Tolex Marshall-Style Levant Black / Schwarz

Set of metal corners for housing consisting of:

• 8 x Cabinet corner w/ cutaway 2 leg, silver (pe-c1819k)
• Powder Coated black
• Internal radius: 12 mm
• 16 x Screws, flat head, black

PVC piping for baffles and front panels

• Size 3.1 x 8.5 mm
• 4 m piece

The TT VPUMP kit is a very effective working voltage converter which generates an output voltage of 90 V DC to 220 V DC  from a 12V DC input voltage.
The circuit is in use for many years now and it is proven. In this kit the circuit has been adapted to a compact size and optimized for use in small preamplifier chassis. So it is an ideal HV power supply for tube stompboxes and preamps without the need of additional transformers and HV filter capacitors.

The VPump can be operated with a standard 12V DC switching power supply.
The switching power supply is not included in the kit.

Specification:
Input Voltage: 12 V DC @ min 4 VA
Output Voltage: 90 - 220 V DC, adjustable
Output Current: 15 mA @ 220 V DC max

Files:

• Layout PCB V1.4
• Layout PCB V1.5
• Layout PCB V1.6

• Diameter outside: 5,6 mm
• Diameter inside: 2,1 mm
• Depth: 27,0 mm
• Mounting hole: 11 mm
• Material: Metal
• Maximum current: 2A / 48 V DC

Carbonfilm Resistor
Low noise, small size, high power rating
Power: 1 Watt
Voltag: 500 V working / 1000 V overload
Axial Leads
-55° C - 155° C
12 * 5 mm
RoHS

The signal lamps for front panel installation are designed for screw mounting with a recommended installation hole of Ø8mm. The sockets can be supplied with an external or internal reflector. The plug insert is removable. Supplied with washer and hexagonal nut.

• Type: Toggle Switch
• Version: 4PDT, ON-OFF-ON
• Assembly Ø: 5,8 mm
• Rating: 5 A / 250VAC, 2 A / 125VAC
• Termination Style: solder-lugs
