TTC Headshell 18Watt Gold - STANDARD - BLACK
TTC Headshell 18Watt Gold - STANDARD - BLACK
Preview: TTC Headshell 18Watt Gold - STANDARD - BLACK
Preview: TTC Headshell 18Watt Gold - STANDARD - BLACK
TTC Headshell 18Watt Gold - STANDARD - BLACK
Mobile Preview: TTC Headshell 18Watt Gold - STANDARD - BLACK
Mobile Preview: TTC Headshell 18Watt Gold - STANDARD - BLACK

TTC Headshell 18Watt Gold - STANDARD - BLACK

Product No.:
ttc-hd-ma020
In stock for immediate delivery. Delivery time depends on the destination country* In stock for immediate delivery. Delivery time depends on the destination country*
Stock:
4 piece
Weight:
15 kg per piece
349,00 €

incl. VAT excl. Shipping costs

Needed for:

TT66 - MKII Tube-Amp Kit

TT66 MKII Guitar Tube-Amp kit:
Including all items for building the TT66-MKII.

NOT included:
- Alu Chassis
- Knobs
- Solder
- Faceplate

Please see the >>Project-Page for more infos and details.

To build this project knowledge in electric engeneering, experience with high voltage, and the reading and understanding of schematics and dealing with measurement device is highly recommended .
There is NO step-by-step guide for beginners. The circuit and layout plan includes all relevant information. If you don't understand it than don't build it.


419,00 €

TT-Kit PX18
TT PX18 - An All-Tube Mini Plexi 18 Watt Guitar Amp Kit.

Set of componentes for building the TT TT PX18 Guitar Amp.
Please visit the >>Project page for more infos about the amp, schematics and layout.

INCLUDED:
  • Outputtransformer: Hammond 1750PA or TT-MA18-OT
  • Powertransformer: Tube-Town 18W, 0-120-230-240V @ 50/60 Hz (since 22. Nov. 2019)
  • Resistors
  • Capacitors
  • Jacks
  • Light
  • Wires
  • Board
  • Switches
  • Tubes
  • Fuses & Fuesholder

NOT INCLUDED:
  • Chassis
  • Knobs
  • Faceplate

To build this project knowledge in electric engeneering, experience with high voltage, and the reading and understanding of schematics and dealing with measurement device is highly recommended .
There is NO step-by-step guide for beginners. The circuit and layout plan includes all relevant information. If you don't understand it then don't build it.
THIS IS NOT A BEGINNERS PROJECT !
369,00 €

Customers who bought this product bought also the following products:

JJ 12AX7 / ECC83S

Sweet and warm sounding preamp tube with high gain. We recommend this tube for guitar/bass amps.

Files:

16,90 €

Psvane 12AX7 / ECC83 - Classic Series
Psvane 12AX7 / ECC83 preamp tube from the Classic series with red logo.
Dropin replacement for all 12AX7, ECC83 and 7025 tubes.

[content:3210144]
[content:3210145]
17,50 €

Potentiometer Alpha 16 PCB 1M Log DPDT - Push / Pull
Panel Mount Potentiometer - Push / Pull
  • Power Rating: 0,125 W
  • Voltage Rating: 150 V AC
  • Tolerance: 20%
  • Shaft: 6,35 mm, Solid Shaft
  • Shaft length: 15 mm
  • Drill Ø: M7 (6,8 mm)
  • Termination: PCB
  • Dimension: 16 mm
  • Switch: DPDT
4,00 €

Wood screw, Pozi drive 3.9x30 mm, black 100 pcs.
Dry wall / wood screw
  • with fine thread
  • phosphated, black-gray
  • 3,9 x 30
  • steel
  • PH 2
  • Pack of 100
1,90 €
0,02 € per Piece

TT 12AX7 / ECC83 Classic
Tube-Town 12AX7 / ECC83 Preamp-Tube

The TT12AX7 impresses with its fine and detailed reproduction of the highs, which is maintained even at high amplification levels. Due to a higher H3 part, the TT12AX7 sounds significantly cleaner than many other 12AX7/ECC83 tubes, which makes the bass range appear much tighter. We therefore especially recommend this tube for styles such as clean, crunch, and metal, where high amplification and clear transparency are required.

Electrical Characteristics

  • Heater voltage (Uf): 6.3V or 12.6V
  • Heater current (If): 300mA at 6.3V, 150mA at 12.6V
  • Anode voltage (Ua): Maximum 300V
  • Grid voltages (Ug1): -2V (typical)
  • Grid voltages: -50V to 0V
  • Anode current (Ia): 1.2mA (typical)
  • Anode power dissipation: Maximum 1W per triode
  • Anode resistance (ra): 62.5kΩ
  • Amplification factor (μ): 100
  • Transconductance (S): 1.6mA/V
  • Input capacitance (Cin): 1.6pF
  • Output capacitance (Cout): 1.6pF

Mechanical Characteristics

  • Socket: B9A (Noval)
  • Number of pins: 9

Pin Configuration

  • 1 Anode (Triode 1)
  • 2 Grid (Triode 1)
  • 3 Cathode (Triode 1)
  • 4 Heater (f)
  • 5 Heater (f)
  • 6 Anode (Triode 2)
  • 7 Grid (Triode 2)
  • 8 Cathode (Triode 2)
  • 9 Center Heater (f)

Application Notes

  • Heater operation: The tube can be operated with 6.3V or 12.6V, depending on the circuit design.
  • Grid resistors: It is recommended to use grid resistors of at least 1MΩ to ensure stable functionality.
  • Coupling capacitors: Capacitors with low capacitance (typically 0.1µF) are recommended to minimize high-frequency interference.
19,50 €
