Alpha 2.5 kOhm linear

• Type: Aluminum Electrolytic Capacitors
• Capacitance: 22 µF
• Voltage Rating: 500 V
• Tolerance: +/- 20%
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 18 mm x 39 mm
• Termination Style: axial

• Type: Aluminum Electrolytic Capacitors
• Capacitance: 100 µF
• Voltage Rating: 500 V
• Tolerance: +/- 20%
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 30 mm x 49 mm
• Termination Style: axial

• Rated Voltage: 250 VAC
• Contact caps: nickel-plated brass
• Size: Ø 5 mm x 20 mm
• Pack of 10

This classic big bottle rectifier is the tube of choice for those famous, dual-rectifier amps. Clean and detailed while maintaining a warm and sweet tone, the 5U4GBEH offers gorgeous tube compression and articulate AC/DC conversion. The most desirable replacement ever built.

Files:

• Datasheet

• Specification: ½ Watt, axial
• Temperature Range: -55°C to +125°C
• Tolerance: 10%
• Max. Operating Voltage: 350 V
• Size: l=9.5 mm, d=3.6 mm

Carbonfilm Resistor, Bulk pack with 100 pieces.

• Low noise, small size, high power rating
• Power: 1 Watt
• Voltag: 500 V working / 1000 V overload
• Axial Leads
• -55° C - 155° C
• 12 * 5 mm
• RoHS

• Type: Cancap
• Capacitance: 40 + 20 + 20 + 20 µF
• Voltage Rating: 500 V
• Tolerance: -10 % / +30 %
• Operating Temperature Range: - 25°C / + 70 °C
• Dimensions: Ø 40 mm x 50 mm
• Termination Style: radial, solder-lugs

Rectifier

Headshell Fender Super Reverb Style
Based upon the size of the Fender Super Reverb Head, incl. corners, feet and handle.

Specifications

• Size: ca. 640 x 240 x 240 mm
• Tolex: Fender black
• Grillcloth: Fender black-white-silver
• Hardware: Fender Blackface Standard
• Weight: ca. 5,5 kg
• Wood: 18 mm Pine
• Feet: Rubber Feet, h = 30 mm

• Mounting hole distance around 128 mm
• Large Chrome straps
• length around 5-5/8" (14 cm) end to end
• mounting screws included
• For Twin Reverb®, Prosonic™, Vibrosonic, Vibro-King®

Active, serial FX-Loop for a subsequent installation in an existing tube amplifier
The FX-Loop works with  two LND150 in the send and in the return stage. The send and return level can be adjusted to their optimal value with two potentiometers. The Loop works with the present high voltage of the amplifier.
It has two inputs for low and high signal levels.

Input Levels:
InA: 30 - 60 Vpp, max. 65 Vpp
InB: 10 - 15 Vpp, max. 18 Vpp

The FX-Loop utilize POTENTIALLY FATAL HIGH VOLTAGES.
Seek help from a competent technician if you are in any way unfamiliar with high voltage circuits.
Use at your own risk.

Files:

• Documentation
