HICON J63M01, Jack plug mono, silver

• Type: Rocker Switch
• Version: DPST  ON-OFF, Lighted red, labeled I/O
• Recess: 30 x 22 mm, Snap-in mount
• Rating: max. 16A/250V AC
• Termination Style: solder lug / quick-connect terminals

• Type:Toggle Switch
• Version:SPST, ON-OFF
• Rating: 3A / 250V, 6A / 125V
• Insulation resistance: 100MΩ min.
• Dielectric strength: 1000V min.
• Operating Life: 25.000 cycles
• Drill Ø: 12 mm
• Termination Style: solder-lugs

• Type: Toggle Switch
• Version:DPST, ON - OFF
• Rating: 15A / 250VAC, 10A / 400VAC
• Contact resistance: 10 mΩ max. at 1A 2VDC
• Insulation resistance: 1.000 MΩ min. at 500VDC
• Dielectric strength: 2.000 Vrms 50 Hz min.
• Operating Life:    10.000 cycles at full load
• Termination Style: solder lug / quick-connect terminals

Files:

• Datasheet

• Type: Footswitch
• Version: 3PDT Latching
• for True Bypass
• Rating: 1A/9VDC
• Contact resistance: <30mΩ
• Insulation resistance: 500VDC-100MΩ min.
• Dielectric strength: 500VAC for 1 minute
• Operating Life: 30.000 cycles
• Termination Style: solder-lugs

Files:

• Datasheet

• Type: Octal Socket Fender Style
• Version: Ceramic Chassis mount
•   w/mounting bracket
• Termination Style: solder lugs
• for Tube Type: EL34, E34L, 6L6, 6V6, 6550,
•   KT66/77/88 etc.

Panel Mount Potentiometer

• Power Rating: 0,125 W
• Voltage Rating: 150 V AC
• Tolerance: 20%
• Shaft: 6,3 mm, Solid Shaft
• Shaft length: 15 mm
• Drill Ø: M7 (6,8 mm)
• Termination: Solder lugs
• Dimension: 16 mm

Metal Oxide Film Resistors

• Termination Style: Axial
• Power Rating: 5 W
• Tolerance: 5 %
• Temperature Coefficient: 350 PPM / C
• Operating Temperature min/max: - 55 C / + 155 C
• Voltage Rating: 500 V
• Diameter: 8,5 mm
• Length: 25 mm
• Lead Diameter:  0.75 mm

• Springs: 2
• Delay Type: long
• Size: long
• Replacement: Fender Hot Rod Deluxe / DeVille

• Springs: 3
• Delay Type: medium
• Size: short (9 ¼" / 23,5 cm)
• Input Impedance: 800 Ohms
• Output Impedance: 2575 Ohms
• Mounting: Horizontal Open Side Down
• Connectors: Input Insulated - Output Grounded
• Accutronics by Accu-Bell, Made in Korea

Suitable for these amplifiers Fender® Blues Jr., Deluxe 90, Princeton 65, Stage Series, Acoustasonic Junior, Vaporizer, Ultimate Chorus, Ultra Chorus, Sidekick Keyboard 60, Sidekick Reverb 35, Super 60, Super 112, Frontman 65R, Eighty-Five, Tech 21® Trademark 30, Epiphone® Valve Junior Hot Rod, Vox® AC15CC, AC15C, Peavey® Envoy 110, Ultra 60/120, Backstage, Valveking and similar models.
