Chassis Strap Nut 8-32 x 3 1/4, Set of 10

• Matching srew for the chassis straps.
• Size: UNC 8-32 x 3-1/4
• Fender®  Part # 002-2236-049
• price per screw

• Matching srew for the chassis straps.
• Size: UNC 8-32 x 3-1/4
• Fender®  Part # 002-2236-049
• price per screw

• Chassis Straps small size
• Mounting hole distance around 76 mm
• one piece

• Chassis Straps large size
• Mounting hole distance around 128 mm
• one piece

• Chassis Straps, medium size
• Mounting hole distance around 101 mm
• one piece

• Type: Aluminum Electrolytic Capacitors
• Capacitance: 15 µF
• Voltage Rating: 500 V
• Tolerance: +/- 20%
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 16 mm x 30 mm
• Termination Style: axial

• Type: Electrolytic capacitor
• Capacitance: 22 µF
• Voltage Rating: 35 V
• Tolerance: - 10 % / +30 %
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 5 mm x 11 mm
• Termination Style: axial
• Color and manufacturer may differ from the picture shown

Images are for reference only. See Product Specifications

Capacitor Cover for 65 Twin Reverb
Size: l = 7 1/8" x 3 1/2", center to center on the mounting holes
Fender®  Part # 003-7854-000

• Type: Aluminum Electrolytic Capacitors
• Capacitance: 220 µF
• Voltage Rating: 350 V
• Tolerance: - 10%+30%
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 25 mm x 38 mm
• Termination Style: axial

The Sovtek 12AX7WA is a defacto standard in 12AX7 tubes for many years yet because of its high dependability and its low noise floor.

Sweet and warm sounding preamp tube with high gain. We recommend this tube for guitar/bass amps.

Files:

• Datasheet

Headshell Fender Super Reverb Style
Based upon the size of the Fender Super Reverb Head, incl. corners, feet and handle.

Specifications

• Size: ca. 640 x 240 x 240 mm
• Tolex: Fender black
• Grillcloth: Fender black-white-silver
• Hardware: Fender Blackface Standard
• Weight: ca. 5,5 kg
• Wood: 18 mm Pine
• Feet: Rubber Feet, h = 30 mm

[content:3210136]

• Faceplate for TT Kit 5F6
• Color #C14 silver brusched, black
• Material: 1,5 mm Transply
• Front and rear pane

Files:

• Template

Tube-Town 5F6A Fender-Style Chassis

• Size: 508 x 126 x 67 mm
• Material: 1,5 mm Steel, hot-dip galvanized
• without silkscreen printing
• including capacitor cover
• cornerd welded
• Made in Germany

Files:

• Datasheet

TT 5F6 V2 Classic Amp Kit

Set of componentes for building the TT 5F6 V2 Guitar Amp.
Please visit the >>Project page for more infos about the amp, schematics and layout.

INCLUDED:

• Transformers (Power, Choke and Output)
• Resistors
• Capacitors
• Jacks
• Light
• Wires
• Board
• Switches
• Tubes
• Fuses & Fuesholder

NOT INCLUDED:

• Chassis ( see "Accessories" tab for matching chassis )
• Knobs
• Faceplate

To build this project knowledge in electric engeneering, experience with high voltage, and the reading and understanding of schematics and dealing with measurement device is highly recommended .
There is NO step-by-step guide for beginners. The circuit and layout plan includes all relevant information. If you don't understand it then don't build it.
THIS IS NOT A BEGINNERS PROJECT !

Mounting set for case handles with 2 holes consisting of

•     2 x T-Nut M5
•     2 x Countersunk screw M5x30 mm, nickel-plated

• Chassis Straps, medium size
• Mounting hole distance around 101 mm
• one piece
