Desoldering pump Standard

• Type: Chickenhead
• Material: Phenolic
• Shaft Size: 6 - 6,3 mm
• Size: 32 x 13,7 mm
• Mounting: Set-Screw

Relays, type Finder Dual-In-Line-Relais 2,0 A
for low breaking capacity

• Compact dimensions: 20.3 x 10.1 x 11.4 mm, grid according to wiring diagram
• Function: 2 x changeover contacts
• Constant/inrush current: 3.0 A/2.0 A
• Rated/switching voltage: 125 VAC/250 VAC
• Breaking capacity AC 1/AC 15 (230 V): 125 VA/25 VA
• Switching current DC 1:    2.0 A/30 V, 0.3 A/110 V
• Minimum switching load: 10 mW (0.1 V/1.0 mA)
• Contact material: AgNi+Au (5.0 µm)
• Useful mechanical life DC: 10 x 10 exp6 switching cycles
• Electrical life AC 1: 100 x 10 exp3 switching cycles
• Insulation coordination EN 61810-5: 1.2 kV/2
• Electric strength coil/contact (1.2/50 µs): 1.5 kV
• Response/release time: 6.0 ms/2.0 ms
• Ambient temperature: –40 to +85 °C
• Relay protection class: RT III
• Certifications: CSA, UL, GOST

• Datasheet

Metaloxide film resistor

• Nominal Power: 1 Watt
• Max. cont. Working Voltage:: 500 V RMS
• Tolerance: +/- 1%
• Temperature range: -55° C...200° C
• Flame retardant
• Very Small Size
• Size: 6,3 x 2,4 mm

Our freezing spray is designed for cooling components, providing a quick and effective solution for your needs. With a cooling capacity of up to -50 °C, this spray is material-compatible and ideal for a variety of applications.

• Effective cooling for material-sensitive components
• Helps cool heat-sensitive devices during soldering
• Quickly cools components like transistors, diodes, and resistors for thermal fault detection
• Great for testing thermostats in refrigerators and freezers
• Halogen-free and suitable for electronic, electrical, and precision mechanics applications
• Provides shock-like rapid cooling down to -50 °C with long-lasting effects
• Easy application with a fine nozzle spray
• Material-compatible and flammable

• Capacity: 200 ml

Attention: No shipping with FedEx possible.

Files:

• Safety Datasheet
