TT Dumble Style 50 Watt Powertransformer

• Power: 3,5 W
• 4 Ohm @ 14k5
• 8 Ohm @ 29k

Output transformer for 5F6

• Pri.: 4200 Ohm C.T.
• Sec.: 0-4-8-16 Ohm
• Power: 50 Watt (28 Hz -3dB)
• Made in Europe

Files:

• Datasheet

• Type: Aluminum Electrolytic Capacitors
• Capacitance: 100 µF
• Voltage Rating: 350 V
• Tolerance: +/- 20%
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 18 mm x 37 mm
• Termination Style: axial

• Type: Aluminum Electrolytic Capacitors
• Capacitance: 22 µF
• Voltage Rating: 500 V
• Tolerance: +/- 20%
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 18 mm x 39 mm
• Termination Style: axial

• Type: Polyester Film Capacitor
• Voltage Rating: 600 V
• Operating Temperature Range: - 55°C / + 85 °C
• Termination Style: radial, copper leads

• Type: Polyester Film Capacitor
• Voltage Rating: 600 V
• Operating Temperature Range: - 55°C / + 85 °C
• Termination Style: radial, copper leads

• Type: Polyester Film Capacitor
• Voltage Rating: 600 V
• Operating Temperature Range: - 55°C / + 85 °C
• Termination Style: radial, copper leads

• Type: Polyester Film Capacitor
• Voltage Rating: 600 V
• Operating Temperature Range: - 55°C / + 85 °C
• Termination Style: radial, copper leads

Replacment for Fender Amps

• Chassis Hole: 17,5 mm
• Threading: 9/16 - 24
