Fender Chassis-Straps Medium

Fender Princeton Reverb Style Chassis, bare
Without drills and cutouts

• Size : 463 x 176,3 x 45 mm
• Material: 2 mm Aluminium
• Protectionfoil Outside
• Made in Germany

Note: Aluminium housings may show machining marks on the surface due to production.

Files:

• Datasheet

Capacitor Cover for Deluxe Reverb

• Size: 145mm x 76 mm, center to center on the mounting holes
• Fender®  Part # 003-7300-000

Superior large plate format Twin Triode, ideal for use in driver and reverb circuits. Offers superior dissipation compared to NOS versions of this tube.
Excellent 12AT7 choice choice for HiFi and guitar amp circuits.
Electro-Harmonix tubes are all new designs and are of excellent quality. Many OEMs use relabeled Electro-Harmonix vacuum tubes in their amplifiers. If you want great sounding tubes at a very reasonable price, then Electro-Harmonix tubes should be on your list.

Files:

• Datasheet

Resistor Metaloxide 2 Watts

• +/- 5% tolerance
• -55° C to 240° C operating range
• Max 500 V
• Excellent flame retardant coating
• Different manufacturers

Please note:
These resistors have a very small form factor:
red: l = 10 mm, d = 3.9 mm
green: l = 11.5 mm, d = 4.5 mm

• Type: Tubular Metalized Polyester Film Capacitors
• Voltage Rating: 630 V
• Tolerance: +/- 10%
• Operating Temperature Range: - 40°C / + 85 °C
• Termination Style: axial
• • Non-inductive
  • Self healing windings.
  • Similar to the Mallorys 150-Series

Wall thickness max: 1,6 mm
Cable diameter: 5,6 - 6,2 mm
Material: PA 6.6, UL 94 V-2
Color: black
Operating temperatures: –35 to +105 °C

Resistor, Metal Oxide 5 Watt

• +/- 5% tolerance
• -55° C to 240° C operating range
• max 500 V
• Excellent flame retardant coating
• Small Size

Mallory Type 150 is a general purpose capacitor for use in blocking, bypass, decoupling, smoothing and some timing applications.

• Epoxy end fill meets UL94V-0
• Non inductively wound
• Flame retardant outer wrap meets UL510
• Non polar

Specifications:

• Operating Tempeature Range: –55 ºC to +125 ºC (derate linearly to 50% rated voltage at 125 ºC)
• Dielectric Withstand Voltage: .6 x rated voltage for 2 s @ +25 ºC ±5 ºC
• Dissipation Factor (DF): tgd x 10–4 at +25 ºC ±5 ºC
• Insulation Resistance: 10,000 MO x µF, 30,000 MO Min.
• Self Inductance: 1 nH max. per 1 mm lead and body length
• Life Test: 1000 hrs @ 85 ºC 1.25 x Vn
• Damp Heat Test: 95% RH @ +45 ºC for 21 days
• Soldering: 260 ºC ±5 ºC for 10 s ±1 s
• Long Term Storage Stability: ?C/C = ±3% after 2 years

Color can differ from the picture.

• Type: Aluminum Electrolytic Capacitors
• Capacitance: 33 + 33 µF
• Voltage Rating: 450 V
• Tolerance: +/- 20%
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 26 mm x 51 mm
• Termination Style: axial

Resistor Metaloxide 2 Watts

• +/- 5% tolerance
• -55° C to 240° C operating range
• Max 500 V
• Excellent flame retardant coating
• Different manufacturers
• Pack of 5

Please note:
These resistors have a very small form factor:
red: l = 10 mm, d = 3.9 mm
green: l = 11.5 mm, d = 4.5 mm

Wall thickness max: 1,6 mm
Cable diameter: 6,4 - 7,4 mm
Material: PA 6.6, UL 94 V-2
Color: black
Operating temperatures: –35 to +105 °C

Clamp for capacitors

• Material: Steel, galvanized
• Diameter: 40 mm
