Fuse 1.6 A slow blow, Pack of 10

Carbonfilm Resistor
Low noise, small size, high power rating
Power: 1 Watt
Voltag: 500 V working / 1000 V overload
Axial Leads
-55° C - 155° C
12 * 5 mm
RoHS

• 5F6A Generic Aluminium Chassis
• Size: 509 x 105 x 68 mm
• Material: 2 mm Aluminium (AlMg3)
• Lettering: none
• Made in Germany

• Datasheet
• Datasheet (3D)

• Type: Raised Head with cross recess
• Material: Steel
• Strength class: 4.8
• Surface: Zinc-plated
• DIN: 7985
• ISO: 7045
• Price: per pcs.

for building turret boards

Power Jack, Chassis mount

• Schurter 6162.0046
• Ratings IEC: 10 A / 250 VAC; 50 Hz
• Ratings UL/CSA: 15 A / 250 VAC; 60 Hz
• Dielectric Strength:
  • > 3 kVAC between L-N
  • > 1.5 kVAC between L/N-PE (1 min/50 Hz)
• Allowable Operation Temp.:-25 °C to 70 °C
• Degree of Protection: from front side IP 20 acc. to IEC 60529
• Protection Class:Suitable for appliances with protection class 1 acc. to IEC 61140
• Material: Housing PA6, black, UL 94V-0

• 6,3 mm jack
• mono, switched
• Installation diameter: 10 mm

Files:

• Datasheet

• 6,3 mm jack
• mono
• Installation diameter: 10 mm

Files:

• Datasheet

• Type: Toggle Switch
• Version:DPST, ON - OFF
• Rating: 15A / 250VAC, 10A / 400VAC
• Contact resistance: 10 mΩ max. at 1A 2VDC
• Insulation resistance: 1.000 MΩ min. at 500VDC
• Dielectric strength: 2.000 Vrms 50 Hz min.
• Operating Life:    10.000 cycles at full load
• Termination Style: solder lug / quick-connect terminals

• Datasheet

• 1x internal and 1x external thread
• Thread size: M3
• External thread: 6.0 mm
• Internal thread: 7.0 mm
• Material: galvanised steel
• Length: 10 mm
• Pack of 4

• Type: Pan Head, slotted
• Material: Steel
• Strength class: 4.8
• Surface: Zinc-plated
• DIN: 84
• ISO: 1207
