JJ ECC99 Red Label

JJ5Y3S rectifier tube with directly heated cathode. Robust and durable.

Files:

• Datasheet

• Type: Panel Mount Potentiometer - Push / Pull
• Power Rating: 0,125 W log / 0,2 W linear
• Voltage Rating: 150 V DC Audio / 200 V DC linear
• Tolerance: 20%
• Shaft: 6,35 mm, Solid Shaft
• Shaft length: 15 mm
• Drill Ø: M7 (6,8 mm)
• Termination: Solder Lugs
• Dimension: 16 mm
• Switch: DPDT

Silicon Wire 0,5 mm²

• 1m black
• 1m red
• 1m yellow
• 1m green
• 1m blue
• Operation Voltage Uo/U: 300 / 300 V AC
• Test Voltage: 2000 V
• Operating temperatures: –50 bis +180 °C

Silicon Wire 0,25 mm²

• 1m black
• 1m red
• 1m yellow
• Operation Voltage Uo/U: 300 / 300 V AC
• Test Voltage: 2000 V
• Operating temperatures: –50 bis +180 °C



• Silver-plated Copper wire
• Wire diameter 1 mm²
• Length: 5 m

• Silver-plated Copper wire
• Wire diameter 1.2 mm
• Length: 3 m

• Type: Electrolytic capacitor
• Capacitance: 47 µF
• Voltage Rating: 63 V
• Tolerance: - 10 % / +30 %
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 8,5 mm x 17 mm
• Termination Style: axial

Images are for reference only. See Product Specifications

• Type: Electrolytic capacitor
• Capacitance: 22 µF
• Voltage Rating: 35 V
• Tolerance: - 10 % / +30 %
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 5 mm x 11 mm
• Termination Style: axial
• Color and manufacturer may differ from the picture shown

Images are for reference only. See Product Specifications

Psvane 12AX7 / ECC83 preamp tube from the Classic series with red logo.
Dropin replacement for all 12AX7, ECC83 and 7025 tubes.

[content:3210144]
[content:3210145]

• Colors: red, blue, yellow, black
• Packing: 4 x 2 m
• Insulation: Silicon
• Operation Voltage Uo/U: 300 / 300 V AC
• Test Voltage: 2000 V
• Operating temperatures: –50 bis +180 °C
• Cross-Section: 0,5 mm²
• Outer Diameter: 2,1 mm
• Stranded wire structure: 16 x 0,20 mm, tinned copper

Retainer for EL84 / EL844Tubes
