Rubber foot with steel insert 38 x 25 mm

The ideal speaker cabinet for the DIY guitarist!
All parts CNC milled and drilled from high quality birch plywood for easy assembly at home or as a base for your own creations.

Size:

• Width: 350 mm
• Height: 335 mm
• Depth: 225 mm
• Speaker cutout: 8"
• Material: 15 mm birch plywood housing, 12 mm birch plywood baffle

The kit includes all components to build the speaker box according to standard as per documentation, such as:

• Connection terminal, round
• Fixing screws for terminal
• Screws and drive-in nuts for speaker mounting
• Wood glue
• Wooden dowels

Not included

• Cable set
• Corner
• Rubber pads
• Handle
• Wood screws

Files:

• Building Instruction (PDF)

[content:3210136]

The ideal speaker cabinet for the DIY guitarist!
All parts CNC milled and drilled from high quality birch plywood for easy assembly at home or as a base for your own creations.

Size based on the very popular 112AM Lemberg:

• Width: 500 mm
• Height: 410 mm
• Depth: 240 mm
• Speaker cutout: 12"
• Material: 15 mm birch plywood housing, 12 mm birch plywood baffle

The kit includes all components to build the speaker box according to standard as per documentation, such as:

• Connection terminal, round
• Fixing screws for terminal
• Screws and drive-in nuts for speaker mounting
• Wood glue
• Wooden dowels

Not included

• Cable set
• Corner
• Rubber pads
• Handle
• Wood screws

Files:

• Building Instruction (PDF)

[content:3210136]

Set of metal corners for housing consisting of:

• 8 x Cabinet corner w/ cutaway 2 leg, silver (pe-c1824n)
• Steel nickel plated
• High Quality
• 16 x Screws with extra flat head, silver

Set of metal corners for housing consisting of:

• 8 x Cabinet corner w/ cutaway 2 leg, silver (pe-c1824k)
• High Quality
• Powder Coated black
• Internal radius: 12 mm
• 16 x Screws, flat head, black

Punch Sound speakers offer great dynamics and super-fast response, giving the player an extremely solid bass sound.
Equipped with ferrite magnets and steel baskets, they are ideal for classic styles where a clean, tight and bright sound is required.

Specifications

• Nominal Diameter: 209 mm / 8 in
• Nominal Impedance: 8 Ω
• Rated Power AES: 150 W
• Continuos Program Power: 300 W
• Sensitivity @ 1W/1m: 95.0 dB
• Voice Coil Diameter: 50 mm (2")
• Voice Coil Winding Depth: 11 mm
• Magnetic Gap Depth: 8 mm
• Flux Density: 1.10 T
• Magnet Weight: 1100 g
• Net Weight: 3.1 Kg
• Magnet Type: Ferrite
• Basket Material: Pressed Sheet Steel
• Voice Coil Winding Material: Copper
• Voice Coil Former Material: Kapton
• Cone Material: Paper
• Cone Treatment: No
• Surround Material: Treated Cloth
• Dust Dome Material: Solid Paper

Thiele & Small Parameters

• Re: 6.08 Ω
• Qms: 3.61
• Qts: 0.33
• Cms: 203 µm/N
• Vas: 13.1 l
• X max: +/- 3.1 mm
• N: 1.45 %
• Fs: 74.7 Hz
• Qes: 0.36
• Mms: 22.4 g
• Bxl: 13.29 Tm
• Sd: 213.8 cm²
• X var: +/- 6.6 mm
• Le (1KHz): 0.71 mH

Recessed Sprung Handle small

• Version: Surface Mounted Handle - Sprung
• Steel, zinc plated
• 90° stop with PVC grip
• Fixing holes: 5 mm

• Mono Terminal with parallel output for a second cab
• Speaker Crimps for Speaker Connection

• Mesh Gold
• Size: 660 x 150 mm
• Meshsize: 12 x 6 x 1 x 0,5 mm
• Net Weight: ca. 150 g

High Quality Speaker Cabs for the DIY
Specifications

• Size: ca. 510 x 420 x 240 mm
• 1 x 12"
• Material:
  • Body: 18 mm Pine Plywood
  • Baffle: 12 mm Birch Plywood
• Tolex: -
• Grillcloth: -
• Hardware: -
• Back: Open-Back
• Weight: ca.  7,5 kg
• Speaker: None

[content:3210142]
[content:3210137]
[content:3210136]

Pointer Knob "Classic"

• Material: Phenolic
• Shaft Size: 6 - 6,3 mm
• Size: 19 x 14,5 mm
• Mounting: Hexagon Set Screw
