Elektrolyt 22 µF @ 450V

• Capacitance: 10 nF
• Voltage: 305 VAC
• Lead Pitch: 10 mm
• Maximum Operating Temperature: +110°C
• Tolerance: ±20%
• Terminal Type: Through Hole

• Wiring harness for internal speaker connection
• Type: Mono / 1 Speaker
• Wire: 2 x 1,5 mm² red - black
• Hicon HI-J63MA05 Angled Jack / speaker crimps
• Length: ca. 55 cm

• Type: Aluminum Electrolytic Capacitors
• Capacitance: 220 µF
• Voltage Rating: 350 V
• Tolerance: - 10%+30%
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 25 mm x 38 mm
• Termination Style: axial

• Type: Aluminum Electrolytic Capacitors
• Capacitance: 100 µF
• Voltage Rating: 100 V
• Tolerance: +/- 20%
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 10 mm x 30 mm
• Termination Style: axial

• Fender#: 002-8421-000
• Hum Control Potentiometer
• Without nut and washer.

• Type: Electrolytic capacitor
• Capacitance: 22 µF
• Voltage Rating: 35 V
• Tolerance: - 10 % / +30 %
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 5 mm x 11 mm
• Termination Style: axial
• Color and manufacturer may differ from the picture shown

Images are for reference only. See Product Specifications

• Capacitance: 100 µF ±20 %
• Withstand voltage: 500 Volts DC
• Dimensions: Ø33xL49 mm
• Connections: Ø0.80xL40 mm
• Temperature range: -40°C/-40°F...+85°C/+185°F
• Conductor material: Aluminum foil
• Winding technique: MLytic

• Type: Cancap
• Capacitance: 100 µF
• Voltage Rating: 500 V
• Tolerance: -10 % / +30 %
• Operating Temperature Range: - 25°C / + 70 °C
• Dimensions: Ø 25 mm x 40 mm
• Termination Style: radial, Snap-In mount

• Type: Electrolytic can capacitor
• Capacitance: 2,2 µF
• Voltage Rating: 450 V
• Tolerance: - 20 % / +20 %
• Operating Temperature Range: - 40°C / + 105 °C
• Dimensions: Ø 10 mm x 12 mm
• Termination Style: radial
• Grid: 5,0

Images are for reference only. See Product Specifications

• Type: Multisection Capacitor
• Capacitance: 32 + 32 µF
• Voltage Rating: 500 V
• Tolerance: - 10% / +30 %
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 35 mm x 50 mm
• Termination Style: radial, solder lugs

• Type: Electrolytic can capacitor
• Capacitance: 47 µF
• Voltage Rating: 450 V
• Tolerance: - 20 % / +20 %
• Operating Temperature Range: - 25°C / + 105 °C
• Dimensions: Ø 16 mm x 25 mm
• Termination Style: radial
• Grid: 7,5

Images are for reference only. See Product Specifications

• Powertransformers for preamps, same specs as the Engl 520 Powertransformers
• Pri: 230 V (gelb / yellow)
• Sec 1: 25V @ 0,1 A (grün / green )
• Sec 2: 10V @ 0,9 A (blau / blue)
• Sec 3: 240 V @ 0,03 A (rot / red)
• Sec 4: 6,4 V @ 1,3 A (schwarz / black)
• Long leads
• d = 80 mm / h = 27 mm

Fender-Style Outputtransformer for 5E3, vertical mounting

• Pri.: 8000 Ohm C.T.
• Sec.: COM-4-8-16 Ohm
• Power: 25 Watt

Files:

• Datasheet

• Power: 3,5 W
• 4 Ohm @ 14k5
• 8 Ohm @ 29k
