Grillcloth Mesa Style Small Weave Cane Brown - 80 x 100 cm

Technical Data:

• Core M6
• Primary: 120V-230V-240V @ 50Hz
• Secondary HT: 345V-0-345V @ 300mA
• Secondary Heater: 3.15V-0-3.15V @ 6A
• Secondary Bias: 50V @ 150mA
• Secondary: Auxiliary 0V-6V-12V @ 1,5A

Files:

• Datasheet

• Mounting fittings: Steel, nickel plated
• Color: Light brown
• WITHOUT NUTS AND SCREWS

PVC piping for baffles and front panels

• Clear with metal Tinsel
• Marshall style
• Size 3 x 8 mm
• 4 m piece

• Reverb Driver 125A20B / 022921 Single-Ended
• Pri: 22800 Ohm
• Sec: 8 Ohm
• Power: 3,5 Watt

Files:

• Datasheet

SOMMER CABLE MERIDIAN MOBIL SP215 - 10 Meter

Were raw force reigns...

the sound technicians are at work and do not have the time to handle cables with tender love and care. This robust cable is especially intended for speakers and satifies all special technical demands. The oxygen-free copper strand provides better sound and more durability.
All PVC-versions are easy to wind. Versions SP215 and SP225 are now available with highly flexible 0.15 mm copper stranding!
New are the versions in FRNC and E30 (IEC 228, IEC 332-/1, IEC 332-3 Cat C, IEC 60331, IEC 61034-1/2, IEC 60754-2)

THE ADVANTAGES:

• Flexible and easily windable
• Small diameter
• Great durability through the use of a special jacket mixture
• Very affordable

THE APPLICATION:

• All types of sound systems
• For fixed installation
• Wiring of HiFi-systems

• Construction (2LIY1.50mm²)Y
• Diameter 6,8 mm
• AWG 16
• No. of conductors 2 x 1,5 mm²
• Jacket material, insulation PVC
• Copper strand per conductor 84 x 0,15 mm
• Conductor insulation, diameter 2,62 mm
• Temperature range min. -30 °C
• Temperature range max. 70 °C
• Fire load per m 0,28 kWh
• Weight per 1 m 78 g
• Color dark gray

• Capac. cond./cond. per 1 m 150 pF
• Cond. resistance per 1 km < 13 Ohm
• Insulat. resistance per 1 km > 5 MOhm

Width ca. 135 cm
Price per linear meter.
Actual shades may vary.
We ship the tolex as one piece if you order more than 1 meter.

Material:
80% PVC Film
20% Poly-Cotton Fibre

REACH compliant

Please note !
when you order more than 1 m and select Deutsche Post / DHL Parcel (Not DHL Express) we need to cut the width of the tolex to ca. 115 cm. Otherwise it is not possible to ship the tolex with DHL because the parcel length would exceed the maximum parcel length.

• Mounting fittings: Steel, nickel plated
• Color: Black
• WITHOUT NUTS AND SCREWS

• 8 x Cabinet corner w/ cutaway 2 leg, silver (pe-c1824k)
• High Quality
• Powder Coated black
• Internal radius: 12 mm
• 16 x Screws, flat head, black

Set of metal corners for housing consisting of:

• 8 x Cabinet corner w/ cutaway 2 leg, silver (pe-c1824n)
• Steel nickel plated
• High Quality
• 16 x Screws with extra flat head, silver
