Flat Cable-Plug, Cable Shoe 5,2 x 0,5 mm, Pack of 10

for building turret boards

• Type: Alpha Rotary Switch
• Version: 4 pole / 3 positions, non-Shorting
• Shaft lenght: 19 mm
• Rating: 0.3 A / 125 V/AC
• Contact resistance: max. 50 mΩ
• Insulation resistance: min. 100 mΩ / 500 V/DC
• Termination Style: solder lugs
• Shaft: 6,3 mm, D-Shaft
• Drill Ø: 8,9 mm



• Type: Toggle Switch
• Version: DPDT   ON - ON
• Rating: 15A / 250VAC, 10A / 400VAC
• Contact resistance: 10 mΩ max. at 1A 2VDC
• Insulation resistance: 1.000 MΩ min. at 500VDC
• Dielectric strength: 2.000 Vrms 50 Hz min.
• Operating Life:    10.000 cycles at full load
• Termination Style: solder lug / quick-connect terminals

Files:

• Datasheet

High Power Rotary Switch - Can be used as Voltage or Impedance selector

• 1 pole / 3 position
• Solder lugs
• Shaft Diameter 6 mm, D-Shaft
• Rating: 250 VAC 6(4) A
• Contact Resistance: 100MOhm Max
• Dielectric Intensity:
  • 1500VAC / 5S for terminal and terminal
  • 3000VAC / 5s for terminal and ground
• Withstand Voltage: 1500VAC / min
• Operating Temperature: -25~85°C
• Insulation Resistance: 500 VDC, 100MOhm Min
• Electrical Life: 10,000 cycles
• Housing material: PA66
• Ø: 22 mm
• h: 17,0 mm
• Ø Frontpanel drill: 10 mm

• Turrets
• for 3 mm Boards
• nickel-plated

• Turrets, forked
• for 3 mm Boards
• nickel-plated

• 6,3 mm jack
• mono, switched
• Installation diameter: 10 mm

Files:

• Datasheet

• Type: Alpha Rotary Switch
• Version: 2 pole / 6 positions, non-Shorting
• Shaft lenght: 19 mm
• Rating: 0.3 A / 125 V/AC
• Contact resistance: max. 50 mΩ
• Insulation resistance: min. 100 mΩ / 500 V/DC
• Termination Style: solder lugs
• Shaft: 6,3 mm
• Drill Ø: 8,9 mm

• Type: Octal Socket Fender Style
• Version: Ceramic Chassis mount
•   w/mounting bracket
• Termination Style: solder lugs
• for Tube Type: EL34, E34L, 6L6, 6V6, 6550,
•   KT66/77/88 etc.

• Type: Chickenhead
• Material: Phenolic
• Shaft Size: 6 - 6,3 mm
• Size: 32 x 13,7 mm
• Mounting: Set-Screw

High Power Rotary Switch e.g. for impedance selector switch

• open version
• 1 x 3 Pos, 4-times
• Break-before-make
• Max. Voltage: 380 VAC / 220 VDC
• Max. Current: 3A / 100 VA per contact
• Connection solder contacts
• Shaft Diameter 6 mm, D-Shaft

The switch has four 1 x 3 Pos switches.
Higher switching capacity can be achieved by parallel connection
