JJ 6550 - QUAD

• Type: Aluminum Electrolytic Capacitors
• Capacitance: 100 µF
• Voltage Rating: 100 V
• Tolerance: +/- 20%
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 10 mm x 30 mm
• Termination Style: axial

• Type: Aluminum Electrolytic Capacitors
• Capacitance: 220 µF
• Voltage Rating: 350 V
• Tolerance: - 10%+30%
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 25 mm x 38 mm
• Termination Style: axial

• Type: Aluminum Electrolytic Capacitors
• Capacitance: 47 µF
• Voltage Rating: 500 V
• Tolerance: +/- 20%
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 21 mm x 37 mm
• Termination Style: axial

4 tubes, matched as quad

EL34 II has fuller low mids and low end but does not lose headroom in the high end. Stronger than regular JJ EL34 but not as aggressive as the JJ E34L.

• Ua = 250 V
• Ug3 = 0 V
• Ug2 = 265 V
• Ug1 = -13,5 V
• Ia = 100 mA
• Ig2 = 14,9 mA
• S = 11 mA/V
• Ri = 15 kΩ
• μg2/g1 = 11

• Ua0 = 2000 V
• Ua = 800 V
• Wa(max) = 25 W
• Ug20 = 800 V
• Ug2 = 450 V
• Wg2(max) = 8 W
• Ik = 150 mA
• Uk/f = 100 V
• Rk/f = 20 kΩ

Files:

• Datasheet

4 tubes, matched as quad

The 6L6WXT+ features larger plate dimensions and 20 percent higher output than the Sovtek 5881WXT. Extremely low noise and a excellent detailed and harmonic sound, plenty of power and very easy to handle - even while using in "hot" setups.

FULL - WAVE VACUUM RECTIFIER
5U4GB is a directly heated full wave octal base rectifier for Hi-Fi and guitar amplifiers. Suitable for use in any 5U4 socket.

Files:

• Datasheet

Sweet and warm sounding preamp tube with high gain. We recommend this tube for guitar/bass amps.

Files:

• Datasheet

TT Selection: Balanced
Both systems with balanced gain

Sweet and warm sounding preamp tube with high gain. We recommend this tube for guitar/bass amps.

Files:

• Datasheet

• Type: Electrolytic can capacitor
• Capacitance: 470 µF
• Voltage Rating: 63 V
• Tolerance: 20 %
• Operating Temperature Range: - 55°C / + 105 °C
• Dimensions: Ø 13 mm x 21 mm
• Termination Style: radial
• Grid: 5

Images are for reference only. See Product Specifications

• Type: Electrolytic can capacitor
• Capacitance: 3,3 µF
• Voltage Rating: 63 V
• Tolerance: - 20 % / +20 %
• Operating Temperature Range: - 40°C / + 105 °C
• Dimensions: Ø 4 mm x 7 mm
• Termination Style: radial
• Grid: 1,5

Images are for reference only. See Product Specifications

• Type: Electrolytic can capacitor
• Capacitance: 220 µF
• Voltage Rating: 16 V
• Tolerance: - 20 % / +20 %
• Operating Temperature Range: - 40°C / + 105 °C
• Dimensions: Ø 8 mm x 11 mm
• Termination Style: radial
• Grid: 3,5

Images are for reference only. See Product Specifications

• Type: Electrolytic can capacitor
• Capacitance: 10 µF
• Voltage Rating: 16 V
• Tolerance: - 20 % / +20 %
• Operating Temperature Range: - 40°C / + 105 °C
• Dimensions: Ø 4 mm x 7 mm
• Termination Style: radial
• Grid: 1,5

Images are for reference only. See Product Specifications

• Type: Electrolytic can capacitor
• Capacitance: 1000 µF
• Voltage Rating: 25 V
• Tolerance: - 20 % / +20 %
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 10 mm x 19 mm
• Termination Style: radial
• Grid: 5

Images are for reference only. See Product Specifications
