Mini Rocker switch, 2 postion, DPST, ON-OFF, red

• Power Rating: 0,125 W
• Voltage Rating: 150 V AC
• Tolerance: 20%
• Shaft: 6,3 mm, Solid Shaft
• Shaft length: 15 mm
• Drill Ø: M7 (6,8 mm)
• Termination: Solder lugs
• Dimension: 16 mm

• Type: Mini Rocker Switch
• Version: SPST  ON-OFF, Lighted red
• Dimension: 21 x 15 mm, Snap-in mount
• Rating: 6,5 A / 250VAC
• Termination Style: solder lug / quick-connect terminals

• Springs: 2
• Delay Type: long
• Size: long
• Replacement: Fender, Marshall, Ampeg "F"
• corresponds to Fender part number 006-4063-049
• Accutronics by Accu-Bell, Made in Korea

• Springs: 2
• Delay Type: long
• Size: long
• Replacement: Fender, Marshall, Ampeg "F"
• corresponds to Fender part number 006-4063-049

2 tubes, matched as pair

JJ 6V6 Double Mica double-layered mica in the upper part of the tube. This stabilizes the tube system and significantly reduces possible vibrations that can occur due to heavy mechanical stress. This version of the JJ 6V6 was specifically designed for use in combo amplifiers.

The JJ6V6 is a beam power pentode with octal base and a maximum plate dissipation of 14W. It has fat low end and full mid tones with very good tone separation and a smooth, clean high end - in general, a very balanced tone.
Currently, the only new production 6V6 which is approved for up to 500V anode voltage in pentode operation.

Files:

• Datasheet

Cliff 1160 mono jack, vintage-style

• Jack socket, mono
• switched
• for chassis mounting, 4 solder terminals
• for 6.3 mm jack plug
• Used by Marshall and many others

• Datasheet
