Miniatur-Potentiometer 100k horizontal PT10

• Type: Electrolytic can capacitor
• Capacitance: 22 µF
• Voltage Rating: 63 V
• Tolerance: - 20 % / +20 %
• Operating Temperature Range: - 40°C / + 105 °C
• Dimensions: Ø 6 mm x 11 mm
• Termination Style: radial
• Grid: 2,5

Images are for reference only. See Product Specifications

• Type: Film capacitor
• Dielectric: polypropylene film
• Coating: plastic foil, metalized on both sides
• Capacitance: 0,01 µF
• Voltage Rating: 400 VDC / 250 VAC
• Tolerance: ±10 %
• IEC climate category: 55/100/56
• Operating Temperature Range: - 55°C / + 100 °C
• Dimensions: 10 x 9 x 4 mm
• Termination Style: radial
• Grid: 7,5

• Type: Film capacitor
• Dielectric: polypropylene film
• Coating: plastic foil, metalized on both sides
• Capacitance: 0,022 µF
• Voltage Rating: 400 VDC / 250 VAC
• Tolerance: ±10 %
• IEC climate category: 55/100/56
• Operating Temperature Range: - 55°C / + 100 °C
• Dimensions: 4 x 9 x 13 mm
• Termination Style: radial
• Grid: 7,5

JJ 6L6 - #16 - Mesa RED

• Corresponds to Mesa Color Code RED
• Price for one tube

FAQ: If I order two or more of these tubes, are they all "matched"?
Yes, the tubes are all "matched" and selected for the above amplifiers.

FAQ: Can I change the tubes myself or does anything need to be adjusted?
Adjustment work is not possible on the above amplifiers (unless a bias adjustment has been retrofitted). The exchange can therefore be done without any adjustment or measurement work.

Files:

• Datasheet

• Type: Electrolytic can capacitor
• Capacitance: 100 µF
• Voltage Rating: 35 V
• Tolerance: - 20 % / +20 %
• Operating Temperature Range: - 55°C / + 105 °C
• Dimensions: Ø 6.3 mm x 11.5 mm
• Termination Style: radial
• Grid: 2,5

Images are for reference only. See Product Specifications

• Type: Electrolytic can capacitor
• Capacitance: 47 µF
• Voltage Rating: 35 V
• Tolerance: - 20 % / +20 %
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 5 mm x 11.5 mm
• Termination Style: radial
• Grid: 2,0

Images are for reference only. See Product Specifications

6+2 solder lugs

Mounting kit for all TT-Chassis which are designed for mounting with cagenuts and 19" housings

Included are:

• 4 x cagenut M6
• 4 x thread screw M6 x 30

• Bridge Rectifier
• Average Rectified Output Current Io (@TA = 50°C): 1,5A
• Forward Voltage Vfm(@IF = 1.5A): 1,0 V
• Peak reverse Voltage: 200 V

• Type: Bridge Rectifier
• Max. alternating input voltage: 250 V
• Repetitive peak reverse voltage: 600 V
• Peak forward surge current  I_FSM 50/55 A
• Repetitive peak forward current  I_FRM
  10 A
• Junction temperature: –50 to +150 °C
• Size: 19 x 3,5 x 10 mm

• Type: Electrolytic can capacitor
• Capacitance: 10 µF
• Voltage Rating: 100 V
• Tolerance: - 20 % / +20 %
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 5 mm x 11 mm
• Termination Style: radial
• Grid: 2,0

Images are for reference only. See Product Specifications
