Tung-Sol 5881 Reissue - SINGLE

Bourns PDA24 Potentiometer, SRT-Type (Standard Rotational Torque), smooth torque
This specialty potentiometer is commonly used in guitar and bass amplifiers. However, it is also suitable for use in electric guitars and basses. This product is designed with the features most widely requested by amplifier designers.

• Mounting: Panel
• Shaft Type: round, straight
• Terminal: Solder Terminal
• Power Rating:
  • Log: 250 mW (1/4W)
  • Lin: 500 mW (1/2 W)
• Max. Operation Voltage:
  • Log: 250 V
  • Lin: 500 V
• Standard Resistance Tolerance: 15%
• Operating Temperature: - 10 C bis +70 C
• Diameter Shaft:    6,35 mm
• LengthShaft: 19 mm
• Rotational Torque: Standard, 20 to 40 g-cm

• U-Shape Chassis
• Version 2020 U
• Size: 480 x 160 x 65 mm
• Material: 2 mm Aluminium
• Made in Germany
• Mounting: with cage nuts (not included)

Files:

• Datasheet V2020
• Datasheet old version

waterbased Tolex-Glue, 500 ml

How To use ?
The glue must be applied onto the wood and the Tolex.
After a dyring time of ca. 30 min the Tolex can be put onto the wood.

And how much glue do you need ?
The can of 500 ml is enough for ca. 2.3 m². This is enough for a TTC212REX and there is still about 100 ml glue left.

Attention
For a better adhesive power it is recommended to put a second layer of glue onto the tolex after the drying time.

Files:

• Safety Datasheet
