Speaker cable, 2 x 6,3 mm plug, 1 m

TT Cable Speaker Cable

• Length: 1 m
• Color: black
• 1st Jack: Mono 6,3 mm (red)
• 2nd Jack: Mono 6,3 mm (red)
• Cable type: Sommer Cable Typ SC-MERIDIAN SP215 2 x 1,5 mm², grey (#so415-0056)

The Invader 50 is the weeter and creamier version of the hugely popular Green Beret.  It retains all the same great rock and roll character with just a little sweeter top end and breakup.  The beefed up coil means you can now use it with higher wattage amps.  It's time to invade your amp with tone!

Thiele-Small Parameters

• Resonant Frequency (Fs): 82.67 Hz
• DC Resistance (Re): 7.83 Ohm
• Coil Inductance (Le): 0.34 mH
• Mechanical Q (Qms): 10.73
• Electromagnetic Q (Qes):0.81
• Total Q (Qts): 0.76
• Compliance Equiv. Vol. (Vas): 24.13 cu ft
• Mech. Compliance of Susp. (Cms):0.13 mm/N
• BL Product (BL): 12.08 T-M
• Diaphragm Mass Inc. Airload (Mms): 29.20 grams
• Surface Area of Cone (Sd): 366.10 cm squared
• Sound Pressure Level (spl): 99.03 db

B-STOCK: could have flaws in weaving

• Color and texture like the "Marshall Bluesbreaker" Grillcloth
• Size (W x L): ca. 80 x 100 cm (only available in this size)
• Material: 100% treated paper
• Price per pcs.
• Actual shades may vary.

Further information and notes on Grillcloth

• FAQ Grillcloth

Dish - Punched for 2 x 1/4" Jack Connectors

• Material: 1.2 mm Steel, black powder coated.
• Size: 78 x 88 mm
• Fixing holes Ø 10 mm

Strap Handle black, small

• Handle Plastic covered with steel inner core
• Metal Endcaps w/ Plastic Cover

Strap Handle, black Marshall  Style
Perfect replacment for the black Marshall handle (MRV18), only the "Marshall" logo is missing

• Plastic covered with steel inner core
• Metal Endcaps w/ Plastic Cover
• Color: Black
• Screws and t-nuts included



Set of metal corners for housing consisting of:

• 8 x Cabinet corner, silver (ah4020)
• 24 x Screws with extra flat head, silver
• 1 mm Steel, nickel plated coated.
• Internal radius: 12 mm

Lemberg 020 Headshell Flatpack
For all chassis of the LoW-Series WITHOUT side mounting brackets.
This flatpack is made of high quality, 15 mm birch multiplex, is completely CNC milled and drilled and very easy to assemble.

For the assembly you need

• Wood drill 5 mm
• Cross-head screwdriver or cordless screwdriver (recommended)
• Wood glue (NOT included in delivery)

The surface of the assembled headshell can be treated as desired. We recommend to oil it, because this is a very simple but effective procedure. However, it can also be painted or covered with Tolex (in which case the width of the front panel may need to be reduced) or otherwise treated.
Furthermore, corners, handles and rubber feet can be added according to your taste and need. Suitable accessories are listed in the accessories list under the product description here.

Files

• Assembly Instruction

Specifications

• Size (WxHxD): 318 x 190 x 215 mm (Outside)
• Hardware: Screws are included.
• Wood: 15 mm Birch Plywood

[content:3210136]

The 12” ET65™ speakers has big and creamy lows blend with tight midrange and sparkling highs for some of the best tones ever created! This speaker is for classic rock, country, and blues. Upgrade from your Celestion™ G12-65.

Unit Weight:  7.5 pounds

Thiele-Small Parameters

• Resonant Frequency (Fs): 98.69 Hz
• DC Resistance (Re): 8.05 Ohm
• Coil Inductance (Le): 0.35 mH
• Mechanical Q (Qms): 5.38
• Electromagnetic Q (Qes): 1.10
• Total Q (Qts): 0.91
• Compliance Equiv. Vol. (Vas): 16.75 cu ft
• Mech. Compliance of Susp. (Cms): 0.09 mm/N
• BL Product (BL): 11.58 T-M
• Diaphragm Mass Inc. Airload (Mms): 29.51 grams
• Surface Area of Cone (Sd): 366.10 cm squared
• Sound Pressure Level (spl): 99.45 db

waterbased Tolex-Glue, 500 ml

How To use ?
The glue must be applied onto the wood and the Tolex.
After a dyring time of ca. 30 min the Tolex can be put onto the wood.

And how much glue do you need ?
The can of 500 ml is enough for ca. 2.3 m². This is enough for a TTC212REX and there is still about 100 ml glue left.

Attention
For a better adhesive power it is recommended to put a second layer of glue onto the tolex after the drying time.

Files:

• Safety Datasheet

The ideal speaker cabinet for the DIY guitarist!
All parts CNC milled and drilled from high quality birch plywood for easy assembly at home or as a base for your own creations.

Size based on the very popular 112AM Lemberg:

• Width: 500 mm
• Height: 410 mm
• Depth: 240 mm
• Speaker cutout: 12"
• Material: 15 mm birch plywood housing, 12 mm birch plywood baffle

The kit includes all components to build the speaker box according to standard as per documentation, such as:

• Connection terminal, round
• Fixing screws for terminal
• Screws and drive-in nuts for speaker mounting
• Wood glue
• Wooden dowels

Not included

• Cable set
• Corner
• Rubber pads
• Handle
• Wood screws

Files:

• Building Instruction (PDF)
