Power Jack IEC320 / C14 , Schurter

Screw set for power jack chassis mounting

• 2 x screw M3 x 10 mm
• 2 x nut M3
• 2 x tooth lock washers

• Type: Multisection Capacitor
• Capacitance: 50 + 50 µF
• Voltage Rating: 500 V
• Tolerance: - 10% / +30 %
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 35 mm x 50 mm
• Termination Style: radial, solder lugs

• Type: Aluminum Electrolytic Capacitors
• Capacitance: 22 µF
• Voltage Rating: 500 V
• Tolerance: +/- 20%
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 18 mm x 39 mm
• Termination Style: axial

• Type: Electrolytic capacitor
• Capacitance: 47 µF
• Voltage Rating: 63 V
• Tolerance: - 10 % / +30 %
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 8,5 mm x 17 mm
• Termination Style: axial

Images are for reference only. See Product Specifications

• Type: Aluminum Electrolytic Capacitors
• Capacitance: 10 µF
• Voltage Rating: 350 V
• Tolerance: +/- 20%
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 10 mm x 30 mm
• Termination Style: axial

A huge part of being a musician is being intentional about your work. This concept can apply to sound, songwriting, aesthetic, and even gear selection; which goes hand-in-hand with the philosophy behind our Anthem Series Speakers. Each speaker in our Anthem Series waspurpose-built to optimize their overall power and functionality without compromising their finely-tuned classic American-voiced tone.
After hundreds of hours of research, parts selection, and testing, we’re confident we have outfitted each of these speaker baskets with their perfect paper, voice coil, and magnet counterparts. Straight-seamed ribbed cones, were chosen for their superior performance and unmatched tone, and top-shelf voice coils and magnets have been carefully paired to each of their respective speaker cone sizes.

Technical Data:

• Size: 8" Speaker
• Voice Coil: 1" Voice Coil
• Magne:t 10 oz Ceramic Magnet
• Power Handling: 15 Watts
• Efficiency: 91 db
• Voice Coil Type: Nomex voice coil

Files:

• Datasheet

Variable voltage control for voltages up to 600 V

Possible applications:
- G2 Control
- Power adjustment

Please see the >>TT VoCoM Projekt-Seite zu finden.

Der Bausatz beinhaltet alle Teile die zum Bau benötigt werden wie Widerstände, Dioden, Leistungstransistor, Kühlkörper, Potentiometer, Schraube, Mutter, Leitung, Beschriftungsschild.

ACHTUNG HOCHSPANNUNG:
Dieser Bausatz ist nichts für Anfänger. Wer nicht weis, was er damit tut, sollte diesen Bausatz auch nicht kaufen !

">>TT VoCoM project page for more infos

Kit includes:
all parts to build this VVC. Resistors, Heatsink, Wires, Potentiometer, PCB, Label, Screws, Nuts.

WARNING: HIGH VOLTAGE !!
This kit is not for beginners. If you do not know what you are doing than you should NOT buy this kit!

• Pri: 0-220-230-240 V (schwarz-gelb-lila-rot / black-yellow-purple-red)
• Sec 1: 0 - 300 V @ 0,15 A (grün-rot / green-red)
• Sec 2: 0 - 300 V @ 0,15 A (weiß-blau / white-blue)
• Sec 3: 50 V @ 0,05 A (orange)
• Sec 4: 5 V @ 3 A (braun/brown)
• Sec 5: 6,3 V @ 5 A (schwarz/black)
• freie Enden / long leads 250 mm
• Größe / Size: 115 * 45 mm
• EN 61558 50/60 Hz

• Rated Voltage: 250 VAC
• Contact caps: nickel-plated brass
• Size: Ø 5 mm x 20 mm

Set of 4 feet with screws.

Original Fender part number 099-3900-000
