Alpha Rotary Switch 4 pole / 3 positions

Mobile Preview: Alpha Rotary Switch 4 pole / 3 positions

Description

Type: Alpha Rotary Switch
Version: 4 pole / 3 positions, non-Shorting
Shaft lenght: 19 mm
Rating: 0.3 A / 125 V/AC
Contact resistance: max. 50 mΩ
Insulation resistance: min. 100 mΩ / 500 V/DC
Termination Style: solder lugs
Shaft: 6,3 mm, D-Shaft
Drill Ø: 8,9 mm
