TT-Kit Spit F.

Product No.:
kit-spitf
<font color=green><b>In stock for immediate delivery.</b></font> </br>Delivery time depends on the destination country* In stock for immediate delivery.
Delivery time depends on the destination country*
Stock:
4 piece
RoHs:
conform
Weight:
6 kg per piece
339,00 €

incl. VAT excl. Shipping costs

Bookmark
Ask Question
Description
A 100% Matchless® Spitfire Clone, Point-to-Point

Set of componentes for building the TT Spit F. Guitar Amp.
Please visit the >>Project page for more infos about the amp, schematics and layout.

INCLUDED:
  • Transformers (Power and Output, tt-ma18pw-INT and Hammond 1750PA or TT-MA18-OT)
  • Resistors
  • Capacitors
  • Jacks
  • Light
  • Wires
  • Board
  • Switches
  • Tubes
  • Fuses & Fuesholder

NOT INCLUDED:
  • Chassis ( see "Accessories" tab for matching chassis )
  • Knobs
  • Faceplate

To build this project knowledge in electric engeneering, experience with high voltage, and the reading and understanding of schematics and dealing with measurement device is highly recommended .
There is NO step-by-step guide for beginners. The circuit and layout plan includes all relevant information. If you don't understand it then don't build it.
THIS IS NOT A BEGINNERS PROJECT !
Manufacturer
Herstellerinformationen | Manufacturer Information

Tube-Town GmbH
Rumbergring 37
D-66969 Lemberg
eMail: info@tube-town.de
Customer reviews (2)

Essential information about customer reviews We do not verify that the published reviews come from such consumers who have actually used or purchased the rated goods or services. All reviews, i.e. positive and negative, are published. No reviews that are unobjective, offensive or unrelated to the product will be published.

  • Roth S., 05/07/2017
    I've just finished mounting this kit. Everything went fine, no parts missing and a lot of useful little accessories included, that's great ! Schematics and layout plan are correct, the amp worked as intended at first start (you just have know what you are doing). Sounds great :-) Thanks Tube Town ! Schematics and layout plan are correct, the amp worked as intended at first start (you just have know what you are doing). Sounds great :-) Thanks Tube Town !
    go to post
