Miniatur-Potentiometer 100 k vertical PT10

The "Living legends" of Rock and Roll guitar sounds are back! Original designs of the late 40's and early 50's have been recreated using many of the original parts suppliers. Highly efficient AlNiCo magnets and seamed paper cones are the foundation for the famous JENSEN® Sound. JENSEN® "P" Series Vintage AlNiCo magnet speakers represent an important contribution to the paste, present and, no doubt, the future of rock and roll music. They are loved by generations of guitarists around the world.

 Technical Details:

• Size: 10"
• Impedance: 8 Ohm
• Rated Power (RMS): 25 W
• Sensitivity @ 1 W, 1 m:    95 dB
• Resonance Frequency  fs: 97 Hz
• Bell: No Bell

Files:

• Datasheet

Vishay ORANGE DROP® 225P

• Type:  Polyester Film Capacitors
• Voltage Rating: 400 V
• Tolerance: - 10 % / +10 %
• Operating Temperature Range: - 55°C / + 85 °C
• Termination Style: radial

• Type: Film capacitor
• Dielectric: polypropylene film
• Coating: plastic foil, metalized on both sides
• Capacitance: 0,1 µF
• Voltage Rating: 400 VDC / 250 VAC
• Tolerance: ±10 %
• IEC climate category: 55/100/56
• Operating Temperature Range: - 55°C / + 100 °C
• Dimensions: 7 x 14 x 18 mm
• Termination Style: radial
• Grid: 15

• Type: Film capacitor
• Dielectric: polypropylene film
• Coating: plastic foil, metalized on both sides
• Capacitance: 0,047 µF
• Voltage Rating: 400 VDC / 250 VAC
• Tolerance: ±10 %
• IEC climate category: 55/100/56
• Operating Temperature Range: - 55°C / + 100 °C
• Dimensions: 5 x 11 x 18 mm
• Termination Style: radial
• Grid: 15

• Type: Electrolytic can capacitor
• Capacitance: 10 µF
• Voltage Rating: 100 V
• Tolerance: - 20 % / +20 %
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 5 mm x 11 mm
• Termination Style: radial
• Grid: 2,0

Images are for reference only. See Product Specifications

• Resistance: 25k Ohm
• Power: 0,25 W
• Max Voltage: 250 V
• Grid 12,5/10 mm
• Ø: 15,0 mm
• h: 7,0 mm
