SCR / Solen Fast 3,3 uF / 630 V / MKP

• Type: Metalized polypropylene film Capacitors
• Capacitance: 10 µF
• Voltage Rating: 630 V
• Tolerance: - 5% / +5 %
• Operating Temperature Range: - 25°C / + 85 °C
• Dimensions: Ø 29 mm x 49 mm
• Termination Style: axial
• Small size
• self-healing
• non inductive

These axial capacitors are specially appreciated for their high sonic performances.

• Type: Metalized polypropylene film Capacitors
• Capacitance: 4,7 µF
• Voltage Rating: 630 V
• Tolerance: - 5% / +5 %
• Operating Temperature Range: - 25°C / + 85 °C
• Dimensions: Ø 24 mm x 38 mm
• Termination Style: axial
• Small size
• self-healing
• non inductive

These axial capacitors are specially appreciated for their high sonic performances.

• Type: Metalized polypropylene film Capacitors
• Capacitance: 6,8 µF
• Voltage Rating: 630 V
• Tolerance: - 5% / +5 %
• Operating Temperature Range: - 25°C / + 85 °C
• Dimensions: Ø 25,4 mm x 43,4 mm
• Termination Style: axial
• Small size
• self-healing
• non inductive

These axial capacitors are specially appreciated for their high sonic performances

• Type: Metalized polypropylene film Capacitors
• Capacitance: 22 µF
• Voltage Rating: 630 V
• Tolerance: - 5% / +5 %
• Operating Temperature Range: - 25°C / + 85 °C
• Dimensions: Ø 40 mm x 58 mm
• Termination Style: axial
• Small size
• self-healing
• non inductive

These axial capacitors are specially appreciated for their high sonic performances.

EHX Oil Capacitors are oil impregnated, polyester capacitors that are enclosed in aluminum cylindrical cans and hermetically sealed for superior performance and durability. Impregnating the capacitors in oil eliminates air bubbles between the dielectric and foil that could affect their stability during operation. This enables the capacitors to operate over a wide temperature range with a very tight tolerance.
Originally, oil capacitors were only used in military and precision equipment as well as Hi-Fi audio. Due to their rich, natural tone, they are now widely used in guitars and guitar amplifiers. EHX Oil Capacitors have a balanced, detailed sound with a smooth, vintage top end. They will make any guitar or amplifier more responsive, touch sensitive, and refined.

Spezification:

• Capacitance: 0,033 µF
• Voltage Rating: 600 V
• Dimensions: Ø 11 mm x 23 mm
• Termination Style: axial
