Hammond Diecast 1590DDBK - black

• Insulation: Silicon
• Operation Voltage: 500 V
• Test Voltage: 2000 V
• Operating temperatures:    –50 bis +180 °C
• Packing:: 5 m
• Cross-Section: 0,5 mm²
• Outer Diameter: 2,1 mm
• Stranded wire structure: 16 x 0,20 mm, tinned copper

• Insulation: Silicon
• Operation Voltage: 300 V AC / 500 V DC
• Test Voltage: 2000 V
• Operating temperatures:    –40 bis +180 °C
• Packing: 5 m
• Cross-Section: 0,25 mm²
• Outer Diameter: 1.6 mm
• Stranded wire structure: tinned copper

Mixed sizes, length 10 cm / ea, black

• 30 x 1,5mm Ø
• 30 x 2,5mm Ø
• 20 x 4mm Ø
• 10 x 6mm Ø
• 6 x 10mm Ø
• 4 x 13mm Ø

• Length: 100 mm
• Width: 2,5 mm
• color: black
• Set of 100 pcs

• Insulation: Silicon
• Operation Voltage: 500 V
• Test Voltage: 2000 V
• Operating temperatures: –50 bis +180 °C
• Packing: 100 m
• Cross-Section: 0,5 mm²
• Outer Diameter: 2,1 mm
• Stranded wire structure: 16 x 0,20 mm, tinned copper

Active, serial FX-Loop for a subsequent installation in an existing tube amplifier
The FX-Loop works with  two LND150 in the send and in the return stage. The send and return level can be adjusted to their optimal value with two potentiometers. The Loop works with the present high voltage of the amplifier.
It has two inputs for low and high signal levels.

Input Levels:
InA: 30 - 60 Vpp, max. 65 Vpp
InB: 10 - 15 Vpp, max. 18 Vpp

The FX-Loop utilize POTENTIALLY FATAL HIGH VOLTAGES.
Seek help from a competent technician if you are in any way unfamiliar with high voltage circuits.
Use at your own risk.

Files:

• Documentation

• Material: Phenolic
• Shaft Size: 6 - 6,3 mm
• Size: 20,3 x 11,8 mm
• Mounting: Set-Screw with Bras insert

Clamp for capacitors

• Material: Steel, galvanized
• Diameter: 35 mm

• Type: Cancap
• Capacitance: 250 µF
• Voltage Rating: 500 V
• Tolerance: -10 % / +30 %
• Operating Temperature Range: - 25°C / + 70 °C
• Dimensions: Ø 35 mm x 88 mm
• Termination Style: radial, solder-lugs

for Fender Pilot-Light

• BA9s
• #47
• 6,3 V

TT-Chassis Aluminium - Typ 008 Standard, Dumble-Size (V2020

• Size: 490 x 200 x 65 mm (Dumble size)
• Material: 2 mm Aluminium
• Mounting: with cage nuts (not included)
• reinforced Corners
• With two cut-outs for power jacks
• Made in Germany

Files:

• Datasheet V2020
• Datasheet V2017 (old)

• Primary: 115, 220, 230 & 240 V @ 50/60 Hz
• Sec. 1: 720 V C.T. @ 200 mA, 60 V Bias Tap
• Sec. 2: 6,3 V C.T. @ 6 A
• Sec. 3: 6,3 V C.T. @ 3 A

Files:

• Datasheet
