Terminal 10 + 18

• Capacitance: 100 µF
• Voltage Rating: 500 V
• Tolerance: -10 % / +30 %
• Operating Temperature Range: - 25°C / + 70 °C
• Dimensions: Ø 25 mm x 42 mm
• Termination Style: axial leads

• Voltage Rating:    500 V
• Tolerance: 5%
• Operating Temperature Range: - 50°C / + 150°C
• Termination Style: radial

• Primary: 120, 230 & 240 V @ 50 Hz
• Sec. 1: 720 V C.T. @ 400 mA, 60 V Bias Tap
• Sec. 2: 6,3 V C.T. @ 7,5 A
• Sec. 3: 6,3 V C.T. @ 3 A

• Datasheet

• 4+2 Solder lugs

• 2+1 Solder lugs
• vertical

4 tubes, matched as quad

Mullard reincarnated. With the new EL34EH, Marshall amp owners can recreate the balanced tone, deep, tight bass, sweet mids, and well-defined highs of the original equipment Mullards. Innovative design and precision construction give the EL34EH exceptionally smooth and an ideal balance of pleasing even-order harmonics while virtually eliminating undesirable odd-order harmonics.

Files:

• Datasheet

• Inductance (+/- 15%): 10 H
• Resistance (+/- 15%): 195 Ohm
• max Current DC: 100 mA
• max Voltage DC: 400 V
• Leads: min 12 cm
• Hipot tested (100%) mit 1500 VAC

• Datasheet

Kit for TT PSU Mini

The kit includes all components except a powertransformer and a choke for building PSU for tube amps. If you want to use a choke instead of the 5 W resistor than you must order the choke that you need separately.
The PSU can handle max 700 V DC at out B1 and B2, 450 V DC at out B3 and is recommended for tube amps up to 50 Watt. The size of the PSU is 97 x 55 mm only and has a high of ca. 40 mm.

Please refer the attached schematic for more infos about the layout and design of the PSU.

Tip: use Duncanamps' PSU Designer to simulate and calculate power supplies.

Files:

• Document

• Termination Style: Axial
• Power Rating: 5 W
• Tolerance: 5 %
• Temperature Coefficient: 350 PPM / C
• Operating Temperature min/max: - 55 C / + 155 C
• Voltage Rating: 500 V
• Diameter: 8,5 mm
• Length: 25 mm
• Lead Diameter:  0.75 mm

1N5359B, Zener diode,

5.0 W,

24 V,

CB417

• Type: Metalfilm Resistor
• Power: 0,4 Watt
• Voltage: 350 V / 500 VDC Overload
• Tolerance: 1%
• Surface temperature: max. 125 °C
• Temperature coefficient: TC ±50
• Dimensions:    6,3 mm x 2,5 mm
• Termination Style: axial
• RoHS compliant: Yes
• Pack of 5

ORANGE DROP®, 716 P Series

• Polypropylene Film Capacitors, extended foil
• Voltage Rating: 600 V
• Operating Temperature Range: - 55°C / + 85 °C
• Termination Style: radial, copper leads
