Strap Handle black w/ nickel ends

Double Relay Switcher for channel switching and similar applications.

The kits comes with all components incl. 6 V Finder relaise but without switches for the front panel.
Works with 6,3 V heater voltage.

Files:

• Datasheet

Relays, type Finder Dual-In-Line-Relais 2,0 A
for low breaking capacity

• Compact dimensions: 20.3 x 10.1 x 11.4 mm, grid according to wiring diagram
• Function: 2 x changeover contacts
• Constant/inrush current: 3.0 A/2.0 A
• Rated/switching voltage: 125 VAC/250 VAC
• Breaking capacity AC 1/AC 15 (230 V): 125 VA/25 VA
• Switching current DC 1:    2.0 A/30 V, 0.3 A/110 V
• Minimum switching load: 10 mW (0.1 V/1.0 mA)
• Contact material: AgNi+Au (5.0 µm)
• Useful mechanical life DC: 10 x 10 exp6 switching cycles
• Electrical life AC 1: 100 x 10 exp3 switching cycles
• Insulation coordination EN 61810-5: 1.2 kV/2
• Electric strength coil/contact (1.2/50 µs): 1.5 kV
• Response/release time: 6.0 ms/2.0 ms
• Ambient temperature: –40 to +85 °C
• Relay protection class: RT III
• Certifications: CSA, UL, GOST

• Datasheet

Cliff 1160 mono jack

• Jack socket, mono
• switched
• for chassis mounting, 4 solder terminals
• for 6.3 mm jack plug
• Used by Marshall and many others

• Datasheet

• Size 5 x 14 mm
• 4 m piece

• Ø 2.5 mm
• 2 m piece

• Mounting caps: Steel, nickel plated
• Color: Brown
• Including mounting hardware and screws

• 20 mm rubber foot black.
• Height: 9 mm.
• Fixing hole: 3,3 mm.
• Weight: 2,8g
• Pack of 4
• Screws included

• Rubber foot with steel insert
• Size: d = 38 mm, h = 20 mm
• Pack of 4
• Screws included

• Size: ca. 90 x 75 cm (only available in this size), recommended for baffles with a maximum size of 80 x 60 cm.
• Easy-to-use Grillcloth
• Neutral appearance, medium material thickness
• Material: 94 % Polypropylen, 6 % Acrylic
• Price per pcs.
• Actual shades may vary.

• FAQ Grillcloth

• 6,3 mm jack
• mono
• Installation diameter: 10 mm

Files:

• Datasheet

waterbased Tolex-Glue, 500 ml

How To use ?
The glue must be applied onto the wood and the Tolex.
After a dyring time of ca. 30 min the Tolex can be put onto the wood.

And how much glue do you need ?
The can of 500 ml is enough for ca. 2.3 m². This is enough for a TTC212REX and there is still about 100 ml glue left.

Attention
For a better adhesive power it is recommended to put a second layer of glue onto the tolex after the drying time.

Files:

• Safety Datasheet

Round dish / ferrule for 6.3 mm jack

• metal
• black powder coated
• incl. 3 screws

Set of metal corners for housing consisting of:

• 8 x Cabinet corner, Fender Style - w/ cutaway 2 leg, silver (ah4026)
• Steel nickel plated
• Internal radius: 12 mm
• 24 x Screws with extra flat head, silver
