Elektrolyt 220 µF @ 16V

• Type: Electrolytic capacitor
• Capacitance: 10000 µF
• Voltage Rating: 16 V
• Tolerance: - 10 % / +30 %
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 18 mm x 35 mm
• Termination Style: axial

Images are for reference only. See Product Specifications

High Power Resistor
Rating: 3.9 Ohms / 5%
Power: 150 Watt / 55 Watt without heat sink
Size: 97 x 47 mm
Aluminium Chassis
Norm: MiL-R-18546 E (RE 70)

Great for attenuators, power soaks and dummy loads
Very low background noise
RoHS Compliant

Sweet and warm sounding preamp tube with high gain. We recommend this tube for guitar/bass amps.

Files:

• Datasheet

4 tubes, matched as quad

Standard EL34 made by JJ with a smooth and dizzy sound.

Limiting Values:

• Ua0: 2000 V
• Ua: 800 V
• Wa(max): 25 W
• Ug20: 800 V
• Ug2: 450 V
• Wg2(max): 8 W
• Ik: 150 mA
• Uk/f: 100 V
• Rk/f: 20 kΩ

• Datasheet

• Length: 1 m
• Color: grey
• 1st Jack: Mono 6,3 mm
• 2nd Jack: Mono 6,3 mm
• Cable type: Sommer Cable Typ SC-MERIDIAN SP215 2 x 1,5 mm², grau (#so415-0056)

• 4+2 Solder lugs

• 2+1 Solder lugs
• lugs brass, tinned

• Type: Electrolytic can capacitor
• Capacitance: 4700 µF
• Voltage Rating: 16 V
• Tolerance: - 20 % / +20 %
• Operating Temperature Range: - 40°C / + 105 °C
• Dimensions: Ø 16 mm x 32 mm
• Termination Style: radial
• Grid: 7,5

Images are for reference only. See Product Specifications

• for noval sockets
• Color: silver
• High: 55 mm
• Including Base and Shield
