Piping large, silver - 4,8 x 10 mm - 4 m

New version 2024 with reduced material thickness, texture like Tolex Mesa black

• Width ca. 135 cm
• Price per linear meter.
• Actual shades may vary.
• We ship the tolex as one piece if you order more than 1 meter.

Material:

• 80% PVC Film
• 20% Poly-Cotton Fibre
• REACH compliant

Please note !
when you order more than 1 m and select Deutsche Post / DHL Parcel (Not DHL Express)
we need to cut the width of the tolex to ca. 115 cm. Otherwise it is not
possible to ship the tolex with DHL because the parcel length would
exceed the maximum parcel length.

Technical Data:

• Inductance: 10 H

Files:

• Datasheet

• Termination Style: Axial
• Power Rating: 5 W
• Tolerance: 5 %
• Temperature Coefficient: 350 PPM / C
• Operating Temperature min/max: - 55 C / + 155 C
• Voltage Rating: 500 V
• Diameter: 8,5 mm
• Length: 25 mm
• Lead Diameter:  0.75 mm

Resistor, Metal Oxide 5 Watt

• +/- 5% tolerance
• -55° C to 240° C operating range
• max 500 V
• Excellent flame retardant coating
• Small Size

• Type: Electrolytic capacitor
• Capacitance: 22 µF
• Voltage Rating: 100 V
• Tolerance: - 20 % / +20 %
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 7 mm x 11 mm
• Termination Style: axial

Images are for reference only. See Product Specifications

• Type: HV ceramic disk capacitor
•   Epoxy resin molding
•   (insulating and flame retardant)
• Voltage Rating: 2 kV
• Tolerance: - 20 % / +20 %
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: 3 mm x 7 mm
• Grid: 7,5

• Type: Aluminum Electrolytic Capacitors
• Capacitance: 33 + 33 µF
• Voltage Rating: 450 V
• Tolerance: +/- 20%
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 26 mm x 51 mm
• Termination Style: axial

Clamp for capacitors

• Material: Steel, galvanized
• Diameter: 35 mm
