JJ EL34 Red Label - QUAD

Very linear working 12AX7 / ECC83 with long anode plates and spiral heating, which makes the tube less sensitive to interference from AC heating.
We recommend this tube for audio and high-end amps as well as for "modern" Fender amps with more overdrive, but also as an input tube in old Marshall JCM800s.

Note: Tubes equipped with long plates are commonly associated with a "warmer" or "richer" sound, whereas those with shorter plates tend to deliver a "tighter sound". However, tubes featuring long plates exhibit increased sensitivity to vibrations and mechanical disturbances, rendering them less ideal for critical applications.

Files

• Datasheet

The Sovtek 12AX7WA is a defacto standard in 12AX7 tubes for many years yet because of its high dependability and its low noise floor.

• Dimensions: 20.2 x 9.8 x 12.5 mm
• Function: 2 x changeover contacts, DPDT
• Nominal voltage: 5 V/DC
• Nominal load: 1 A - 24 V/DC, 0.5 A - 120 V/AC
• Max. switching voltage: 60 V/DC / 120 V/AC

Files:

• Datasheet

2 tubes, matched as pair

Very credible 6550 so far.
We recommend this 6550 for bass amps which are working with 6550 tubes, especially Ampegs.

Files:

• Datasheet

• Type: Electrolytic capacitor
• Capacitance: 100 µF
• Voltage Rating: 63 V
• Tolerance: - 10 % / +30 %
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 8 mm x 19 mm
• Termination Style: axial

Images are for reference only. See Product Specifications

• Type: Electrolytic capacitor
• Capacitance: 10 µF
• Voltage Rating: 100 V
• Tolerance: 20 %
• Operating Temperature Range: - 40°C / + 105 °C
• Dimensions: Ø 6,5 mm x 18 mm
• Termination Style: axial

Images are for reference only. See Product Specifications

• Type: Aluminum Electrolytic Capacitors
• Capacitance: 33 µF
• Voltage Rating: 500 V
• Tolerance: +/- 20%
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 18 mm x 39 mm
• Termination Style: axial

The high-quality TTEL84/6BQ5 tube with 12 watts of power is perfect for guitar, bass, and audio amplifiers. Inspired by classic NOS EL84 models, this tube is manufactured using modern production methods to ensure consistent high quality.

It offers an ideal combination of sound and reliability and is a direct replacement for all EL84 or 6BQ5 tubes.

Electrical Specifications

• Type: Pentode
• Base: Noval (B9A)
• Heater Voltage: 6.3 V (min 5.8 V / max 7.7 V)
• Heater Current: approx. 0.76 A
• Anode Dissipation: 12 W
• Screen Grid Dissipation: 2 W

Operating Conditions

• Anode Voltage (Va): max. 300 V
• Screen Grid Voltage (Vg2): max. 300 V
• Grid Bias Voltage (Vg1): -7.3 V (typical for Class-A operation)
• Anode Current (Ia): 48 mA (at -7.3 V grid bias)
• Screen Grid Current (Ig2): 5 mA

Characteristic Curves

• Amplification Factor (μ): approx. 20
• Internal Resistance (Ra): approx. 38 kΩ
• Transconductance (S): 11 mA/V

Mechanical Specifications

• Length: approx. 70 mm (without pins)
• Diameter: approx. 22.5 mm
• Weight: approx. 25 g

Typical Applications

• Class-A Amplifier: 5.7 W output power at 250 V Anode voltage, 48 mA Anode current
• Class-AB Amplifier: 17 W output power at 300 V Anode voltage, 48 mA Anode current per tube (Push-Pull configuration)

Pinout

1. g1 (Control Grid)
2. k, g3 (Cathode, Screen Grid)
3. h (Heater)
4. h (Heater)
5. a (Anode)
6. • (no connection)
7. • (no connection)
8. g2 (Screen Grid)
9. g3 (Screen Grid)

Usage Notes

• Operating Temperature: Should be operated in a well-ventilated enclosure to prevent overheating.
• Interchangeability: EL84 can be replaced by the Russian 6П14П or American 7189, taking into account different specifications.

• Standard Recovery Rectifier
• Current Rating: 6A
• Forward Current: 6A
• Forward Current Avg Rectified, IF(AV): 6A
• Forward Surge Current Max, Ifsm: 400A
• Forward Voltage: 1 V
• Forward Voltage Max, VF:1.3V
• Repetitive peak reverse voltage Vrrm: 50 V

Files:

• Datasheet

• Type: Metalfilm Resistor
• Power: 0,4 Watt
• Voltage: 350 V / 500 VDC Overload
• Tolerance: 1%
• Surface temperature: max. 125 °C
• Temperature coefficient: TC ±50
• Dimensions:    6,3 mm x 2,5 mm
• Termination Style: axial
• RoHS compliant: Yes

Metalfilm Resistor
Great for amps and effects, low noise, small size, high power rating

Spezification:

• Power: 0,5 Watt
• Voltag: 350 V working / 700 V overload
• Axial Leads
• -55° C - 155° C
• 9,4 * 3,2 mm
• 1,0 %
• RoHS

• Signal wire LiYDY 1 x 0,14 mm², shielded
• Diameter Outside: ca. 2,6 mm
• Voltage Rating max: 50 / 75 V AC / DC
• Capacity: ca. 260 pF / m
• Temperature range: -10 bis +70 C°
• Conductor resistance: 40 Ohm / km @ 20 C°
• Test voltage: > 1 kHz
• IEC 60228/ VDE 0295
• 5 meter

• Type: Metalfilm Resistor
• Power: 0,4 Watt
• Voltage: 350 V / 500 VDC Overload
• Tolerance: 1%
• Surface temperature: max. 125 °C
• Temperature coefficient: TC ±50
• Dimensions:    6,3 mm x 2,5 mm
• Termination Style: axial
• RoHS compliant: Yes
