DC Jack 2.1 mm, plastic, PCB mount

NP2X-BAG

The heavy duty professional phone plug series improves on the design of the existing C series by offering the thinnest available A-gauge 1/4" plug with unique Neutrik chuck type strain relief on the market. The slimline shell with a width of 14.5 mm meets the most recent requirements for highest density jackfields (15.88mm jack pitch). The precise machined one-piece tip contact without rivets makes it unique and avoids hook up in a socket or break off the tip. The Plug X Series serves all applications such as guitar applications, audio cables, snakes, speakers, amplifiers and mixing desks.
2 pole 1/4" professional phone plug, nickel contacts, black shell

Features & Benefits

• Extra slim 1/4" plug for highest packing density
• Robust diecast shell in stylish design
• Improved chuck type strain relief for reliable cable retention
• Sleek design for best handling convenience
• Precision machined one-piece contacts - avoid hook up of tip contact

Files:

• Datasheet
• Mounting

Miniature Signal Relays

• Dimensions: 20.2 x 9.8 x 12.5 mm
• Function: 2 x changeover contacts, DPDT
• Nominal voltage: 24 V/DC
• Nominal load: 1 A - 24 V/DC, 0.5 A - 120 V/AC
• Max. switching voltage: 60 V/DC / 120 V/AC

Files:

• Datasheet

2 tubes, matched as pair

The Sovtek EL84 series produces an unbeatable smooth, warm distortion sound. Excellent replacements in vintage VOX AC-30's and the like, very popular in Fender, Crate and Peavey amps.

5+2 solder lugs

• Type: Aluminum Electrolytic Capacitors
• Capacitance: 47 µF
• Voltage Rating: 500 V
• Tolerance: +/- 20%
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 21 mm x 37 mm
• Termination Style: axial

• Type: Aluminum Electrolytic Capacitors
• Capacitance: 33 µF
• Voltage Rating: 500 V
• Tolerance: +/- 20%
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 18 mm x 39 mm
• Termination Style: axial

6+2 solder lugs

ORANGE DROP®, Low Loss

• Type:  Polypropylene Film Capacitors
• Voltage Rating: 600 V
• Tolerance: - 10 % / +10 %
• Operating Temperature Range: - 55°C / + 85 °C
• Termination Style: radial

• Type: Electrolytic can capacitor
• Capacitance: 100 µF
• Voltage Rating: 100 V
• Tolerance: - 20 % / +20 %
• Operating Temperature Range: - 40°C / + 105 °C
• Dimensions: Ø 12,5 mm x 21 mm
• Termination Style: radial
• Grid: 5,0

Images are for reference only. See Product Specifications

Electro-Harmonix has released a low noise, low microphonic version of the 12AX7 that meets all specifications required for the tube to be designated 7025. The original 7025 tube was a 12AX7 that was tested and selected for the lowest noise and microphonics for use in the critical first preamp stages of amplifiers where noise and microphonics could be an issue. In order to ensure that the 7025 specification is consistently met, Electro-Harmonix has redesigned the structure of the 12AX7 and has implemented construction techniques to ensure the absolute lowest noise and microphonics possible. In all samples tested, noise and microphonics could not be detected.

The Electro-Harmonix 7025EH has a mid-range that gives clarity and definition to the sound and a smooth top end for warmth and balance. With these characteristics, along with the exceptionally low noise and low microphonics, the Electro-Harmonix 7025EH will work equally well in vintage and modern high-gain guitar amplifiers, as well as sensitive phono preamps.

• Type: LIH/125 Stranded wire - halogen free
• Conductor: stranded copper - tinned
• Conductor strands: 16 x 0.2 mm
• Insulation: TPE-S (12Y), flammable
• Cross sectional area: 0,5 mm²
• Outer Ø: 1.6 mm
• Temperature Range
• static / dynamic: -40 to +125°C / -25 to +125°C
• Operating voltage: 900V
• Insulation resistance: min. 200MΩ x km at +20°C

• Type: LIH/125 Stranded wire - halogen free
• Conductor: stranded copper - tinned
• Conductor strands: 16 x 0.2 mm
• Insulation: TPE-S (12Y), flammable
• Cross sectional area: 0,5 mm²
• Outer Ø: 1.6 mm
• Temperature Range
• static / dynamic: -40 to +125°C / -25 to +125°C
• Operating voltage: 900V
• Insulation resistance: min. 200MΩ x km at +20°C
