT has a thick insulation between wires and shiedling. This improves the capacitive values and ensures loss-free high rendition, even with longer cables. To avoid crackling and hum interference we use a special conductive carbon shield and copper braided shield. When soldering make sure that the carbon shield and the inner conductor do not touch.
Your audience will be surprised at the sound of this cable!

THE ADVANTAGES:

Enormously powerful and clear sound image for bass, guitar, and keyboard due to the special stranding and a wire diameter of 0.50 mm² or 0.75 mm²
Triple shielding due to the combination of double copper spiral shielding and conductive carbon shielding
Loss free transmission due to the low capacity
Very flexible and easy to wind due to the use of fine individual stranding
Durability and robustness due to a special high quality PVC-mixture for the jacket
Strain relief and good protection against bending due to the thick PVC-jacket

THE APPLICATION:

High quality guitar cable for studio and stage
Unbalanced cable for keyboards, samplers, mixing boards, etc.
Connection of stereo video recorder and DAT-recorder

TECHNICAL DATA:

Construction LI2Y(LS)CY1x0,50mm²
Jacket, diameter PVC 7,0 mm
AWG 21
Inner conductors 1 x 0,50 mm²
Copper strand per conductor 28 x 0,15 mm
Conductor insulation PE 2,4 mm
Shielding copper braiding tin-plated + semiconductor
Shielding factor 100 %
Temperature range min. -30 °C
Temperature range max. 70 °C
Fire load per m 0,26 kWh
Weight per 1 m 66 g
Color black

ELECTRICAL DATA:

Capac. cond./shield. per 1 m 78 pF
Cond. resistance per 1 km 38,2 Ohm
Insulation resist. per 1 km > 1 GOhm

22,90 €
2,29 € per m

WGS G8C 8" / 20 W / 8 Ohm

The G8C ceramic speaker will breathe new life into your small combo. This little monster puts out some serious sound. A serious upgrade for your Fender Champ.

Thiele-Small Parameters

Resonant Frequency (Fs): 148.07 Hz
DC Resistance (Re): 6.7 Ohm
Coil Inductance (Le): 8 mH
Mechanical Q (Qms): 9.6715
Electromagnetic Q (Qes): 0.9538
Total Q (Qts): 0.8682
Compliance Equiv. Vol. (Vas): 0.257 cu ft
Mech. Compliance of Susp. (Cms): 110.714 mm/N
BL Product (BL): T-M
Diaphragm Mass Inc. Airload (Mms): 10.4353 grams
Surface Area of Cone (Sd): 214.0839 cm squared
Sound Pressure Level (spl): 95.78 db

69,00 €
