TT Kit Lummerland-Express Mk2
Set of componentes for building the TT Lummerland Express - Version Mk2
Now build on PCB
Please visit the >>Project page for more infos about the amp.
INCLUDED:
- Mains Transformer universal for 120-230-240 V mains
- Outputtransformer
- Resistors
- Capacitors
- Jacks
- Light
- Wires
- Board
- Switche
- PSU
- Tubes (2 x 12AX7,1 x ECC99)
- Fuses & Fuesholder
NOT INCLUDED:
- Knobs
- Chassis
- Faceplate
To build this project knowledge in electric engeneering, experience with high voltage, and the reading and understanding of schematics and dealing with measurement device is highly recommended .
There is NO step-by-step guide for beginners. The circuit and layout plan includes all relevant information. If you don't understand it than don't build it.
